Dewalt DXPW005E Type 1 Pressure Washer Spare Parts

An exploded drawing and spare parts listing for the Dewalt DXPW005E Type 1 Pressure Washer

	Ex VAT	Inc VAT
1 - CASING BDE-1004714-00.A3 1004714-00	£25.70	£30.84
2 - SCREW BDE-1004712-13.A1 1004712-13	£1.50	£1.80
3 - KNOB BDE-1004712-40.A6 1004712-40	£7.18	£8.62
4 - SUPPORT BDE-1004714-24.A3 1004714-24	£16.03	£19.24
5 - CASING BDE-1004713-99.A0 1004713-99	£25.70	£30.84
6 - SCREW BDE-1004709-59.A0 1004709-59	£1.50	£1.80
7 - KNOB BDE-1004713-73.A5 1004713-73	£7.18	£8.62
8 - SPACER BDE-1004714-10.A2 1004714-10	£7.18	£8.62
9 - BOLT BDE-1004712-37.A2 1004712-37	£4.69	£5.63
10 - HOSE BDE-1004710-70.A4 1004710-70	£4.69	£5.63
11 - FILTER BDE-1004710-89.A6 1004710-89	£14.57	£17.48
12 - HOSE SA BDE-1004710-68.A0 1004710-68	£10.85	£13.02
13 - NUT BDE-1004709-67.A0 1004709-67	£1.50	£1.80
14 - FILTER BDE-1004710-83.A4 1004710-83	£1.50	£1.80
15 - GUARD BDE-1004713-77.A3 1004713-77	£24.39	£29.27
16 - HANDLE BDE-1004713-75.A3 1004713-75	£60.94	£73.13
17 - GUARD BDE-1004713-64.A6 1004713-64	£7.18	£8.62
18 - GUARD BDE-1004713-65.A5 1004713-65	£7.18	£8.62
19 - CARRIER BDE-1004713-85.A3 1004713-85	£17.48	£20.97
20 - GUARD BDE-1004713-76.A4 1004713-76	£25.70	£30.84
21 - KNOB BDE-1004714-12.A6 1004714-12	£14.57	£17.48
22 - GUARD BDE-1004714-01.A0 1004714-01	£16.03	£19.24
23 - GUARD BDE-1004713-82.A0 1004713-82	£16.03	£19.24
24 - WASHER BDE-1004713-45.A0 1004713-45	£3.30	£3.96
25 - WHEEL BDE-1004713-44.A3 1004713-44	£37.35	£44.82
26 - FRAME BDE-1004713-74.A0 1004713-74	£165.92	£199.11
27 - NUT BDE-1004710-34.A10 1004710-34	£1.50	£1.80
28 - GUARD BDE-1004713-80.A4 1004713-80	£7.18	£8.62
29 - GUARD BDE-1004713-79.A3 1004713-79	£7.85	£9.42
30 - DAMPER BDE-1004713-81.A3 1004713-81	£19.90	£23.88
31 - GUARD BDE-1004713-78.A4 1004713-78	£24.39	£29.27
32 - SCREW BDE-1004712-12.A10 1004712-12	£1.50	£1.80
33 - PLUG BDE-1004713-04.A1 1004713-04	£7.18	£8.62
34 - O RING BDE-1004710-49.A5 1004710-49	£1.50	£1.80
35 - VALVE BDE-1004712-63.A1 1004712-63	£5.88	£7.06
36 - SCREW BDE-1004709-98.A1 1004709-98	£1.50	£1.80
37 - WASHER BDE-1004711-33.A0 1004711-33	£1.50	£1.80
38 - HEAD BDE-1004712-96.A1 1004712-96	£87.82	£105.39
39 - O RING BDE-1004709-60.A5 1004709-60	£1.50	£1.80
40 - PLUG BDE-1004710-03.A0 1004710-03	£5.88	£7.06
41 - O RING BDE-1004709-90.A14 1004709-90	£1.50	£1.80
42 - PLUG BDE-1004711-91.A6 1004711-91	£3.80	£4.56
43 - RING BDE-1004711-80.A3 1004711-80	£1.50	£1.80
44 - SEAL BDE-1004711-84.A3 1004711-84	£14.57	£17.48
45 - GUIDE BDE-1004713-06.A1 1004713-06	£7.18	£8.62
