1 - MOTOR HOUSING
BSD-1605108045.A28
1605108045
|
-
|
|
|
|
2 - BRUSH HOLDER
BSD-1604336006.A57
1604336006
|
-
|
|
|
|
3 - SPIRAL SPRING
BSD-1604652015.A513
1604652015
|
£2.94
|
£3.53
|
|
|
4 - POLE SHOE 220V
BSD-1604220039.A18
1604220039
|
-
|
|
|
|
5 - AIR-DEFLECTOR RING
BSD-1600209002.A389
1600209002
|
£5.30
|
£6.36
|
|
|
7 - ARMATURE 220V
BSD-1604010048.A18
1604010048
|
-
|
|
|
|
8 - SEALING CAP
BSD-3605500058.A58
3605500058
|
£13.12
|
£15.75
|
|
|
9 - SEALING CAP
BSD-3605500059.A44
3605500059
|
£14.91
|
£17.89
|
|
|
14 - HANDLE
BSD-3605132023.A0
3605132023
|
-
|
|
|
|
15 - SWITCH
BSD-1607200037.A149
1607200037
|
£47.95
|
£57.54
|
|
|
16 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A527
1607000227
|
£23.86
|
£28.63
|
|
|
17 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A490
3600703011
|
£2.94
|
£3.53
|
|
|
21 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A237
1602381001
|
-
|
|
|
|
23 - SOCKET HEAD CAP SCREW DIN 84-BM5x82
BSD-1603410001.A162
1603410001
|
-
|
|
|
|
24 - NAMEPLATE
BSD-160111A3H3.A4368
160111A3H3
|
£2.74
|
£3.29
|
|
|
25 - MANUFACTURER'S NAMEPLATE
BSD-1601110005.A78
1601110005
|
-
|
|
|
|
26 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A148
1601110003
|
-
|
|
|
|
27 - O-RING 74.0x3.0 MM
BSD-1600210006.A292
1600210006
|
£1.84
|
£2.21
|
|
|
28 - FASTENING CLAMP
BSD-1601302014.A376
1601302014
|
£2.74
|
£3.29
|
|
|
29 - CONNECTING TERMINAL
BSD-1601091003.A0
1601091003
|
-
|
|
|
|
32 - SOCKET HEAD CAP SCREW
BSD-2910021181.A59
2910021181
|
-
|
|
|
|
33 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A313
2910011162
|
£1.84
|
£2.21
|
|
|
34 - SOCKET HEAD CAP SCREW DIN 84-AM5x22-8.8
BSD-2910021163.A62
2910021163
|
-
|
|
|
|
35 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A366
2910021118
|
£1.84
|
£2.21
|
|
|
36 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A797
2910021125
|
£1.75
|
£2.10
|
|
|
38 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A730
2910021116
|
£2.27
|
£2.72
|
|
|
39 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A6
2910211019
|
£1.84
|
£2.21
|
|
|
40 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A91
2910021122
|
£2.27
|
£2.72
|
|
|
41 - RETAINING RING 32 DIN 9045
BSD-2916600017.A12
2916600017
|
£1.32
|
£1.58
|
|
|
42 - SPRING LOCK WASHER DIN 127-B 5
BSD-2916680006.A6
2916680006
|
-
|
|
|
|
43 - SPRING LOCK WASHER B 4 DIN 127
BSD-2916681005.A16
2916681005
|
£1.75
|
£2.10
|
|
|
44 - PLAIN WASHER A 4.3 DIN 125-ST
BSD-2916010410.A369
2916010410
|
-
|
|
|
|
45 - SPRING WASHER DIN 137-A4
BSD-1600150006.A601
1600150006
|
-
|
|
|
|
46 - PAN HEAD SCREW DIN 85 AM 4x6-MS
BSD-2910110116.A294
2910110116
|
