1 - MOTOR HOUSING
BSD-1615106036.A0
1615106036
|
-
|
|
|
|
2 - FIELD 220-230V
BSD-1617031009.A31
1617031009
|
-
|
|
|
|
2/20 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A119
1900452012
|
£1.75
|
£2.10
|
|
|
4 - ARMATURE 220-230V
BSD-1614011019.A17
1614011019
|
-
|
|
|
|
5 - SEALING DISK
BSD-1610108012.A50
1610108012
|
£1.75
|
£2.10
|
|
|
6 - SHIM 1.0 MM
BSD-1610102013.A50
1610102013
|
£1.75
|
£2.10
|
|
|
7 - BEARING FLANGE
BSD-1615805060.A29
1615805060
|
-
|
|
|
|
8 - FAN
BSD-1616610047.A29
1616610047
|
-
|
|
|
|
10 - WHEEL SHAFT
BSD-1613159007.A2
1613159007
|
£46.82
|
£56.18
|
|
|
11 - CYLINDRICAL GEAR Z=45
BSD-1616317029.A11
1616317029
|
-
|
|
|
|
12 - CYLINDRICAL GEAR Z=47/21
BSD-1616328025.A24
1616328025
|
-
|
|
|
|
13 - SEALING FRAME
BSD-1611015023.A0
1611015023
|
£4.75
|
£5.70
|
|
|
14 - GEAR COVER
BSD-1615808050.A11
1615808050
|
£54.42
|
£65.30
|
|
|
15 - SEALING CAP
BSD-1615500168.A7
1615500168
|
£2.52
|
£3.02
|
|
|
16 - FAN COVER
BSD-1615500276.A49
1615500276
|
£52.15
|
£62.58
|
|
|
17 - SWITCH COVER
BSD-1615500261.A0
1615500261
|
£7.78
|
£9.33
|
|
|
18 - SEALING CAP
BSD-1615500282.A7
1615500282
|
£2.33
|
£2.80
|
|
|
20 - SPIRAL SPRING
BSD-1614652000.A90
1614652000
|
-
|
|
|
|
21 - RUBBER PLATE
BSD-1612392001.A19
1612392001
|
£3.80
|
£4.56
|
|
|
22 - RUBBER PLATE
BSD-1612392000.A47
1612392000
|
£3.80
|
£4.56
|
|
|
23 - HANDLE
BSD-1615133025.A0
1615133025
|
£23.86
|
£28.63
|
|
|
25 - CARRIER Z=11/31
BSD-1616490024.A0
1616490024
|
£68.42
|
£82.10
|
|
|
26 - STRIKER
BSD-1618710058.A0
1618710058
|
£41.62
|
£49.95
|
|
|
27 - HAMMER PISTON
BSD-1618700047.A0
1618700047
|
£27.23
|
£32.68
|
|
|
29 - PROTECTIVE TUBE
BSD-1615190006.A5
1615190006
|
-
|
|
|
|
30 - BIT HOLDER Z=12
BSD-1618598100.A0
1618598100
|
£80.61
|
£96.73
|
|
|
31 - STOP DISC
BSD-3606100101.A0
3606100101
|
£12.04
|
£14.45
|
|
|
32 - TOOLHOLDER
BSD-1618597036.A0
1618597036
|
-
|
|
|
|
37 - CONNECTING ROD
BSD-1612001029.A18
1612001029
|
-
|
|
|
|
39 - SEAL RING
BSD-1610280004.A1
1610280004
|
-
|
|
|
|
40 - SPACER SLEEVE
BSD-1610400020.A6
1610400020
|
£2.52
|
£3.02
|
|
|
41 - BUSHING
BSD-1615801022.A6
1615801022
|
-
|
|
|
|
44 - CLUTCH ELEMENT SW22
BSD-1616409005.A11
1616409005
|
£72.18
|
£86.62
|
|
|
45 - COMPRESSION SPRING
BSD-1614619006.A2
1614619006
|
-
|
|
|
|
46 - SHIM dia40.2xdia60x0.3 MM
BSD-1610134004.A2
1610134004
|
£3.80
|
£4.56
|
|
|
48 - TOOTHED SHAFT Z= 8/8
BSD-1613060009.A6
1613060009
|
-
|
|
|
|
49 - PISTON PIN
BSD-1610300058.A18
1610300058
|
£2.80
|
£3.36
|
|
|
50 - SCREW PLUG
BSD-1613465003.A2
1613465003
|
£13.12
|
£15.75
|
|
|
51 - SEAL RING
BSD-1610210048.A9
1610210048
|
£2.80
|
£3.36
|
|
|
52 - GEAR HOUSING
BSD-1615806040.A0
1615806040
|
-
|
|
|
|
53 - GEAR HOUSING
BSD-1615806042.A5
1615806042
|
-
|
|
|
|
54 - COVER DISC dia12xdia26x2.0 MM
BSD-1610113005.A44
1610113005
