2 - FIELD 220-230V
BSD-1604220354.A42
1604220354
|
£33.74
|
£40.49
|
|
|
3/10 - FAN
BSD-1606610122.A24
1606610122
|
£2.80
|
£3.36
|
|
|
4 - SWITCH
BSD-2607200169.A5
2607200169
|
-
|
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A325
2600703013
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A688
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110483.A83
1601110483
|
£2.61
|
£3.13
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A619
1607328028
|
£5.30
|
£6.36
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A30
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 9x26x8
BSD-1610905009.A64
1610905009
|
£14.72
|
£17.67
|
|
|
16 - BRUSH HOLDER
BSD-3604336016.A4
3604336016
|
-
|
|
|
|
21 - MANUFACTURER'S NAMEPLATE
BSD-1601110490.A9
1601110490
|
£2.52
|
£3.02
|
|
|
22 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A80
2912401019
|
£1.75
|
£2.10
|
|
|
23 - COILED SPRING
BSD-1604651008.A7
1604651008
|
-
|
|
|
|
24 - PROTECTIVE COVER
BSD-1605510157.A3
1605510157
|
£14.72
|
£17.67
|
|
|
27 - INTERMEDIATE RING
BSD-1600221003.A21
1600221003
|
£2.61
|
£3.13
|
|
|
28 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A679
2603410001
|
£1.75
|
£2.10
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591007.A21
1600591007
|
£2.61
|
£3.13
|
|
|
30 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A166
2603435042
|
£1.75
|
£2.10
|
|
|
31 - SEALING CAP
BSD-1605500135.A2
1605500135
|
-
|
|
|
|
32 - INTERMEDIATE RING
BSD-1600502011.A121
1600502011
|
£2.61
|
£3.13
|
|
|
33 - SLOTTED SPRING PIN 6x22 DIN7346
BSD-2917780150.A22
2917780150
|
£1.75
|
£2.10
|
|
|
34 - COVER STRIP
BSD-1601099013.A7
1601099013
|
-
|
|
|
|
35 - HANDLE COVER
BSD-1605500153.A10
1605500153
|
-
|
|
|
|
36 - LOCKING LEVER
BSD-1602099003.A9
1602099003
|
-
|
|
|
|
38 - MOUNTING PLATE
BSD-1600134005.A9
1600134005
|
-
|
|
|
|
39 - CONICAL SPRING WASHER SW 36
BSD-1605703079.A10
1605703079
|
-
|
|
|
|
40 - CONICAL SPRING WASHER dia 30 MM
BSD-1605703080.A6
1605703080
|
-
|
|
|
|
41 - THREAD-FORMING TAP. SCREW DIN 7500-M 4x12
BSD-2914491409.A75
2914491409
|
£1.66
|
£1.99
|
|
|
42 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A526
1900905163
|
£11.30
|
£13.56
|
|
|
43 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A367
2916660014
|
£1.75
|
£2.10
|
|
|
44 - HEX SOCKET HEAD CAP SCREW M6x14 MM
BSD-1603414007.A275
1603414007
|
£2.29
|
£2.75
|
|
|
45 - CYLINDRICAL GEAR Z=41
BSD-1606320076.A10
1606320076
|
-
|
|
|
|
46 - DRIVE SHAFT M6. dia16 MM
BSD-1603124112.A10
1603124112
|
-
|
|
|
|
47 - EXTENSION SPRING
BSD-1604649001.A24
1604649001
|
-
|
|
|
|
48 - NOZZLE SOCKET
BSD-1600910019.A5
1600910019
|
£3.34
|
£4.01
|