£1.84
|
£2.21
|
|
|
48 - HANDLE
BSD-3605133010.A40
3605133010
|
-
|
|
|
|
49 - HANDLE 400 MM
BSD-1600763010.A50
1600763010
|
£42.84
|
£51.41
|
|
|
51 - SPINDLE BEARING
BSD-3605806066.A10
3605806066
|
-
|
|
|
|
52 - NEEDLE BEARING
BSD-1600910013.A55
1600910013
|
£5.58
|
£6.70
|
|
|
53 - ROTARY SHAFT LIP SEAL
BSD-1600283003.A17
1600283003
|
£4.26
|
£5.11
|
|
|
54 - GROOVE BALL BEARING
BSD-1600900004.A0
1600900004
|
-
|
|
|
|
55 - SPACER BUSHING
BSD-1600300028.A50
1600300028
|
-
|
|
|
|
56 - DRILLING SPINDLE
BSD-1606135009.A40
1606135009
|
-
|
|
|
|
57 - SHIM 0.5 MM
BSD-1600100631.A34
1600100631
|
£1.75
|
£2.10
|
|
|
58 - CYLINDRICAL GEAR Z=50
BSD-1606317045.A108
1606317045
|
-
|
|
|
|
59 - SHIM 0.8 MM
BSD-1600102678.A0
1600102678
|
-
|
|
|
|
60 - ADJUSTING BOLT
BSD-1603104005.A10
1603104005
|
-
|
|
|
|
61 - SHIM 0.2 MM
BSD-1420100620.A17
1420100620
|
£1.38
|
£1.66
|
|
|
62 - CONTROL LEVER
BSD-1602026026.A0
1602026026
|
-
|
|
|
|
63 - SOCKET HEAD CAP SCREW M3.5x5.5 MM
BSD-1603413005.A125
1603413005
|
£2.64
|
£3.17
|
|
|
64 - FELT WASHER
BSD-1600205009.A11
1600205009
|
-
|
|
|
|
65 - CONTROL LEVER
BSD-1602120006.A86
1602120006
|
-
|
|
|
|
66 - SPINDLE WITH GEAR Z=15/26/33
BSD-1606328060.A11
1606328060
|
-
|
|
|
|
67 - SPINDLE WITH GEAR Z=12
BSD-1606309036.A125
1606309036
|
-
|
|
|
|
68 - CYLINDRICAL GEAR Z=30/41
BSD-1606328059.A39
1606328059
|
-
|
|
|
|
69 - ROTARY SHAFT LIP SEAL
BSD-1600283003.A18
1600283003
|
£4.26
|
£5.11
|
|
|
70 - SHIM 0.5 MM
BSD-1600100631.A35
1600100631
|
£1.75
|
£2.10
|
|
|
71 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A92
2910021122
|
£2.27
|
£2.72
|
|
|
73 - SPRING LOCK WASHER DIN 127-B3.5
BSD-2916680004.A31
2916680004
|
-
|
|
|
|
74 - SPRING RETAINING RING DIN 472-42x1.75MM
BSD-2916660019.A0
2916660019
|
£4.26
|
£5.11
|
|
|
75 - FELT DISC
BSD-1600108003.A209
1600108003
|
£1.32
|
£1.58
|
|
|
76 - BEARING COVER
BSD-1600501019.A260
1600501019
|
£25.05
|
£30.06
|
|
|
77 - GROOVE BALL BEARING 17x35x10
BSD-1600900001.A24
1600900001
|
-
|
|
|
|
78 - INTERMEDIATE BEARING
BSD-3605820033.A86
3605820033
|
-
|
|
|
|
79 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A796
2910021125
|
£1.75
|
£2.10
|
|
|
80 - SHIM 0.10 MM
BSD-1420100023.A198
1420100023
|
-
|
|
|
|
80 - SHIM 0.2 MM
BSD-1600100632.A282
1600100632
|
£1.75
|
£2.10
|
|
|
81 - BALL BEARING 7x22x7
BSD-1900905018.A552
1900905018
|
£19.91
|
£23.89
|
|
|
96 - END SPLICE
BSD-3604477009.A139
3604477009
|
£2.61
|
£3.13
|
|
|
650 - DRIFT
BSD-1601030009.A12
1601030009
|
-
|
|
|
|
801 - BUSHING
BSD-1600300902.A27
1600300902
|
£14.72
|
£17.67
|
|
|
802 - CARBON-BRUSH SET
BSD-1607014102.A186
1607014102
|
-
|
|
|
