1 - MOTOR HOUSING
BSD-3600760015.A39
3600760015
|
£93.88
|
£112.65
|
|
|
2 - STATOR 370W
BSD-3604090002.A33
3604090002
|
£81.81
|
£98.17
|
|
|
3 - ROTOR
BSD-3604220002.A44
3604220002
|
£93.88
|
£112.65
|
|
|
5 - BEARING FLANGE
BSD-3605700005.A81
3605700005
|
£54.42
|
£65.30
|
|
|
6 - GROOVE BALL BEARING 9x24x7 MM
BSD-3600905039.A284
3600905039
|
£12.04
|
£14.45
|
|
|
7 - BEARING FLANGE
BSD-3605700006.A36
3605700006
|
£72.18
|
£86.62
|
|
|
8 - BALL BEARING 7x19x6
BSD-2600905032.A1316
2600905032
|
£5.30
|
£6.36
|
|
|
9 - SPACER RING
BSD-2600202013.A64
2600202013
|
£8.67
|
£10.41
|
|
|
10 - SPACER RING
BSD-2600202014.A128
2600202014
|
£11.30
|
£13.56
|
|
|
11 - PLAIN WASHER DIN 125-A5.3-ST
BSD-2916011012.A33
2916011012
|
£1.75
|
£2.10
|
|
|
12 - HEX SCREW
BSD-3603450000.A41
3603450000
|
£7.36
|
£8.83
|
|
|
13 - INTERMEDIATE PIECE
BSD-3602305000.A13
3602305000
|
£37.27
|
£44.72
|
|
|
14 - CYLINDRICAL GEAR Z=12
BSD-3606316098.A27
3606316098
|
£27.23
|
£32.68
|
|
|
15 - NEEDLE-ROLLER ASSEMBLY INA K3x5x7
BSD-3600913000.A510
3600913000
|
£4.26
|
£5.11
|
|
|
16 - CYLINDRICAL GEAR Z=16
BSD-3606316099.A77
3606316099
|
£21.68
|
£26.01
|
|
|
26 - PINION
BSD-3606300000.A2
3606300000
|
£33.74
|
£40.49
|
|
|
27 - STOP DISC
BSD-3600101001.A24
3600101001
|
£2.61
|
£3.13
|
|
|
28 - RING GEAR Z=49
BSD-3606334000.A156
3606334000
|
£102.57
|
£123.08
|
|
|
29 - PLANETARY-GEAR CARRIER
BSD-3606337000.A18
3606337000
|
-
|
|
|
|
33 - NEEDLE ROLLER
BSD-3603201000.A133
3603201000
|
£1.75
|
£2.10
|
|
|
34 - SHIM WASHER
BSD-3600103002.A140
3600103002
|
£3.72
|
£4.47
|
|
|
35 - RETAINING RING
BSD-3600224000.A156
3600224000
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A15
1900900287
|
£21.68
|
£26.01
|
|
|
38 - PLANETARY-GEAR CARRIER
BSD-3606337005.A21
3606337005
|
£120.11
|
£144.13
|
|
|
41 - GROOVE BALL BEARING 12x32x10
BSD-1600905007.A110
1600905007
|
£11.30
|
£13.56
|
|
|
43 - SPRING RETAINING RING
BSD-3600119000.A36
3600119000
|
£10.10
|
£12.12
|
|
|
56 - VALVE BODY
BSD-3605190004.A7
3605190004
|
-
|
|
|
|
57 - SILENCER
BSD-3605190014.A17
3605190014
|
-
|
|
|
|
58 - FITTING
BSD-3603458001.A12
3603458001
|
-
|
|
|
|
59 - SINTERED-METAL BUSHING
BSD-3600521000.A8
3600521000
|
-
|
|
|
|
60 - STRAINER
BSD-3600002000.A355
3600002000
|
£3.72
|
£4.47
|
|
|
61 - PLAIN WASHER
BSD-3600101003.A5
3600101003
|
-
|
|
|
|
62 - SUSPENSION LOOP
BSD-2604720004.A95
2604720004
|
£4.26
|
£5.11
|
|
|
63 - STRAIGHT PIN 128 MM
BSD-3604710004.A6
3604710004
|
-
|
|
|
|
64 - UNLOADING VALVE
BSD-3603201021.A6
3603201021
|
-
|
|
|
|
65 - STRAIGHT PIN 3 H 8x6 DIN 7
BSD-2917500074.A15
2917500074
|
-
|
|
|
|
66 - STRAIGHT PIN
BSD-3604710000.A64
3604710000
|
£5.58
|
£6.70
|
|
|
67 - GUIDE BUSHING
BSD-3600320000.A2
3600320000
|
-
|
|
|
|
69 - COMPRESSION SPRING
BSD-3604643002.A44
3604643002
|
£2.80
|
£3.36
|
|
|
70 - ASSEMBLY OF SERVICE PARTS
BSD-3607031094.A2
3607031094
|
-
|
|
|
|
71 - CONTROL PISTON
BSD-3608750000.A6
3608750000
|
-
|
|
|
|
72 - SLOTTED SPRING PIN 2x12 DIN 1481
BSD-2917760037.A10
2917760037
|
-
|
|
|
|
73 - PUSH-BUTTON
BSD-3603122000.A10
3603122000
|
-
|
|
|
|
74 - COMPRESSION SPRING
BSD-3604611002.A40
3604611002
|