46 - GASKET BDE-1004713-07.A0 1004713-07	£3.30	£3.96
47 - RING BDE-1004713-11.A3 1004713-11	£1.50	£1.80
48 - O RING BDE-1004709-93.A9 1004709-93	£1.50	£1.80
49 - GUIDE BDE-1004713-05.A0 1004713-05	£5.88	£7.06
50 - BODY BDE-1004712-95.A0 1004712-95	£84.42	£101.30
51 - BEARING BDE-1004711-81.A0 1004711-81	£24.39	£29.27
52 - RING BDE-1004710-61.A0 1004710-61	£1.50	£1.80
53 - RING BDE-1004711-83.A0 1004711-83	£1.50	£1.80
54 - O RING BDE-1004709-76.A0 1004709-76	£1.50	£1.80
55 - LEVEL BDE-1004727-72.A1 1004727-72	£16.03	£19.24
56 - RING BDE-1004729-45 1004729-45	£1.50	£1.80
57 - SUPPORT BDE-1004713-01.A3 1004713-01	£7.85	£9.42
58 - SCREW BDE-1004710-48.A2 1004710-48	£1.50	£1.80
59 - PLUG BDE-1004710-10.A6 1004710-10	£7.85	£9.42
60 - NUT BDE-1004710-53.A3 1004710-53	£1.50	£1.80
61 - WASHER BDE-1004710-52.A2 1004710-52	£1.50	£1.80
62 - PISTON BDE-1004710-54.A0 1004710-54	£19.90	£23.88
63 - PLATE BDE-1004710-51.A3 1004710-51	£1.50	£1.80
64 - SEAL BDE-1004710-57.A4 1004710-57	£4.69	£5.63
65 - O RING BDE-1004709-78.A10 1004709-78	£1.50	£1.80
66 - PISTON BDE-1004713-00.A0 1004713-00	£18.91	£22.69
67 - CON ROD BDE-1004712-98.A0 1004712-98	£10.85	£13.02
68 - PIN BDE-1004711-77.A0 1004711-77	£3.30	£3.96
69 - O RING BDE-1004712-57.A1 1004712-57	£1.50	£1.80
70 - COVER BDE-1004712-97.A1 1004712-97	£12.17	£14.60
71 - O RING BDE-1004710-05.A1 1004710-05	£1.50	£1.80
72 - PLUG BDE-1004710-14.A9 1004710-14	£3.80	£4.56
73 - SCREW BDE-1004713-08.A6 1004713-08	£1.50	£1.80
74 - CRANKSHAFT BDE-1004712-99 1004712-99	£110.62	£132.74
75 - KEY BDE-1004713-09.A0 1004713-09	£1.50	£1.80
76 - BEARING BDE-1004710-77.A1 1004710-77	£16.03	£19.24
77 - RING BDE-1004710-58.A0 1004710-58	£7.18	£8.62
78 - HEAD SA BDE-1004727-73.A0 1004727-73	£245.11	£294.13
79 - PUMP SA BDE-1004709-04 1004709-04	£523.98	£628.77
80 - PLUG BDE-1004713-13.A1 1004713-13	£19.90	£23.88
81 - PRESSURE GAUGE BDE-1004709-00.A0 1004709-00	£25.70	£30.84
82 - VALVE KIT BDE-1004708-85.A0 1004708-85	£24.39	£29.27
83 - PISTON KIT BDE-1004709-26.A1 1004709-26	£37.35	£44.82
84 - SEALS KIT BDE-1004709-27.A0 1004709-27	£12.17	£14.60
85 - SEALS KIT BDE-1004709-28.A1 1004709-28	£37.35	£44.82
86 - GASKET SET BDE-1004709-29.A0 1004709-29	£7.18	£8.62
87 - RING BDE-1004708-92.A0 1004708-92	£4.69	£5.63
88 - VALVE BDE-1004709-13 1004709-13	£192.14	£230.57
89 - SCREW BDE-1004712-72.A4 1004712-72	£1.50	£1.80
90 - NUT BDE-1004710-34.A19 1004710-34	£1.50	£1.80
91 - TERMINAL BOX BDE-1004729-46.A0 1004729-46	£25.70	£30.84
92 - INSERT BDE-1004712-45.A6 1004712-45	£17.48	£20.97