|
£1.75
|
£2.10
|
|
|
55 - BEARING BOLT
BSD-1610300052.A2
1610300052
|
£5.30
|
£6.36
|
|
|
56 - BEARING BOLT
BSD-1610300057.A11
1610300057
|
£4.75
|
£5.70
|
|
|
57 - NAMEPLATE
BSD-160111A3H3.A3106
160111A3H3
|
£2.61
|
£3.13
|
|
|
58 - ROUND-HEAD GROOVED PIN 2x6 DIN 1476-ST
BSD-2917721034.A136
2917721034
|
£1.75
|
£2.10
|
|
|
59 - SPLIT PIN 3.2x18 DIN 94-ST
BSD-1904681350.A59
1904681350
|
£1.75
|
£2.10
|
|
|
60 - COVER DISC 2.0 MM
BSD-1610101010.A2
1610101010
|
£2.80
|
£3.36
|
|
|
61 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A161
1607000228
|
£23.86
|
£28.63
|
|
|
61/02 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A120
1900452012
|
£1.75
|
£2.10
|
|
|
62 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A605
3600703011
|
£2.80
|
£3.36
|
|
|
63 - FASTENING CLAMP
BSD-1611302006.A11
1611302006
|
-
|
|
|
|
64 - SUPPRESSION FILTER
BSD-1617328002.A16
1617328002
|
-
|
|
|
|
65 - ON-OFF SWITCH
BSD-1617200017.A26
1617200017
|
-
|
|
|
|
66 - CONNECTING TERMINAL
BSD-1611091002.A21
1611091002
|
£1.75
|
£2.10
|
|
|
67 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A138
1900905163
|
£11.30
|
£13.56
|
|
|
68 - GROOVE BALL BEARING 10x32x12
BSD-1610905001.A13
1610905001
|
£14.91
|
£17.89
|
|
|
69 - GROOVE BALL BEARING 12x32x10
BSD-1900900302.A75
1900900302
|
-
|
|
|
|
70 - NEEDLE-ROLLER BEARING
BSD-1610910049.A7
1610910049
|
£37.26
|
£44.71
|
|
|
71 - NEEDLE-ROLLER BEARING
BSD-1610910060.A0
1610910060
|
£31.64
|
£37.97
|
|
|
72 - NEEDLE-ROLLER BEARING
BSD-1610910007.A67
1610910007
|
£21.68
|
£26.01
|
|
|
73 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913001.A10
1610913001
|
£11.30
|
£13.56
|
|
|
74 - THRUST NEEDLE RIM
BSD-1600920000.A33
1600920000
|
£5.30
|
£6.36
|
|
|
75 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A797
2916660013
|
£2.16
|
£2.59
|
|
|
76 - SPRING RETAINING RING DIN 472-26x1.2 MM
BSD-2916660010.A6
2916660010
|
£1.75
|
£2.10
|
|
|
78 - GROOVE BALL BEARING 10x26x8
BSD-1900905159.A1
1900905159
|
£27.23
|
£32.68
|
|
|
80 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A1
2916680006
|
-
|
|
|
|
81 - SPRING WASHER DIN 137-A4
BSD-1600150006.A828
1600150006
|
-
|
|
|
|
83 - O-RING 35x2.5MM
BSD-1900210136.A7
1900210136
|
£3.72
|
£4.47
|
|
|
84 - O-RING 70x3 MM
BSD-1900210160.A52
1900210160
|
£5.58
|
£6.70
|
|
|
85 - O-RING 55x3 MM
BSD-1900210152.A8
1900210152
|
£3.72
|
£4.47
|
|
|
86 - O-RING 30x2 MM
BSD-1900210130.A53
1900210130
|
£3.72
|
£4.47
|
|
|
88 - O-RING 22.0x6.0 MM
BSD-1610210042.A28
1610210042
|
£1.75
|
£2.10
|
|
|
89 - SHAFT SEAL A 30x42x7 DIN 3760
BSD-2916740053.A12
2916740053
|
£13.41
|
£16.09
|
|
|
90 - HEX NUT DIN 985-M8-8
BSD-2915061005.A69
2915061005
|
£2.61
|
£3.13
|
|
|
91 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913006.A2
1610913006
|
£4.75
|
£5.70
|
|
|
93 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x12-8.8