£2.80
|
£3.36
|
|
|
90 - SILENCER
BSD-3603462000.A33
3603462000
|
£16.41
|
£19.69
|
|
|
95 - NAMEPLATE
BSD-160111A3HF.A312
160111A3HF
|
£3.72
|
£4.47
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A65
1601110481
|
£2.16
|
£2.59
|
|
|
97 - GROOVED NAIL
BSD-3603133000.A80
3603133000
|
£2.61
|
£3.13
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1986
3601119236
|
£3.72
|
£4.47
|
|
|
100 - HOUSING
BSD-3605125019.A20
3605125019
|
-
|
|
|
|
101 - CLUTCH ELEMENT
BSD-3606445031.A7
3606445031
|
£218.41
|
£262.09
|
|
|
103 - DRIVE SHAFT
BSD-3606122013.A43
3606122013
|
£81.81
|
£98.17
|
|
|
106 - COMPRESSION SPRING
BSD-3604615001.A54
3604615001
|
£2.61
|
£3.13
|
|
|
109 - COMPRESSION SPRING dia 3.5 MM
BSD-3604619005.A16
3604619005
|
£7.36
|
£8.83
|
|
|
110 - RETAINING RING
BSD-3604601001.A129
3604601001
|
£2.16
|
£2.59
|
|
|
111 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A174
1903230007
|
£1.75
|
£2.10
|
|
|
112 - CLAMPING SLEEVE
BSD-3600311015.A21
3600311015
|
£31.64
|
£37.97
|
|
|
114 - BUSHING
BSD-3600202003.A13
3600202003
|
-
|
|
|
|
115 - SEALING PLATE
BSD-3600001000.A24
3600001000
|
£2.80
|
£3.36
|
|
|
116 - ADJUSTING DISC
BSD-3600134000.A8
3600134000
|
£2.80
|
£3.36
|
|
|
120 - ROUND NUT
BSD-3603301004.A30
3603301004
|
£21.68
|
£26.01
|
|
|
122 - ROLLER THRUST BEARING
BSD-3600921000.A88
3600921000
|
£6.52
|
£7.83
|
|
|
123 - SUPPORT DISC
BSD-3600103004.A59
3600103004
|
£13.12
|
£15.75
|
|
|
124 - SUPPORT DISC
BSD-3600101002.A141
3600101002
|
£2.16
|
£2.59
|
|
|
125 - RETAINING RING
BSD-3600224001.A7
3600224001
|
£3.72
|
£4.47
|
|
|
127 - BALL DIN 5401-5 G28
BSD-1903230009.A193
1903230009
|
£1.75
|
£2.10
|
|
|
128 - BALL DIN 5401-6 G28
BSD-1903230011.A118
1903230011
|
£2.61
|
£3.13
|
|
|
134 - PLAIN WASHER
BSD-3600101055.A39
3600101055
|
£12.04
|
£14.45
|
|
|
140 - RETAINING RING 14 DIN 9045
BSD-2916600008.A95
2916600008
|
£2.80
|
£3.36
|
|
|
652 - HOSE FITTING
BSD-2603386002.A166
2603386002
|
£5.30
|
£6.36
|
|
|
657 - ANGLE PIECE
BSD-3601329007.A3
3601329007
|
£4.26
|
£5.11
|
|
|
703 - HOSE FITTING dia 8 MM
BSD-3603386001.A150
3603386001
|
£16.41
|
£19.69
|
|
|
704 - SUPPORT CLAMP
BSD-3608040000.A32
3608040000
|
-
|
|
|
|
705 - AUXILIARY HANDLE M14
BSD-1602025022.A992
1602025022
|
£13.41
|
£16.09
|
|
|
705 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A342
1602025030
|
£18.96
|
£22.75
|
|
|
705 - HANDLE
BSD-3600499000.A25
3600499000
|
-
|
|
|
|
706 - SILENCER
BSD-3607000073.A215
3607000073
|
£18.96
|
£22.75
|
|
|
707 - OFFSET SCREWDRIVER DIN 911 SW10
BSD-1907950009.A35
1907950009
|
£21.68
|
£26.01
|
|
|
708 - SINGLE-HEAD ENG. WRENCH DIN 894 SW24
BSD-1907950513.A135
1907950513
|
£16.41
|
£19.69
|
|
|
713 - HEXAGON-SOCKET KEY
BSD-3607950001.A201
3607950001
|
£2.80
|
£3.36
|
|
|
801 - ASSEMBLY OF SERVICE PARTS
BSD-3607031108.A0
3607031108
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031018.A9
3607031018
|
£410.78
|
£492.94
|
|
|
804 - ASSEMBLY OF SERVICE PARTS
BSD-3607030248.A132
3607030248
|
£31.64
|
£37.97
|
|
|
855 - O-RING 10x2 MM
BSD-1900210306.A141
1900210306
|
£1.75
|
£2.10
|
|
|
856 - ASSEMBLY OF SERVICE PARTS
BSD-3607031011.A2
3607031011
|
-
|
|
|
