1 - MOTOR HOUSING
BSD-1605108244.A5
1605108244
|
£25.05
|
£30.06
|
|
|
2 - FIELD 230V
BSD-1604220346.A5
1604220346
|
£33.74
|
£40.49
|
|
|
4 - SWITCH
BSD-1607200198.A50
1607200198
|
£16.41
|
£19.69
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A663
2600703017
|
£2.74
|
£3.29
|
|
|
8 - NAMEPLATE
BSD-2601111864.A0
2601111864
|
£2.61
|
£3.13
|
|
|
9 - MANUFACTURER'S NAMEPLATE GKS 55 GCE
BSD-2601111867.A2
2601111867
|
£2.80
|
£3.36
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A505
2600905032
|
£5.57
|
£6.68
|
|
|
15 - FAN
BSD-1606610145.A2
1606610145
|
£2.94
|
£3.53
|
|
|
21 - PROTECTIVE COVER
BSD-1605510335.A6
1605510335
|
£33.74
|
£40.49
|
|
|
22 - BASE PLATE
BSD-2601016099.A2
2601016099
|
£63.50
|
£76.20
|
|
|
23 - HANDLE
BSD-1605500248.A0
1605500248
|
£13.12
|
£15.75
|
|
|
24 - PIVOTING BLADE GUARD
BSD-1605510337.A15
1605510337
|
£35.42
|
£42.51
|
|
|
25 - CONTACT SPRING
BSD-1601290010.A49
1601290010
|
£1.75
|
£2.10
|
|
|
26 - CONNECTING PIPING
BSD-1604449024.A2
1604449024
|
£2.16
|
£2.59
|
|
|
27 - CONNECTING PIPING
BSD-1604449017.A10
1604449017
|
£2.16
|
£2.59
|
|
|
28 - CONNECTING PIPING
BSD-1604449025.A19
1604449025
|
£2.27
|
£2.72
|
|
|
29 - SAFETY CATCH
BSD-1601900005.A33
1601900005
|
£2.05
|
£2.46
|
|
|
30 - FELT SEAL
BSD-1601015033.A36
1601015033
|
£1.84
|
£2.21
|
|
|
31 - COMPRESSION SPRING
BSD-1604610018.A49
1604610018
|
£1.84
|
£2.21
|
|
|
32 - PUSH-BUTTON
BSD-1603231019.A6
1603231019
|
-
|
|
|
|
33 - HOUSING COVER
BSD-1605500242.A6
1605500242
|
£10.10
|
£12.12
|
|
|
36 - DRIVE SHAFT
BSD-1603124133.A27
1603124133
|
£10.61
|
£12.73
|
|
|
37 - CYLINDRICAL GEAR
BSD-1606320600.A38
1606320600
|
£6.16
|
£7.39
|
|
|
38 - GROOVE BALL BEARING 12x28x8
BSD-1600905031.A13
1600905031
|
£6.85
|
£8.22
|
|
|
40 - CARRIER
BSD-2601322046.A3
2601322046
|
£12.64
|
£15.17
|
|
|
41 - BRIDGE
BSD-2601302077.A0
2601302077
|
£39.61
|
£47.53
|
|
|
42 - CARRIER
BSD-2601322047.A0
2601322047
|
£6.52
|
£7.83
|
|
|
43 - SPACER TUBE
BSD-2600360016.A0
2600360016
|
£6.85
|
£8.22
|
|
|
44 - TENSIONING LEVER
BSD-1602002006.A5
1602002006
|
£1.84
|
£2.21
|
|
|
45 - RUBBER BUFFER
BSD-1600305002.A24
1600305002
|
£1.32
|
£1.58
|
|
|
46 - CLAMP RING
BSD-1600102024.A37
1600102024
|
£2.27
|
£2.72
|
|
|
47 - EXTENSION SPRING
BSD-1604650018.A3
1604650018
|
£2.74
|
£3.29
|
|
|
48 - CLAMPING-FLANGE
BSD-1605703133.A4
1605703133
|
£5.87
|
£7.04
|
|
|
50 - CONICAL SPRING WASHER
BSD-1605703108.A13
1605703108
|
£2.80
|
£3.36
|
|
|
51 - HEX SOCKET HEAD CAP SCREW M6x14 MM
BSD-1603414007.A359
1603414007
|
£2.29
|
£2.75
|
|
|
52 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A614
1907950006
|
£4.48
|
£5.37
|
|
|
53 - SET SCREW
BSD-2603402008.A3
2603402008
|
£2.61
|
£3.13
|
|
|
54 - WING SCREW M 6x16 MM
BSD-2603480003.A156
2603480003
|
£2.74
|
£3.29
|
|
|
57 - SCREW 4x16
BSD-2603490022.A548
2603490022
|
£1.84
|
£2.21
|
|
|
58 - THREAD-FORMING TAP. SCREW
BSD-2914491411.A3
2914491411
|
£1.84
|
£2.21
|
|
|
59 - THREAD-FORMING TAP. SCREW M6x25 MM
BSD-1603414010.A23
1603414010
|
£1.84
|
£2.21
|
|
|
60 - ROUND-HEAD BOLT DIN 603-M6x20
BSD-2910281201.A40
2910281201
|
£1.84
|
£2.21
|
|
|
61 - SLOTTED SPRING PIN 6x36 DIN 7346
BSD-2917780157.A26
2917780157
|
£1.75
|
£2.10
|
|
|
62 - PLAIN WASHER
BSD-2916011894.A13
2916011894
|
£1.75
|
£2.10
|
|
|
64 - LEVER
BSD-1602002011.A7
1602002011
|
£2.16
|
£2.59
|
|
|
65 - THREAD-FORMING TAP. SCREW DIN 7500-M 4x12
BSD-2914491409.A35
2914491409
|
£1.66
|
£1.99
|
|
|
67 - SPEED GOVERNOR
BSD-1607233210.A7
1607233210
|
£54.42
|
£65.30
|
|
|
68 - CONNECTING CABLE
BSD-1604449013.A27
1604449013
|
£1.84
|
£2.21
|
|
|
73 - TORX OVAL-HEAD SCREW 3x10 ST
BSD-1613435033.A11
1613435033
|
£1.84
|
£2.21
|
|
|
657 - ADAPTER
BSD-1608005008.A8
1608005008
|
£2.80
|
£3.36
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-1607000A57.A8
1607000A57
|
£93.88
|
£112.65
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A209
1607000386
|
£22.60
|
£27.12
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A19
160111A3H3
|
£2.74
|
£3.29
|
|
|
812 - SUPPRESSION FILTER
BSD-1607328028.A747
1607328028
|
£5.57
|
£6.68
|
|
|
816 - CARBON BRUSH
BSD-1607014161.A7
1607014161
|
£13.78
|
£16.54
|
|
|
817 - BRUSH PLATE
BSD-1604336050.A6
1604336050
|
£22.76
|
£27.31
|
|
|
818 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A7
2603410001
|
£1.84
|
£2.21
|
|
|
834 - BEARING BRACKET
BSD-1607000A53.A19
1607000A53
|
£16.41
|
£19.69
|
|
|
899 - GREASE TUBE 225 ML
BSD-1605430003.A92
1605430003
|
£35.42
|
£42.51
|
|