|
|
49 - SOCKET HEAD CAP SCREW DIN 84-AM4x5-5.8
BSD-2910011115.A9
2910011115
|
£1.75
|
£2.10
|
|
|
51 - BASE PLATE 170x382 MM
BSD-1608000105.A6
1608000105
|
-
|
|
|
|
52 - RUBBER BUFFER
BSD-1600305001.A40
1600305001
|
£1.75
|
£2.10
|
|
|
53 - SPACER BUSHING
BSD-1600309012.A15
1600309012
|
£1.75
|
£2.10
|
|
|
54 - RIVING KNIFE
BSD-1600025013.A4
1600025013
|
£3.34
|
£4.01
|
|
|
55 - WING NUT M6
BSD-1603339006.A27
1603339006
|
£2.52
|
£3.02
|
|
|
56 - SPACER BUSHING dia33xdia6.2xdia14.7 MM
BSD-1600309013.A19
1600309013
|
-
|
|
|
|
57 - PAN HEAD SCREW M6x170 MM
BSD-1603434005.A28
1603434005
|
-
|
|
|
|
58 - ADJUSTING PLATE
BSD-1601329015.A29
1601329015
|
£1.95
|
£2.34
|
|
|
61 - SPACER RING
BSD-1600201014.A3
1600201014
|
-
|
|
|
|
63 - WING SCREW
BSD-1603480022.A20
1603480022
|
-
|
|
|
|
64 - ROUND-HEAD BOLT M6x35 MM
BSD-1603434006.A10
1603434006
|
-
|
|
|
|
65 - MITER SQUARE
BSD-1608190009.A3
1608190009
|
-
|
|
|
|
66 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A289
1907950006
|
£4.26
|
£5.11
|
|
|
67 - SUPPRESSOR BOX
BSD-1604503014.A46
1604503014
|
-
|
|
|
|
68 - INTERMEDIATE RING
BSD-1600300092.A6
1600300092
|
£1.32
|
£1.58
|
|
|
69 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A445
1600290016
|
£2.61
|
£3.13
|
|
|
70 - BLADE TERMINAL
BSD-1604477005.A71
1604477005
|
£2.61
|
£3.13
|
|
|
73 - MITER SQUARE
BSD-1608190009.A2
1608190009
|
-
|
|
|
|
74 - THREAD-FORMING TAP. SCREW TT M5x30 MM
BSD-1603435022.A9
1603435022
|
£1.75
|
£2.10
|
|
|
77 - PAN HEAD SCREW DIN 923-M4x10-5.8
BSD-2910271120.A4
2910271120
|
£1.32
|
£1.58
|
|
|
80 - O-RING 46.0x1.1 MM
BSD-3600210124.A215
3600210124
|
£2.80
|
£3.36
|
|
|
650 - PARALLEL-GUIDE
BSD-2608005036.A76
2608005036
|
£8.67
|
£10.41
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014129.A79
1607014129
|
£16.41
|
£19.69
|
|
|
801 - SPIRAL SPRING
BSD-2604652008.A34
2604652008
|
-
|
|
|
|
805 - POWER SUPPLY CORD I 4.15m 2 x 1.0mm H05VV-F
BSD-2604460102.A18
2604460102
|
-
|
|
|
|
826 - BEARING COVER
BSD-1605808062.A1
1605808062
|
-
|
|
|
|
830 - ARMATURE WITH FAN 220V
BSD-1604010324.A2
1604010324
|
-
|
|
|
|
835 - PARTS SET
BSD-1607000923.A3
1607000923
|
-
|
|
|
|
837 - PIVOTING BLADE GUARD
BSD-1605510172.A29
1605510172
|
-
|
|
|
|
850 - GUIDE BUSHING
BSD-1600309011.A17
1600309011
|
-
|
|
|
|
856 - PARTS SET
BSD-1607000197.A39
1607000197
|
-
|
|
|
|
859 - PARTS SET
BSD-1607000197.A40
1607000197
|
-
|
|
|
|
872 - PARTS SET
BSD-1607000222.A3
1607000222
|
-
|
|
|
|
878 - PARTS SET
BSD-1607000205.A52
1607000205
|
-
|
|
|
|
880 - SEALING DISK
BSD-1600135002.A7
1600135002
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1516
160111A3H3
|
£2.61
|
£3.13
|
|
