1 - SCREW
BDE-330045-14.A36
330045-14
|
£1.50
|
£1.80
|
|
|
2 - SCREW
BDE-330019-26.A54
330019-26
|
£1.50
|
£1.80
|
|
|
3 - SCREW
BDE-330019-19.A65
330019-19
|
£1.50
|
£1.80
|
|
|
4 - SCREW.TEMP
BDE-330019-11.A54
330019-11
|
£1.50
|
£1.80
|
|
|
5 - SCREW
BDE-330019-50.A100
330019-50
|
£1.50
|
£1.80
|
|
|
6 - SCREW
BDE-330019-32.A137
330019-32
|
£1.50
|
£1.80
|
|
|
10 - FIELD 115V LX
BDE-N411251.A0
N411251
|
£37.35
|
£44.82
|
|
|
10 - FIELD SA GB
BDE-N310019.A2
N310019
|
£38.80
|
£46.56
|
|
|
11 - ARMATURE SA GB
BDE-N467980.A1
N467980
|
£96.55
|
£115.86
|
|
|
11 - ARMATURE 115V LX
BDE-N919714.A0
N919714
|
£121.00
|
£145.20
|
|
|
12 - FIELD CASE
BDE-393239-01.A49
393239-01
|
£14.57
|
£17.48
|
|
|
13 - O RING
BDE-397031-00.A26
397031-00
|
£1.50
|
£1.80
|
|
|
14 - GEARCASE SA
BDE-N442319.A3
N442319
|
£30.08
|
£36.10
|
|
|
15 - GEARCASE COVER SA
BDE-N497001.A2
N497001
|
£58.70
|
£70.44
|
|
|
16 - PINION
BDE-N407625.A2
N407625
|
£7.85
|
£9.42
|
|
|
17 - NUT
BDE-330015-03.A23
330015-03
|
£1.50
|
£1.80
|
|
|
20 - BRUSH SPRING
BDE-645650-00.A10
645650-00
|
£1.50
|
£1.80
|
|
|
21 - BRUSH COVER
BDE-394387-01.A43
394387-01
|
£1.50
|
£1.80
|
|
|
22 - BRUSH HOLDER SA
BDE-N410308.A5
N410308
|
£3.30
|
£3.96
|
|
|
23 - BRUSH PAIR 120V LX
BDE-N084455.A1
N084455
|
£12.17
|
£14.60
|
|
|
23 - BRUSH PAIR GB
BDE-N404514.A4
N404514
|
£7.85
|
£9.42
|
|
|
24 - HANDLE & COVER GB
BDE-636499-01.A0
636499-01
|
£24.39
|
£29.27
|
|
|
24 - HANDLE & COVER LX
BDE-636499-01.A1
636499-01
|
£24.39
|
£29.27
|
|
|
25 - SWITCH SA LX
BDE-N035342.A8
N035342
|
£12.17
|
£14.60
|
|
|
25 - SWITCH SA GB
BDE-N035342.A9
N035342
|
£12.17
|
£14.60
|
|
|
26 - CORD PROTECTOR LX
BDE-330005-11.A6
330005-11
|
£2.26
|
£2.71
|
|
|
26 - CORD PROTECTOR GB
BDE-N219433.A5
N219433
|
£1.50
|
£1.80
|
|
|
27 - CORD CLAMP
BDE-604119-00.A29
604119-00
|
£1.50
|
£1.80
|
|
|
28 - CAPACITOR LX
BDE-632218-00.A16
632218-00
|
£4.69
|
£5.63
|
|
|
28 - CAPACITOR GB
BDE-632218-00.A17
632218-00
|
£4.69
|
£5.63
|
|
|
29 - CORDSET LX
BDE-562226-68.A3
562226-68
|
£34.00
|
£40.80
|
|
|
29 - CORDSET (M/PLUG) GB GB
BDE-N409119.A1
N409119
|
£12.17
|
£14.60
|
|
|
30 - BAFFLE FAN
BDE-631350-00.A28
631350-00
|
£2.26
|
£2.71
|
|
|
31 - SHIELD
BDE-393238-00.A101
393238-00
|
£1.50
|
£1.80
|
|
|
32 - BEARING
BDE-N389509.A40
N389509
|
£3.80
|
£4.56
|
|
|
33 - BEARING
BDE-N110359.A158
N110359
|
£3.75
|
£4.50
|
|
|
34 - SUPPRESSOR GB
BDE-N423473.A3
N423473
|
£2.78
|
£3.34
|
|
|
36 - SCREW
BDE-N033051.A56
N033051
|
£1.50
|
£1.80
|
|
|
37 - BUTTON LOCK-OFF
BDE-636503-00.A26
636503-00
|
£1.50
|
£1.80
|
|
|
38 - SPRING
BDE-636502-00.A10
636502-00
|
£1.50
|
£1.80
|
|
|
39 - COVER
BDE-N391190.A4
N391190
|
£1.50
|
£1.80
|
|
|
40 - RATING PLATE LX
BDE-N427104
N427104
|
£1.50
|
£1.80
|
|
|
40 - RATING PLATE GB
BDE-N427097
N427097
|
£1.50
|
£1.80
|
|
|
41 - INNER FLANGE
BDE-403150-01.A51
403150-01
|
£4.69
|
£5.63
|
|
|
42 - OUTER FLANGE
BDE-401678-05.A26
401678-05
|
£4.69
|
£5.63
|
|
|
43 - SLEEVE INSULATING
BDE-609970-00.A62
609970-00
|
£1.50
|
£1.80
|
|
|
44 - CAP
BDE-630553-00.A17
630553-00
|
£1.50
|
£1.80
|
|
|
45 - SPRING
BDE-638328-00.A18
638328-00
|
£1.50
|
£1.80
|
|
|
46 - RETAINER
BDE-635908-00.A19
635908-00
|
£1.50
|
£1.80
|
|
|
47 - PIN
BDE-634589-00.A7
634589-00
|
£1.82
|
£2.19
|
|
|
48 - O RING
BDE-750831.A17
750831
|
£1.50
|
£1.80
|
|
|
52 - WASHER
BDE-640591-00.A24
640591-00
|
£1.50
|
£1.80
|
|
|
53 - SCREW
BDE-330045-67.A45
330045-67
|
£16.03
|
£19.24
|
|
|
60 - WRENCH PIN
BDE-635261-00.A20
635261-00
|
£4.69
|
£5.63
|
|
|
61 - GUARD SA
BDE-N419366.A1
N419366
|
£14.57
|
£17.48
|
|
|
62 - SCREW
BDE-N082712.A3
N082712
|
£1.50
|
£1.80
|
|
|
63 - SIDE HANDLE
BDE-651858-01.A18
651858-01
|
£7.18
|
£8.62
|
|
|
70 - TERMINAL
BDE-612273-00.A35
612273-00
|
£1.50
|
£1.80
|
|
|
71 - TERMINAL
BDE-610057-00.A32
610057-00
|
£1.50
|
£1.80
|
|
|
73 - TERMINAL
BDE-53650-00.A12
53650-00
|
£1.50
|
£1.80
|
|
|
800 - GREASE 50 GMS
BDE-583534-00.A312
583534-00
|
£144.10
|
£172.92
|
|
