1 - MOTOR HOUSING
BSD-3605108548.A16
3605108548
|
-
|
|
|
|
2 - ARMATURE 110-120V
BSD-3604011521.A0
3604011521
|
£156.22
|
£187.46
|
|
|
2/60 - FAN
BSD-3606610515.A5
3606610515
|
-
|
|
|
|
3 - FIELD 110-120V
BSD-3604220527.A3
3604220527
|
£37.72
|
£45.27
|
|
|
4 - HANDLE COVER
BSD-3605500572.A2
3605500572
|
£14.08
|
£16.89
|
|
|
5 - HOUSING COVER
BSD-3605500573.A22
3605500573
|
£2.94
|
£3.53
|
|
|
6 - POWER SUPPLY CORD 4.25m 2 x 1.5mm H05RN-F
BSD-3604460605.A0
3604460605
|
-
|
|
|
|
7 - SPINDLE WITH GEAR Z=61
BSD-3606328508.A3
3606328508
|
£43.71
|
£52.45
|
|
|
8 - BRUSH HOLDER
BSD-3600492505.A18
3600492505
|
£15.65
|
£18.78
|
|
|
11 - PIVOTING BLADE GUARD
BSD-3605500541.A10
3605500541
|
-
|
|
|
|
13 - GEAR HOUSING
BSD-3605806507.A4
3605806507
|
-
|
|
|
|
14 - DIAL
BSD-3605702529.A22
3605702529
|
-
|
|
|
|
15 - DEPTH-GAUGE
BSD-3605702558.A2
3605702558
|
£14.72
|
£17.67
|
|
|
16 - MAINS SWITCH
BSD-2610916046.A13
2610916046
|
-
|
|
|
|
17 - PROTECTING COVER
BSD-3605510528.A2
3605510528
|
£21.68
|
£26.01
|
|
|
18 - FASTENING CLAMP
BSD-3601032500.A29
3601032500
|
£7.72
|
£9.27
|
|
|
21 - CONICAL SPRING WASHER
BSD-3600144507.A17
3600144507
|
-
|
|
|
|
22 - GROOVE BALL BEARING
BSD-3600900521.A17
3600900521
|
£18.96
|
£22.75
|
|
|
23 - NEEDLE-ROLLER BEARING
BSD-3600910502.A7
3600910502
|
£5.58
|
£6.70
|
|
|
24 - GROOVE BALL BEARING
BSD-3600900520.A7
3600900520
|
£15.49
|
£18.59
|
|
|
25 - BALL BEARING
BSD-2610904891.A14
2610904891
|
-
|
|
|
|
26 - SPRING RETAINING RING
BSD-3600119505.A17
3600119505
|
£2.61
|
£3.13
|
|
|
27 - SPRING RETAINING RING
BSD-3600119506.A7
3600119506
|
£2.61
|
£3.13
|
|
|
28 - EXTENSION SPRING
BSD-2610909254.A11
2610909254
|
£6.61
|
£7.93
|
|
|
30 - SCREW CAP
BSD-2610994437.A39
2610994437
|
-
|
|
|
|
31 - GROMMET dia 9.4 MM
BSD-3600707503.A45
3600707503
|
£3.91
|
£4.69
|
|
|
32 - PLAIN WASHER
BSD-3600100515.A18
3600100515
|
-
|
|
|
|
34 - RUBBER RING
BSD-3600206502.A17
3600206502
|
£2.16
|
£2.59
|
|
|
35 - AUXILIARY HANDLE M8
BSD-3603231516.A13
3603231516
|
-
|
|
|
|
36 - WING NUT M8
BSD-3603231524.A13
3603231524
|
£4.48
|
£5.37
|
|
|
37 - T-SLOT SCREW M 8x45 MM
BSD-3603440502.A19
3603440502
|
-
|
|
|
|
38 - RUBBER BUFFER
BSD-3600707504.A16
3600707504
|
-
|
|
|
|
39 - REFERENCE PLATE
BSD-2610911006.A2
2610911006
|
£3.51
|
£4.21
|
|
|
40 - BASE PLATE 396x230 MM
BSD-3601440510.A13
3601440510
|
-
|
|
|
|
41 - ROUND RUBBER
BSD-3600305500.A7
3600305500
|
£2.45
|
£2.94
|
|
|
42 - HEX SOCKET HEAD CAP SCREW
BSD-3603450501.A5
3603450501
|
-
|
|
|
|
44 - TORX OVAL-HEAD SCREW 4x30
BSD-2603490025.A151
2603490025
|
£1.84
|
£2.21
|
|
|
45 - TAPPING SCREW DIN 7971-BZ4.2x25
BSD-2910611029.A9
2910611029
|
£2.61
|
£3.13
|
|
|
46 - TAPPING SCREW DIN 7981-ST4.2x13-C-H
BSD-2910611025.A3
2910611025
|
£1.84
|
£2.21
|
|
|
47 - TAPPING SCREW DIN 7981-ST3.5x16-C-H
BSD-2910611012.A94
2910611012
|
-
|
|
|
|
