1 - RETAINING RING
HIT-330619.A1
330619
|
£1.67
|
£2.00
|
|
|
2 - WASHER (D)
HIT-330856.A5
330856
|
£2.71
|
£3.25
|
|
|
3 - GUIDE SPRING (D)
HIT-331284.A3
331284
|
£1.67
|
£2.00
|
|
|
4 - GUIDE SLEEVE (D)
HIT-322717.A22
322717
|
£4.22
|
£5.07
|
|
|
5 - FRONT CAP
HIT-332198.A2
332198
|
£5.17
|
£6.20
|
|
|
6A - HAMMER CASE
HIT-333745.A0
333745
|
£28.44
|
£34.13
|
|
|
7 - STEEL BALL D3.5 (10 PCS.)
HIT-319535.A33
319535
|
£1.67
|
£2.00
|
|
|
*8A - ANVIL (D)
HIT-333744.A3
333744
|
£51.46
|
£61.75
|
|
|
9 - STEEL BALL D5.556 (10 PCS.)
HIT-959154.A29
959154
|
£1.67
|
£2.00
|
|
|
10A - HAMMER
HIT-333748.A1
333748
|
-
|
|
|
|
11 - STEEL BALL D3.175 (10 PCS.)
HIT-959148.A56
959148
|
£1.67
|
£2.00
|
|
|
12 - WASHER (J)
HIT-315978.A0
315978
|
£1.67
|
£2.00
|
|
|
13A - HAMMER SPRING (H)
HIT-333746.A1
333746
|
-
|
|
|
|
14 - WASHER (S)
HIT-316172.A13
316172
|
£1.67
|
£2.00
|
|
|
15A - STOPPER (B)
HIT-324222.A6
324222
|
£1.67
|
£2.00
|
|
|
16 - SPINDLE
HIT-332186.A7
332186
|
£27.12
|
£32.55
|
|
|
17 - IDLE GEAR SET (2 PCS.)
HIT-326295.A8
326295
|
£25.42
|
£30.51
|
|
|
18 - NEEDLE ROLLER
HIT-319914.A24
319914
|
£1.67
|
£2.00
|
|
|
19A - RING GEAR(E)
HIT-333747.A0
333747
|
£15.84
|
£19.01
|
|
|
20 - O-RING (S-42)
HIT-983852.A17
983852
|
£1.67
|
£2.00
|
|
|
21 - WASHER (E)
HIT-319911.A3
319911
|
£1.67
|
£2.00
|
|
|
22 - BALL BEARING 6901VV
HIT-6901VV.A9
6901VV
|
£11.83
|
£14.20
|
|
|
23 - DAMPER (A)
HIT-324230.A5
324230
|
£1.67
|
£2.00
|
|
|
24 - INNER COVER
HIT-332185.A0
332185
|
£3.28
|
£3.93
|
|
|
25 - ROTOR PINION ASS'Y INCLUD.46
HIT-332188.A0
332188
|
£61.75
|
£74.10
|
|
|
26 - HOUSING (A).(B) SET
HIT-332190.A1
332190
|
£27.82
|
£33.39
|
|
|
28 - PANEL SHEET (B)
HIT-332207.A0
332207
|
£1.67
|
£2.00
|
|
|
29 - TRUSS HD. SCREW M4 (BLACK)
HIT-327001.A9
327001
|
£2.71
|
£3.25
|
|
|
30B - HOOK
HIT-332824.A17
332824
|
£7.12
|
£8.54
|
|
|
31 - LOCK NUT M4 (BLACK)
HIT-327002.A62
327002
|
£2.71
|
£3.25
|
|
|
32 - PACKING
HIT-330854.A6
330854
|
-
|
|
|
|
33 - STRAP (BLACK)
HIT-306952.A54
306952
|
£7.97
|
£9.57
|
|
|
34 - CONTROLLER
HIT-332206.A0
332206
|
£101.81
|
£122.17
|
|
|
35A - DC-SPEED CONTROL SWITCH
HIT-334903.A3
334903
|
£36.81
|
£44.17
|
|
|
36 - PUSHING BUTTON (B)
HIT-324225.A16
324225
|
£2.49
|
£2.99
|
|
|
37A - STATOR FET PCB
