2 - POLE SHOE 220-230V
BSD-1614220049.A3
1614220049
|
-
|
|
|
|
2/10 - TERMINAL LUG dia 4.3 MM
BSD-1671353005.A8
1671353005
|
-
|
|
|
|
2/20 - END SPLICE dia1.3xdia1.6x10 MM
BSD-1610452003.A19
1610452003
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-1617200017.A38
1617200017
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07RN-F
BSD-1604460447.A42
1604460447
|
£21.68
|
£26.01
|
|
|
5/20 - END SPLICE
BSD-3604477008.A336
3604477008
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A272
3600703011
|
£2.94
|
£3.53
|
|
|
7 - FASTENING CLAMP
BSD-1601302014.A409
1601302014
|
£2.74
|
£3.29
|
|
|
7 - FASTENING CLAMP
BSD-1601302013.A460
1601302013
|
£1.84
|
£2.21
|
|
|
8 - NAMEPLATE
BSD-1611104001.A9
1611104001
|
-
|
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110156.A4
1611110156
|
-
|
|
|
|
12 - HOUSING COVER
BSD-1615500280.A12
1615500280
|
-
|
|
|
|
13 - GEAR HOUSING
BSD-1615806024.A4
1615806024
|
-
|
|
|
|
14 - HANDLE COVER
BSD-1615132016.A3
1615132016
|
-
|
|
|
|
15 - FAN
BSD-1616610052.A9
1616610052
|
-
|
|
|
|
17 - RUBBER RING
BSD-1610206017.A43
1610206017
|
-
|
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522005.A37
1610522005
|
-
|
|
|
|
20 - BEARING PEDESTAL
BSD-1615820087.A17
1615820087
|
-
|
|
|
|
23 - BEARING FLANGE
BSD-1615700024.A3
1615700024
|
-
|
|
|
|
24 - CRANKSHAFT
BSD-1613124019.A18
1613124019
|
-
|
|
|
|
25 - ECCENTRIC BOLT
BSD-1613180002.A38
1613180002
|
-
|
|
|
|
26 - PRESSURE SPINDLE
BSD-1613105010.A34
1613105010
|
-
|
|
|
|
27 - COMPRESSION SPRING
BSD-1604612002.A21
1604612002
|
-
|
|
|
|
28 - SUPPRESSION FILTER
BSD-1617328002.A49
1617328002
|
-
|
|
|
|
28 - SUPPRESSION FILTER
BSD-1617328020.A4
1617328020
|
-
|
|
|
|
28/10 - END SPLICE
BSD-3604477008.A337
3604477008
|
£1.75
|
£2.10
|
|
|
29 - SHIM WASHER 1.8 MM
BSD-1610101610.A16
1610101610
|
-
|
|
|
|
30 - SHIM 0.2 MM
BSD-1610132004.A18
1610132004
|
-
|
|
|
|
31 - CONNECTING ROD
BSD-1612001030.A17
1612001030
|
-
|
|
|
|
32 - CYLINDRICAL GEAR Z=46/6
BSD-1616317023.A2
1616317023
|
-
|
|
|
|
33 - CYLINDRICAL GEAR Z=46/6
BSD-1616317024.A23
1616317024
|
-
|
|
|
|
34 - HAMMER PISTON
BSD-1618700035.A2
1618700035
|
-
|
|
|
|
34/1 - HAMMER PISTON
BSD-1618700051.A38
1618700051
|
-
|
|
|
|
35 - HOLLOW SHAFT Z=6
BSD-1616130005.A25
1616130005
|
-
|
|
|
|
36 - STRIKER
BSD-1613200005.A5
1613200005
|
-
|
|
|
|
36/1 - STRIKER
BSD-1618710046.A38
1618710046
|
-
|
|
|
|
37 - COMPRESSION SPRING
BSD-1614618001.A36
1614618001
|
-
|
|
|
|
38 - BACKUP RING
BSD-1610328010.A31
1610328010
|
-
|
|
|
|
39 - SPRING RETAINING RING DIN 471 25x1.2
BSD-2916650014.A16
2916650014
|
£1.84
|
£2.21
|
|
|
40 - BEARING SLEEVE
BSD-1616334007.A4
1616334007
|
-
|
|
|
|
40/1 - BEARING SLEEVE
BSD-1616334010.A8
1616334010
|
-
|
|
|
|
41 - CARRIER Z=8/9
BSD-1616490009.A13
1616490009
|
-
|
|
|
|
41 - CARRIER Z=12/9
BSD-1616490011.A4
1616490011
|
-
|
|
|
|
42 - STRIKER PIN
BSD-1613124021.A5
1613124021
|
-
|
|
|
|
42/0/1 - STRIKER PIN 15 MM
BSD-1613124027.A9
1613124027
|
-
|
|
|
|
46 - STRAIGHT PIN
BSD-1613101004.A21
1613101004
|
-
|
|
|
|
47 - SUPPORTING DISC 3.0 MM
BSD-1610102016.A38
1610102016
|
-
|
|
|
