101 - NO LONGER AVAILABLE GB
BDE-000000-00.A23966
000000-00
|
-
|
|
|
|
101 - NO LONGER AVAILABLE LX
BDE-000000-00.A23967
000000-00
|
-
|
|
|
|
102 - NO LONGER AVAILABLE LX
BDE-000000-00.A23968
000000-00
|
-
|
|
|
|
102 - NO LONGER AVAILABLE GB
BDE-000000-00.A23969
000000-00
|
-
|
|
|
|
103 - SWITCH
BDE-945614-00.A3
945614-00
|
-
|
|
|
|
104 - BRUSH CUT OFF 115V
BDE-949646-01.A14
949646-01
|
£25.05
|
£30.06
|
|
|
104 - BRUSH CUT OFF 230V GB
BDE-949646-02.A0
949646-02
|
£8.08
|
£9.70
|
|
|
105 - CABLE LX
BDE-562226-07.A1
562226-07
|
£57.22
|
£68.66
|
|
|
105 - CABLE GB
BDE-562226-09.A20
562226-09
|
-
|
|
|
|
106 - OUTER FLANGE
BDE-622613-02.A128
622613-02
|
£4.83
|
£5.80
|
|
|
107 - INNER FLANGE
BDE-391969-00.A50
391969-00
|
£2.49
|
£2.99
|
|
|
108 - SCREW
BDE-562160-06.A45
562160-06
|
£1.66
|
£1.99
|
|
|
109 - RETAINING PLATE
BDE-605415-00.A46
605415-00
|
-
|
|
|
|
110 - GUARD
BDE-944586-00.A9
944586-00
|
£3.39
|
£4.07
|
|
|
111 - RING
BDE-393576-00.A131
393576-00
|
£1.66
|
£1.99
|
|
|
112 - SCREW for 610704-00 kit
BDE-330045-46.A78
330045-46
|
£1.66
|
£1.99
|
|
|
112 - SCREW
BDE-562160-07.A7
562160-07
|
£1.66
|
£1.99
|
|
|
113 - GEARCASE COVER
BDE-390521-00.A9
390521-00
|
-
|
|
|
|
114 - SPINDLE
BDE-391971-00.A22
391971-00
|
-
|
|
|
|
116 - CORD PROTECTOR LX
BDE-401088-03.A18
401088-03
|
£1.66
|
£1.99
|
|
|
116 - CORD PROTECTOR GB
BDE-N542553.A190
N542553
|
£3.92
|
£4.70
|
|
|
117 - GEAR & PINION
BDE-945295-02.A27
945295-02
|
£19.90
|
£23.88
|
|
|
118 - SCREW
BDE-562097-01.A88
562097-01
|
£1.66
|
£1.99
|
|
|
120 - SPACER INSULATING
BDE-398906-00.A10
398906-00
|
£1.66
|
£1.99
|
|
|
121 - SIDE HANDLE
BDE-573115-00.A80
573115-00
|
£2.87
|
£3.44
|
|
|
122 - FLANGE
BDE-403156-00.A13
403156-00
|
£1.66
|
£1.99
|
|
|
123 - NUT
BDE-945292-00.A161
945292-00
|
£1.66
|
£1.99
|
|
|
124 - BUTTON
BDE-944574-00.A10
944574-00
|
£1.66
|
£1.99
|
|
|
125 - SPRING
BDE-562210-00.A171
562210-00
|
£1.66
|
£1.99
|
|
|
126 - SPINDLE LOCK
BDE-944571-00.A149
944571-00
|
-
|
|
|
|
127 - BEARING
BDE-605040-22.A19
605040-22
|
£4.83
|
£5.80
|
|
|
128 - SLEEVE
BDE-641823-00.A152
641823-00
|
£1.66
|
£1.99
|
|
|
130 - BUFFER
BDE-949638-01.A55
949638-01
|
£1.66
|
£1.99
|
|
|
131 - BAFFLE SA
BDE-401635-00.A7
401635-00
|
-
|
|
|
|
132 - BRUSH HOLDER
BDE-606574-00.A9
606574-00
|
£7.40
|
£8.88
|
|
|
133 - SPRING
BDE-562204-00.A118
562204-00
|
£1.66
|
£1.99
|
|
|
134 - NO LONGER AVAILABLE
BDE-000000-00.A23970
000000-00
|
-
|
|
|
|
135 - BEARING
BDE-605040-02.A32
605040-02
|
£2.32
|
£2.78
|
|
|
136 - END CAP
BDE-394938-01.A4
394938-01
|
-
|
|
|
|
137 - SUPPORT
BDE-611540-00.A31
611540-00
|
£1.66
|
£1.99
|
|
|
138 - WRENCH
BDE-401680-00.A115
401680-00
|
£4.83
|
£5.80
|
|
|
139 - SCREW
BDE-562097-05.A86
562097-05
|
£1.66
|
£1.99
|
|
|
140 - FLANGE
BDE-401622-01.A122
401622-01
|
£1.66
|
£1.99
|
|
|
145 - SCREW
BDE-562097-00.A102
562097-00
|
£1.66
|
£1.99
|
|
|
147 - ELECTRONIC GB
BDE-606175-01.A0
606175-01
|
-
|
|
|
|
147 - NO LONGER AVAILABLE LX
BDE-000000-00.A24000
000000-00
|
-
|
|
|
|
149 - PAD
BDE-402489-00.A40
402489-00
|
£1.66
|
£1.99
|
|
|
160 - BEARING
BDE-N110359.A203
N110359
|
£3.75
|
£4.50
|
|
|
162 - LINK
BDE-611737-00.A11
611737-00
|
£1.66
|
£1.99
|
|
|
163 - BUTTON
BDE-569624-01.A48
569624-01
|
£1.66
|
£1.99
|
|
|
164 - SCREW
BDE-562097-13.A63
562097-13
|
£1.66
|
£1.99
|
|
|
165 - SERVICE KIT
BDE-610704-00.A23
610704-00
|
£17.48
|
£20.97
|
|
|
171 - O RING
BDE-393799-00.A1
393799-00
|
£1.66
|
£1.99
|
|
|
800 - GREASE
BDE-286436-00.A23
286436-00
|
£130.43
|
£156.52
|
|
|
816 - BRAND LABEL
BDE-946194-00.A71
946194-00
|
£1.66
|
£1.99
|
|
|
820 - RATING PLATE
BDE-569037-00.A25
569037-00
|
£3.92
|
£4.70
|
|