BSD-2910141154.A17
2910141154
|
£1.75
|
£2.10
|
|
|
93 - HEX SOCKET HEAD CAP SCREW DIN 912-M 4x12-8.8
BSD-2910141122.A146
2910141122
|
£2.16
|
£2.59
|
|
|
94 - RETAINING RING DIN 9045-24
BSD-2916601012.A17
2916601012
|
£2.52
|
£3.02
|
|
|
95 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A165
2910211220
|
-
|
|
|
|
96 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A15
2910021118
|
£1.75
|
£2.10
|
|
|
98 - SOCKET HEAD CAP SCREW DIN 84-B5x65-5.8
BSD-2910011179.A12
2910011179
|
-
|
|
|
|
99 - SOCKET HEAD CAP SCREW DIN 84-AM6x28-8.8
BSD-2910021204.A24
2910021204
|
-
|
|
|
|
100 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x18-8.8
BSD-2910141199.A17
2910141199
|
£3.72
|
£4.47
|
|
|
101 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x25-8.8
BSD-2910141244.A105
2910141244
|
£1.75
|
£2.10
|
|
|
102 - HEX SOCKET HEAD CAP SCREW DIN 912-M5X16-8.8
BSD-2910141158.A120
2910141158
|
£1.75
|
£2.10
|
|
|
103 - COUNTERSUNK-HEAD SCREW M 8x16 DIN 7991-8.8
BSD-2910540238.A9
2910540238
|
-
|
|
|
|
104 - MANUFACTURER'S NAMEPLATE
BSD-1611110162.A4
1611110162
|
-
|
|
|
|
105 - REFERENCE PLATE
BSD-1601110058.A200
1601110058
|
£1.75
|
£2.10
|
|
|
112 - CYLINDRICAL GEAR Z=31
BSD-1616317027.A0
1616317027
|
-
|
|
|
|
113 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-8.8
BSD-2910021120.A180
2910021120
|
£1.75
|
£2.10
|
|
|
114 - SHIM 0.3 MM
BSD-1600101641.A126
1600101641
|
£3.72
|
£4.47
|
|
|
115 - SPRING RETAINING RING DIN 472-45x1.75MM
BSD-2916660020.A11
2916660020
|
£1.66
|
£1.99
|
|
|
650/1 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A258
1907950007
|
£5.30
|
£6.36
|
|
|
650/2 - PROTECTIVE CAP
BSD-2600508019.A0
2600508019
|
£1.75
|
£2.10
|
|
|
651 - CARRYING CASE
BSD-1615438107.A9
1615438107
|
-
|
|
|
|
652 - PROTECTIVE CAP
BSD-2600508019.A1
2600508019
|
£1.75
|
£2.10
|
|
|
653 - AUXILIARY HANDLE M14
BSD-1602025022.A1372
1602025022
|
£13.41
|
£16.09
|
|
|
653 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A1400
1602025030
|
£18.96
|
£22.75
|
|
|
801 - TOOL HOLDER SET
BSD-1617000056.A5
1617000056
|
-
|
|
|
|
802 - LOCKING BOLT SET
BSD-1617000014.A87
1617000014
|
£24.45
|
£29.34
|
|
|
803 - PARTS SET
BSD-1617000055.A0
1617000055
|
-
|
|
|
|
804 - PARTS SET
BSD-1617000080.A5
1617000080
|
-
|
|
|
|
805 - PARTS SET
BSD-1617000081.A0
1617000081
|
-
|
|
|
|
807 - FIELD 220-230V
BSD-1617031009.A30
1617031009
|
-
|
|
|
|
808 - CARBON-BRUSH SET
BSD-1617014110.A47
1617014110
|
£18.96
|
£22.75
|
|
|
809 - PARTS SET
BSD-1617031014.A2
1617031014
|
-
|
|
|
|
810 - ECCENTRIC COG WHEEL Z=36
BSD-1616110029.A4
1616110029
|
-
|
|
|
|
811 - BEVEL GEAR Z=28
BSD-1616333016.A2
1616333016
|
£68.42
|
£82.10
|
|
|
812 - POLE HOUSING
BSD-1617000059.A21
1617000059
|
-
|
|
|
|
816 - PARTS SET
BSD-1617000091.A7
1617000091
|
£81.81
|
£98.17
|
|