HIT-340805.A0
340805
|
-
|
|
|
|
38 - MACHINE SCREW (W/SP. WASHER) M3X5
HIT-994532.A5
994532
|
£1.67
|
£2.00
|
|
|
39 - TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
HIT-301653.A87
301653
|
£1.67
|
£2.00
|
|
|
40 - NAME PLATE
HIT-000000.A3705
000000
|
-
|
|
|
|
41 - BATTERY BSL 1430 (EUROPE AUS NZL) INCLUD.503
HIT-329083.A0
329083
|
£109.82
|
£131.78
|
|
|
42 - WIRING ASS'Y INCLUD.34
HIT-332202.A0
332202
|
-
|
|
|
|
43 - DAMPER (A)
HIT-333750.A2
333750
|
£9.60
|
£11.52
|
|
|
44 - CUSHION
HIT-331101.A3
331101
|
£3.12
|
£3.74
|
|
|
45 - SUMI TUBE
HIT-336090.A2
336090
|
£1.67
|
£2.00
|
|
|
46 - BALL BEARING 625DD
HIT-333826.A9
333826
|
£8.72
|
£10.47
|
|
|
*501 - CHARGER (MODEL UC 18YRSL)
HIT-000000.A3707
000000
|
-
|
|
|
|
502A - CASE
HIT-337852.A1
337852
|
£23.85
|
£28.62
|
|
|
503 - BATTERY COVER
HIT-329897.A51
329897
|
£1.67
|
£2.00
|
|
|
601 - DRILL CHUCK AND ADAPTER SET INCLUD.616
HIT-321823.A23
321823
|
-
|
|
|
|
602 - GREASE (ATTOLUB MS NO.2) 500G
HIT-309922.A39
309922
|
£56.92
|
£68.31
|
|
|
603 - + DRIVER BIT (B) NO.2 50L
HIT-992671.A24
992671
|
-
|
|
|
|
604 - + DRIVER BIT (B) NO.3 50L
HIT-992672.A9
992672
|
£4.33
|
£5.20
|
|
|
605 - NON-MAGNETIC HEX. SOCKET 8MM 65L
HIT-996177.A12
996177
|
-
|
|
|
|
606 - NON-MAGNETIC HEX. SOCKET 10MM 65L
HIT-985329.A27
985329
|
-
|
|
|
|
607 - NON-MAGNETIC HEX. SOCKET 12MM 65L
HIT-996178.A14
996178
|
£16.59
|
£19.91
|
|
|
608 - NON-MAGNETIC HEX. SOCKET 13MM 65L
HIT-996179.A12
996179
|
-
|
|
|
|
609 - NON-MAGNETIC HEX. SOCKET 14MM 65L
HIT-996180.A14
996180
|
-
|
|
|
|
610 - NON-MAGNETIC HEX. SOCKET 15MM 65L
HIT-996185.A7
996185
|
£16.59
|
£19.91
|
|
|
611 - NON-MAGNETIC HEX. SOCKET 16MM 65L
HIT-996181.A12
996181
|
£16.59
|
£19.91
|
|
|
612 - NON-MAGNETIC HEX. SOCKET 17MM 65L
HIT-996182.A14
996182
|
-
|
|
|
|
613 - NON-MAGNETIC HEX. SOCKET 19MM 65L
HIT-996186.A10
996186
|
£16.59
|
£19.91
|
|
|
614 - HEX. SOCKET (LONG) 21MMX166L
HIT-996197.A11
996197
|
£33.82
|
£40.58
|
|
|
615 - BIT PIECE
HIT-996184.A10
996184
|
-
|
|
|
|
616 - CHUCK WRENCH FOR 10VLB-D 1
HIT-987575.A22
987575
|
-
|
|
|
|
617 - CHUCK WRENCH 6.5G
HIT-930119.A9
930119
|
£6.19
|
£7.43
|
|
|
618 - CHUCK ADAPTER
HIT-307543.A8
307543
|
-
|
|
|
|
624 - SILICONE RUBBER
HIT-306927.A45
306927
|
-
|
|
|
