3/60 - FAN
BSD-1606610116.A207
1606610116
|
£2.52
|
£3.02
|
|
|
4 - SWITCH
BSD-2607200202.A29
2607200202
|
£37.27
|
£44.72
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A237
2600703012
|
£2.80
|
£3.36
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1903
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601116667.A4
2601116667
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-2607329114.A325
2607329114
|
-
|
|
|
|
13 - BALL BEARING 7x22x7
BSD-1900905018.A117
1900905018
|
£18.96
|
£22.75
|
|
|
14 - BALL BEARING 9x24x7
BSD-2600905095.A281
2600905095
|
£12.04
|
£14.45
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A74
2604337003
|
£2.16
|
£2.59
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1863
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A1938
2603490022
|
£1.75
|
£2.10
|
|
|
20 - REFERENCE PLATE
BSD-9920490130.A7
9920490130
|
£1.75
|
£2.10
|
|
|
26 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A113
2603490025
|
£1.75
|
£2.10
|
|
|
29 - COVER DISC
BSD-3600590505.A30
3600590505
|
£1.75
|
£2.10
|
|
|
30 - RUBBER BUFFER
BSD-3602391503.A35
3602391503
|
-
|
|
|
|
37 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A98
2603410048
|
£1.75
|
£2.10
|
|
|
38 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A619
2603490023
|
£1.75
|
£2.10
|
|
|
40 - CABLE L=130 MM
BSD-2604448005.A286
2604448005
|
£1.75
|
£2.10
|
|
|
41 - FLAT SEAL RING
BSD-3601016502.A28
3601016502
|
-
|
|
|
|
44 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A157
2916650003
|
£1.75
|
£2.10
|
|
|
49 - NEEDLE BEARING
BSD-2600917004.A67
2600917004
|
£3.72
|
£4.47
|
|
|
50 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A34
1610910057
|
£2.80
|
£3.36
|
|
|
52 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A655
2603490017
|
£2.16
|
£2.59
|
|
|
53 - CONNECTING CABLE L=98 MM
BSD-2604448074.A98
2604448074
|
£2.16
|
£2.59
|
|
|
54 - CONNECTING CABLE L=68 MM
BSD-2604448100.A149
2604448100
|
£1.75
|
£2.10
|
|
|
61 - SHIM 0.5 MM
BSD-2600100628.A250
2600100628
|
£1.75
|
£2.10
|
|
|
62 - SHIM 0.3 MM
BSD-2600101654.A28
2600101654
|
£2.33
|
£2.80
|
|
|
65 - SUPPRESSION FILTER L=148 MM
BSD-2604465086.A234
2604465086
|
£5.58
|
£6.70
|
|
|
66 - SUPPRESSION FILTER L=126 MM
BSD-2604465097.A110
2604465097
|
£5.58
|
£6.70
|
|
|
69 - EARTH CONDUCTOR
BSD-2604448097.A1
2604448097
|
£1.75
|
£2.10
|
|
|
70 - CLIP
BSD-3600690503.A0
3600690503
|
-
|
|
|
|
71 - O-RING
BSD-2600210043.A18
2600210043
|
£1.75
|
£2.10
|
|
|
72 - SPACER SLEEVE
BSD-3600360505.A18
3600360505
|
£7.78
|
£9.33
|
|
|
74 - BALL DIN 5401-3.5 MM-III-ST
BSD-1903230006.A127
1903230006
|
£2.16
|
£2.59
|
|
|
75 - BALL SUPPORT
BSD-3600034504.A19
3600034504
|
£2.52
|
£3.02
|
|
|
77 - LOCKING RING
BSD-3600390502.A22
3600390502
|
£6.61
|
£7.93
|
|
|
78 - SEAL RING
BSD-3600290502.A3
3600290502
|
£3.72
|
£4.47
|
|
|
82 - RETAINING RING
BSD-3600200516.A17
3600200516
|
£1.75
|
£2.10
|
|
|
83 - SPRING
BSD-3604613507.A12
3604613507
|
£1.95
|
£2.34
|
|
|
84 - SPRING RETAINING RING
BSD-3600118502.A20
3600118502
|
£2.33
|
£2.80
|
|
|
89 - BALL DIN 5401-6 G28
BSD-1903230011.A442
1903230011
|
£2.61
|
£3.13
|
|
|
91 - SPRING
BSD-3604613506.A22
3604613506
|
£1.95
|
£2.34
|
|
|
92 - INSULATING SLEEVE
BSD-3600113506.A17
3600113506
|
£1.75
|
£2.10
|
|
|
94 - SEAL RING
BSD-3600290503.A17
3600290503
|
£2.52
|
£3.02
|
|
|
99 - LOCKING WASHER
BSD-3600171504.A1
3600171504
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-3605108557.A7
3605108557
|
£23.86
|
£28.63
|
|
|
802 - FIELD 230-240V
BSD-2604220526.A5
2604220526
|
£21.68
|
£26.01
|
|
|
803 - ARMATURE 230V
BSD-2604010803.A4
2604010803
|
£58.76
|
£70.51
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A366
1607000386
|
£21.52
|
£25.83
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A5119
160111A3H3
|
£2.61
|
£3.13
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A123
2604321905
|
£11.30
|
£13.56
|
|
|
825 - GEAR HOUSING
BSD-3605190518.A1
3605190518
|
-
|
|
|
|
828 - BEARING BRACKET
BSD-3605806537.A15
3605806537
|
£27.23
|
£32.68
|
|
|
839 - HOUSING COVER
BSD-3605133521.A24
3605133521
|
£8.67
|
£10.41
|
|
|
846 - DRIVE SHAFT Z=33
BSD-3606120566.A0
3606120566
|
-
|
|
|
|
847 - TOOTHED SHAFT Z=41/17
BSD-3606319522.A6
3606319522
|
-
|
|
|
|
858 - CHANGE-OVER SWITCH
BSD-2607200231.A61
2607200231
|
£16.41
|
£19.69
|
|
|
873 - CLUTCH
BSD-3605190520.A5
3605190520
|
-
|
|
|
|
877 - DEPTH-GAUGE
BSD-3600552509.A1
3600552509
|
£24.45
|
£29.34
|
|
|
879 - DEPTH-GAUGE
BSD-3600552505.A7
3600552505
|
-
|
|
|
|
886 - CLUTCH
BSD-3606441503.A18
3606441503
|
-
|
|
|