48 - HEX SCREW DIN 933-M8x30-8.8
BSD-2911061246.A35
2911061246
|
£1.84
|
£2.21
|
|
|
49 - SOCKET HEAD CAP SCREW DIN 7500-CM5x25-ST
BSD-2914411064.A6
2914411064
|
-
|
|
|
|
50 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A183
2603435042
|
£1.75
|
£2.10
|
|
|
51 - TAPPING SCREW DIN 7982-ST3.9x45-F-H
BSD-2910611483.A6
2910611483
|
-
|
|
|
|
52 - TAPPING SCREW DIN 7982-ST3.9x45-F-H
BSD-2910611483.A7
2910611483
|
-
|
|
|
|
53 - SET SCREW
BSD-3603415566.A12
3603415566
|
£2.64
|
£3.17
|
|
|
54 - SOCKET HEAD CAP SCREW
BSD-3603415553.A5
3603415553
|
£2.74
|
£3.29
|
|
|
55 - SOCKET HEAD CAP SCREW DIN 7500 CM 4x20
BSD-2914411051.A11
2914411051
|
-
|
|
|
|
56 - SEAL RING
BSD-3601016507.A11
3601016507
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW
BSD-3603430502.A12
3603430502
|
£2.45
|
£2.94
|
|
|
58 - MANUFACTURER'S NAMEPLATE
BSD-3601119666.A12
3601119666
|
-
|
|
|
|
59 - SLOTTED SPRING PIN DIN 1481-3x40
BSD-2917765240.A13
2917765240
|
-
|
|
|
|
60 - SPRING WASHER
BSD-3600151506.A7
3600151506
|
-
|
|
|
|
61 - PAN HEAD SCREW
BSD-3603415549.A12
3603415549
|
£2.74
|
£3.29
|
|
|
63 - RIVING KNIFE
BSD-3601098517.A2
3601098517
|
-
|
|
|
|
64 - SOCKET HEAD CAP SCREW DIN 7500-CM4x16-ST
BSD-2914411049.A12
2914411049
|
-
|
|
|
|
66 - CONTROL LEVER
BSD-3603231518.A12
3603231518
|
£4.26
|
£5.11
|
|
|
67 - EXTENSION SPRING
BSD-3604648503.A8
3604648503
|
-
|
|
|
|
68 - LOCKING LEVER
BSD-3601960500.A12
3601960500
|
-
|
|
|
|
70 - SUPPRESSION CAPACITOR
BSD-3607328509.A13
3607328509
|
-
|
|
|
|
71 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x12-8.8
BSD-2910141193.A43
2910141193
|
-
|
|
|
|
72 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A1423
2915011007
|
-
|
|
|
|
74 - EDGE GUIDE
BSD-2608190002.A84
2608190002
|
-
|
|
|
|
75 - HOLDING BRACKET
BSD-3607000518.A4
3607000518
|
-
|
|
|
|
76 - WING SCREW M6
BSD-1603480018.A80
1603480018
|
£2.27
|
£2.72
|
|
|
78 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A139
2916011014
|
£1.84
|
£2.21
|
|
|
81 - CLAMPING PIECE
BSD-3601030500.A7
3601030500
|
-
|
|
|
|
84 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A100
2916011012
|
£1.84
|
£2.21
|
|
|
650 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A352
1907950006
|
£4.48
|
£5.37
|
|
|
651 - CIRCULAR SAW BLADE dia 230x30 MM. Z=14 HM
BSD-3608640519.A1
3608640519
|
-
|
|
|
|
809 - CARBON-BRUSH SET
BSD-3607014502.A1
3607014502
|
-
|
|
|
|
810 - NAMEPLATE
BSD-3601119590.A9
3601119590
|
-
|
|
|
|
820 - CLAMPING-FLANGE
BSD-3600101510.A9
3600101510
|
-
|
|
|
|
833 - PARTS SET
BSD-3607000566.A12
3607000566
|
£20.42
|
£24.51
|
|
|
865 - DEPTH-GAUGE
BSD-3605702536.A20
3605702536
|
-
|
|
|
|
873 - HEX SCREW DIN 933-M8x25-5.6
BSD-2911051244.A12
2911051244
|
-
|
|
|
|
875 - HOLDING BRACKET
BSD-3605702535.A5
3605702535
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1182
160111A3H3
|
£2.74
|
£3.29
|
|