|
50 - BRUSH HOLDER
BSD-1604336017.A20
1604336017
|
£7.36
|
£8.83
|
|
|
51 - SPIRAL SPRING
BSD-1604652006.A400
1604652006
|
£1.84
|
£2.21
|
|
|
52 - HOUSING COVER
BSD-1615500281.A1
1615500281
|
-
|
|
|
|
55 - HOLDING SPRING
BSD-1614680000.A27
1614680000
|
-
|
|
|
|
56 - CONTROL LEVER
BSD-1612026026.A15
1612026026
|
-
|
|
|
|
58 - SEALING FRAME
BSD-1611015025.A21
1611015025
|
-
|
|
|
|
59 - CONNECTING TERMINAL
BSD-1611091002.A37
1611091002
|
£1.84
|
£2.21
|
|
|
63 - O-RING 62.0x4.0 MM
BSD-1610210089.A38
1610210089
|
-
|
|
|
|
64 - O-RING 45x2.5MM
BSD-1900210145.A12
1900210145
|
£1.75
|
£2.10
|
|
|
65 - INTERMEDIATE RING
BSD-1610300051.A32
1610300051
|
-
|
|
|
|
66 - BALL DIN 5401-5 G28
BSD-1903230009.A972
1903230009
|
£1.84
|
£2.21
|
|
|
67 - BALL DIN 5401-6 G28
BSD-1903230011.A485
1903230011
|
£2.74
|
£3.29
|
|
|
68 - DAMPING RING
BSD-1610210034.A9
1610210034
|
£1.84
|
£2.21
|
|
|
69 - O-RING 18.0x3.0 MM
BSD-1610210058.A192
1610210058
|
£2.61
|
£3.13
|
|
|
70 - O-RING 14.0x2.3 MM
BSD-1610210026.A16
1610210026
|
£1.75
|
£2.10
|
|
|
71 - SEAL RING dia 31.5x42x7 MM
BSD-1610283012.A7
1610283012
|
£8.49
|
£10.19
|
|
|
72 - ROTARY SHAFT LIP SEAL dia13.8xdia26x7.5 MM
BSD-1610283014.A49
1610283014
|
-
|
|
|
|
74 - NEEDLE BEARING dia35xdia42x12 MM
BSD-1610910051.A21
1610910051
|
-
|
|
|
|
75 - NEEDLE BEARING dia14xdia22x13 MM
BSD-1610910056.A78
1610910056
|
-
|
|
|
|
76 - NEEDLE BEARING
BSD-1610910069.A49
1610910069
|
-
|
|
|
|
77 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A7
1610910057
|
£2.80
|
£3.36
|
|
|
78 - GROOVE BALL BEARING 25x47x12
BSD-1900900275.A17
1900900275
|
-
|
|
|
|
79 - GROOVE BALL BEARING DIN 625 6000J C5
BSD-1900900278.A15
1900900278
|
-
|
|
|
|
80 - GROOVE BALL BEARING 10x26x8
BSD-1610905002.A19
1610905002
|
-
|
|
|
|
81 - LUBRICATING FELT
BSD-1610205003.A60
1610205003
|
-
|
|
|
|
83 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1386
2603410001
|
£1.84
|
£2.21
|
|
|
84 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A88
1613412001
|
£1.75
|
£2.10
|
|
|
85 - SCREW B 4.8x45 MM
BSD-3603415560.A271
3603415560
|
£1.75
|
£2.10
|
|
|
86 - TAPPING SCREW DIN 7971-BZ4.8x32
BSD-2910211037.A49
2910211037
|
£1.84
|
£2.21
|
|
|
87 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A577
2910211021
|
£1.75
|
£2.10
|
|
|
88 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A306
2910211018
|
£1.75
|
£2.10
|
|
|
89 - TAPPING SCREW DIN 7971-BZ3.9x9.5
BSD-2910211017.A203
2910211017
|
-
|
|
|
|
90 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A56
2910141166
|
£1.84
|
£2.21
|
|
|
92 - COUNTERSUNK-HEAD SCREW
BSD-1613421000.A7
1613421000
|
-
|
|
|
|
94 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A990
2910021118
|
£1.84
|
£2.21
|
|
|
95 - SOCKET HEAD CAP SCREW DIN 84-BM4x30-8.8
BSD-2910021134.A271
2910021134
|
£1.75
|
£2.10
|
|
|
99 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x40-8.8
BSD-2910141170.A46
2910141170
|
£2.61
|
£3.13
|
|
|
100 - TAPPING SCREW BZ 3.9x19 DIN 7972
BSD-2910601120.A17
2910601120
|
-
|
|
|
|
102 - STRAIGHT PIN RIKO 6325-8m6x40
BSD-2917550184.A10
2917550184
|
-
|
|
|
|
103 - COMPRESSION SPRING