93 - PIN BDE-1004712-46.A1 1004712-46	£1.50	£1.80
94 - PLATE BDE-1004711-87.A13 1004711-87	£1.50	£1.80
95 - SPRING BDE-1004712-59.A6 1004712-59	£5.88	£7.06
96 - PISTON BDE-1004712-58.A0 1004712-58	£16.03	£19.24
97 - O RING BDE-1004712-21.A3 1004712-21	£1.50	£1.80
98 - O RING BDE-1004709-88.A3 1004709-88	£1.50	£1.80
99 - RING BDE-1004712-52.A6 1004712-52	£5.88	£7.06
100 - GUIDE BDE-1004712-60.A0 1004712-60	£24.39	£29.27
101 - O RING BDE-1004710-49.A8 1004710-49	£1.50	£1.80
102 - O RING BDE-1004709-75.A15 1004709-75	£1.50	£1.80
103 - SHUTTER BDE-1004712-20.A4 1004712-20	£19.90	£23.88
104 - SEAT BDE-1004712-62.A0 1004712-62	£10.85	£13.02
105 - O RING BDE-1004709-91.A1 1004709-91	£1.50	£1.80
106 - RING BDE-1004712-61.A7 1004712-61	£1.50	£1.80
107 - O RING BDE-1004709-69.A0 1004709-69	£1.50	£1.80
108 - SCREW BDE-1004711-61.A6 1004711-61	£10.85	£13.02
109 - CONNECTOR BDE-1004712-33.A5 1004712-33	£4.69	£5.63
110 - O RING BDE-1004709-78.A9 1004709-78	£1.50	£1.80
111 - BALL BDE-1004710-50.A9 1004710-50	£1.50	£1.80
112 - SPRING BDE-1004711-70.A14 1004711-70	£1.50	£1.80
113 - O RING BDE-1004712-22.A4 1004712-22	£1.50	£1.80
114 - VALVE BODY BDE-1004713-47.A1 1004713-47	£47.08	£56.49
115 - O RING BDE-1004710-44.A1 1004710-44	£1.50	£1.80
116 - O RING BDE-1004711-65.A4 1004711-65	£1.50	£1.80
117 - BODY BDE-1004713-48.A5 1004713-48	£24.39	£29.27
118 - O RING BDE-1004710-11.A1 1004710-11	£1.50	£1.80
119 - SCREW BDE-1004712-23.A3 1004712-23	£9.41	£11.29
120 - O RING BDE-1004712-14.A5 1004712-14	£1.50	£1.80
121 - SHUTTER BDE-1004712-50.A4 1004712-50	£18.91	£22.69
122 - SPRING BDE-1004712-51.A3 1004712-51	£1.50	£1.80
123 - INSERT BDE-1004712-55.A0 1004712-55	£9.41	£11.29
124 - O RING BDE-1004711-57.A6 1004711-57	£1.50	£1.80
125 - O RING BDE-1004712-56.A1 1004712-56	£1.50	£1.80
126 - COUPLING BDE-1004712-54.A4 1004712-54	£14.57	£17.48
127 - RING BDE-1004712-26.A0 1004712-26	£5.88	£7.06
128 - PIN BDE-1004712-25.A2 1004712-25	£7.18	£8.62
129 - SPRING BDE-1004712-24.A0 1004712-24	£1.50	£1.80
130 - WASHER BDE-1004712-06.A10 1004712-06	£1.50	£1.80
131 - O RING BDE-1004710-63.A0 1004710-63	£1.50	£1.80
132 - RING BDE-1004713-50.A3 1004713-50	£5.88	£7.06
133 - O RING BDE-1004709-81.A22 1004709-81	£1.50	£1.80
134 - CONNECTOR BDE-1004713-49.A0 1004713-49	£9.41	£11.29
135 - FORK BDE-1004712-09.A1 1004712-09	£2.78	£3.34
136 - CONNECTOR BDE-1004711-71 1004711-71	£25.70	£30.84
137 - O RING BDE-1004709-79.A5 1004709-79	£1.50	£1.80
138 - CONNECTOR BDE-1004711-02.A5 1004711-02	£14.57	£17.48
