Bosch PSR 72 / 0603937764 / EU 7.2 Volt Spare Parts

An exploded drawing and listing for the Bosch PSR 72 / 0603937764 / EU 7.2 Volt

	Ex VAT	Inc VAT
1 - HOUSING SECTION BSD-2605104509.A7 2605104509	-
2/10 - PINION Z=9 BSD-2606316158.A6 2606316158	-
5 - ADJUSTING SLIDE BSD-2601099055.A89 2601099055	-
25 - KEYLESS CHUCK BSD-2608572200.A9 2608572200	-
45 - PLANETARY GEAR TRAIN BSD-2606200054.A26 2606200054	-
93 - SCREWDRIVER BLADE 6 MM BSD-1609200147.A327 1609200147	£3.72	£4.47
96 - SUPPORT BSD-2608040079.A40 2608040079	£1.75	£2.10
101 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A698 2603490018	£1.75	£2.10
102 - RETAINING BRACKET BSD-2601329041.A120 2601329041	£2.33	£2.80
107 - COUNTERSUNK-HEAD SCREW M5x20 BSD-2609110721.A29 2609110721	£2.16	£2.59
653 - BATTERY CHARGER EU 230/7.2V. 3h BSD-2607224213.A0 2607224213	-
653 - FAST CHARGER ROK 220/7.2-14.4V. 1h BSD-2607224401.A4 2607224401	£58.76	£70.51
653 - CHARGER GB 230/7.2V. 3h BSD-2607224329.A1 2607224329	£23.86	£28.63
654 - SLIDE-IN ACCU PACKAGE 7.2V.1.5Ah.NiCd BSD-2607336141.A38 2607336141	-
654 - FAST CHARGER EU 230/7.2-24V. 1h BSD-2607224467.A0 2607224467	-
797 - CARRYING LOOP BSD-2601398009.A155 2601398009	-
802 - DC MOTOR 7.2V BSD-2607022943.A6 2607022943	-
804 - ON-OFF SWITCH BSD-2607200351.A28 2607200351	-
809 - MANUFACTURER'S NAMEPLATE BSD-2601119108.A4 2601119108	-
820 - REFERENCE PLATE BSD-2601119109.A0 2601119109	-