BSD-1614616004.A16
1614616004
|
-
|
|
|
|
104 - PROTECTION SLEEVE
BSD-1610499004.A12
1610499004
|
-
|
|
|
|
105 - RUBBER RING dia42xdia4.5x10 MM
BSD-1610206016.A17
1610206016
|
£1.75
|
£2.10
|
|
|
108/1 - MANUFACTURER'S NAMEPLATE
BSD-1611110468.A1
1611110468
|
-
|
|
|
|
112 - PROTECTIVE CAP
BSD-1610590000.A8
1610590000
|
-
|
|
|
|
113 - RETAINING RING 26 DIN 9045
BSD-2916601014.A35
2916601014
|
-
|
|
|
|
115 - DEPTH-GAUGE SW 6x330 MM
BSD-1613001003.A58
1613001003
|
£4.25
|
£5.10
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025019.A78
1612025019
|
£6.85
|
£8.22
|
|
|
121 - SUPPORT CLAMP
BSD-1618040077.A84
1618040077
|
-
|
|
|
|
122 - STUD BOLT M8
BSD-1613521001.A74
1613521001
|
£5.58
|
£6.70
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316003.A104
1611316003
|
£2.61
|
£3.13
|
|
|
124 - STRAIGHT PIN
BSD-1613100012.A154
1613100012
|
£2.61
|
£3.13
|
|
|
125 - WING SCREW M6x25 MM
BSD-1613480009.A89
1613480009
|
£1.88
|
£2.25
|
|
|
126 - HEX NUT M6
BSD-1613300006.A83
1613300006
|
£1.38
|
£1.66
|
|
|
127 - CLAMPING PLATE
BSD-1611030009.A69
1611030009
|
-
|
|
|
|
652 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A396
2607950004
|
£1.84
|
£2.21
|
|
|
655/1 - PROTECTIVE CAP dia11xdia20.5x25 MM
BSD-1610508005.A6
1610508005
|
-
|
|
|
|
656/20 - BIT HOLDER
BSD-1618598086.A3
1618598086
|
-
|
|
|
|
656/20/1 - BIT HOLDER
BSD-1618598087.A6
1618598087
|
-
|
|
|
|
705/2 - TOOLHOLDER
BSD-1618598074.A3
1618598074
|
-
|
|
|
|
706 - BIT HOLDER
BSD-1618598089.A1
1618598089
|
-
|
|
|
|
706/20 - RETAINING RING 12 DIN 9045
BSD-2916600007.A45
2916600007
|
£2.80
|
£3.36
|
|
|
756/20 - BIT HOLDER
BSD-1618598123.A3
1618598123
|
-
|
|
|
|
760 - CHUCK
BSD-1618571008.A5
1618571008
|
-
|
|
|
|
770 - KEY CHUCK dia 1-10 MM. 1/2
BSD-1608571045.A3
1608571045
|
£31.22
|
£37.47
|
|
|
770 - CHUCK dia1.5-13 MM. 1/2
BSD-1608571069.A230
1608571069
|
£25.05
|
£30.06
|
|
|
770/800 - CHUCK WRENCH SG2
BSD-2607950007.A371
2607950007
|
£6.85
|
£8.22
|
|
|
770/801 - SET SCREW
BSD-1603400001.A3
1603400001
|
-
|
|
|
|
800 - BEVEL GEAR Z=33
BSD-1616333005.A44
1616333005
|
-
|
|
|
|
801 - PARTS SET Z=9/16/48
BSD-1617000930.A19
1617000930
|
-
|
|
|
|
802 - CARBON-BRUSH SET
BSD-1617014106.A16
1617014106
|
£22.60
|
£27.12
|
|
|
802/20 - EXTRACTOR HOOK
BSD-1604682006.A24
1604682006
|
£1.84
|
£2.21
|
|
|
804 - PARTS SET
BSD-1617000062.A6
1617000062
|
-
|
|
|
|
805 - PARTS SET
BSD-1617000064.A3
1617000064
|
-
|
|
|
|
806 - PARTS SET
BSD-1617000085.A5
1617000085
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A4395
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - PARTS SET
BSD-1617000060.A5
1617000060
|
-
|
|
|
|
813 - AUXILIARY HANDLE
BSD-1612025020.A57
1612025020
|
£26.12
|
£31.35
|
|
|
814 - PARTS SET
BSD-1617000038.A27
1617000038
|
-
|
|
|
|
815 - AUXILIARY HANDLE M14
BSD-1602025022.A1304
1602025022
|
£13.41
|
£16.09
|
|
|
830 - ARMATURE 220-230V
BSD-1614010027.A30
1614010027
|
-
|
|
|
|
843 - TOOLHOLDER
BSD-1618597031.A9
1618597031
|
-
|
|
|
|
858 - SEALING FRAME
BSD-1611015017.A7
1611015017
|
-
|
|
|
|
876 - NEEDLE BEARING dia14xdia22x13 MM
BSD-1610910056.A79
1610910056
|
-
|
|
|