139 - EXTENSION BDE-1004714-08.A0 1004714-08	£9.41	£11.29
140 - O RING BDE-1004709-77.A3 1004709-77	£1.50	£1.80
141 - COUPLING BDE-1004710-45.A4 1004710-45	£7.85	£9.42
142 - GASKET SET BDE-1004709-40.A4 1004709-40	£24.39	£29.27
143 - BOX BDE-1004713-97.A3 1004713-97	£17.48	£20.97
144 - SCREW BDE-1004712-47.A3 1004712-47	£1.50	£1.80
145 - CONTACT BDE-1004712-41.A0 1004712-41	£78.12	£93.74
146 - GLAND BDE-1004712-04.A16 1004712-04	£3.80	£4.56
148 - SCREW BDE-1004712-01.A4 1004712-01	£1.50	£1.80
149 - O RING BDE-1004713-95.A3 1004713-95	£1.50	£1.80
150 - CLAMP BDE-1004710-67.A1 1004710-67	£5.88	£7.06
151 - CABLE BDE-1004711-76.A2 1004711-76	£60.94	£73.13
152 - GASKET BDE-1004713-93.A3 1004713-93	£1.50	£1.80
153 - PLATE BDE-1004713-96.A0 1004713-96	£17.48	£20.97
154 - SCREW BDE-1004714-06.A0 1004714-06	£16.03	£19.24
155 - GASKET BDE-1004711-75.A0 1004711-75	£4.69	£5.63
156 - MOTOR BDE-1004709-45.A1 1004709-45	£1166.32	£1399.58
157 - GLAND BDE-1004713-94.A0 1004713-94	£5.88	£7.06
158 - GUIDE BDE-1004714-07.A2 1004714-07	£7.85	£9.42
159 - HANDLE SA BDE-1004709-16.A0 1004709-16	£55.30	£66.36
160 - EXTENSION BDE-1004709-21 1004709-21	£38.80	£46.56
161 - O RING BDE-1004712-02.A7 1004712-02	£7.18	£8.62
162 - HOSE BDE-1004714-05.A1 1004714-05	£104.31	£125.17
163 - O RING BDE-1004709-73.A8 1004709-73	£1.50	£1.80
302 - EXTENSION Optional BDE-1004719-40.A0 1004719-40	£78.12	£93.74
307 - EXTENSION Optional BDE-1004719-45.A5 1004719-45	£157.18	£188.61
308 - EXTENSION Optional BDE-1004719-46.A4 1004719-46	£80.98	£97.18
310 - EXTENSION Optional BDE-1004719-48.A2 1004719-48	£258.10	£309.72
312 - NOZZLE Optional BDE-1004719-50.A10 1004719-50	£34.00	£40.80
314 - NOZZLE Optional BDE-1004719-52.A0 1004719-52	£34.00	£40.80
319 - BRUSH Optional BDE-1004719-57.A2 1004719-57	£119.32	£143.19
322 - HEAD SA Optional BDE-1004719-60.A2 1004719-60	£336.69	£404.03
323 - HOSE Optional BDE-1004719-61.A1 1004719-61	£99.47	£119.36
324 - HOSE Optional BDE-1004719-62.A9 1004719-62	-
325 - COUPLING Optional BDE-1004719-63.A1 1004719-63	£55.30	£66.36
326 - COUPLING Optional BDE-1004719-64.A9 1004719-64	£110.62	£132.74
327 - EXTENSION Optional BDE-1004719-65.A1 1004719-65	£37.35	£44.82
328 - EXTENSION Optional BDE-1004719-66.A9 1004719-66	£44.14	£52.97
329 - EXTENSION Optional BDE-1004719-67.A1 1004719-67	£58.69	£70.43
330 - EXTENSION Optional BDE-1004719-68.A9 1004719-68	£58.69	£70.43
331 - EXTENSION Optional BDE-1004719-69.A1 1004719-69	£65.52	£78.62
333 - HOSE Optional BDE-1004719-71.A0 1004719-71	£125.16	£150.19
