Bosch GSR 12 V / 0601916531 / CH 12 Volt Spare Parts

An exploded drawing and listing for the Bosch GSR 12 V / 0601916531 / CH 12 Volt

	Ex VAT	Inc VAT
2/1 - PINION BSD-2606316226.A3 2606316226	£5.87	£7.04
2/4 - ON-OFF SWITCH BSD-2607200461.A6 2607200461	£41.62	£49.95
5 - ADJUSTING SLIDE BSD-2601099114.A4 2601099114	£2.33	£2.80
25 - KEYLESS CHUCK BSD-2608572245.A0 2608572245	£46.82	£56.18
30 - LEAF SPRING BSD-2604690022.A16 2604690022	£1.75	£2.10
32 - ADJUSTING SLIDE BSD-2601099115.A2 2601099115	£1.75	£2.10
54 - TORX SH CAP SCREW M4x8-4.8-Z BSD-2603414049.A25 2603414049	-
91 - SLIDE-IN ACCU PACKAGE 12V.2.6Ah.NiMh BSD-2607335683.A9 2607335683	£154.03	£184.84
91 - SLIDE-IN ACCU PACKAGE 12V.2.0Ah.NiMh BSD-2607335697.A6 2607335697	-
93 - SCREWDRIVER BIT BSD-2607000366.A22 2607000366	-
101 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A48 2603490018	£1.75	£2.10
107 - COUNTERSUNK-HEAD SCREW M5x20 BSD-2609110721.A204 2609110721	£2.16	£2.59
653 - FAST CHARGER EU 230/7.2-24V. 1h BSD-2607224425.A373 2607224425	£88.07	£105.68
801 - HOUSING SECTION BSD-2605105958.A0 2605105958	£27.31	£32.77
802 - DC MOTOR 12-14.4V BSD-2607022869.A2 2607022869	£54.42	£65.30
845 - PLANETARY GEAR TRAIN BSD-2606200945.A1 2606200945	£45.67	£54.80
896 - SPRING ELEMENT BSD-2604690026.A3 2604690026	£1.75	£2.10
