1 - MOTOR HOUSING
BSD-3605102056.A5
3605102056
|
£306.65
|
£367.98
|
|
|
2 - SEAL RING
BSD-1600209009.A67
1600209009
|
£6.52
|
£7.83
|
|
|
3 - STATOR 120V/200HZ
BSD-1604229210.A0
1604229210
|
-
|
|
|
|
4 - GROMMET
BSD-1600306000.A5
1600306000
|
£1.95
|
£2.34
|
|
|
5 - PROTECTIVE COVER
BSD-1600502004.A77
1600502004
|
£4.26
|
£5.11
|
|
|
6 - SET SCREW
BSD-1603402004.A148
1603402004
|
£2.61
|
£3.13
|
|
|
8 - ROTOR WITHOUT WINDING
BSD-1604081013.A6
1604081013
|
£251.67
|
£302.00
|
|
|
9 - BEARING COVER
BSD-3600134004.A9
3600134004
|
£14.91
|
£17.89
|
|
|
10 - GROOVE BALL BEARING
BSD-3600905016.A6
3600905016
|
£18.96
|
£22.75
|
|
|
11 - BEARING COVER
BSD-3605808007.A7
3605808007
|
£179.37
|
£215.24
|
|
|
12 - SEAL RING
BSD-1600209012.A1
1600209012
|
-
|
|
|
|
13 - WOODRUFF KEY DIN6888-3x6.5-ST60-2K
BSD-1900023007.A19
1900023007
|
-
|
|
|
|
14 - FAN
BSD-1606610056.A5
1606610056
|
£63.50
|
£76.20
|
|
|
15 - INTERMEDIATE RING
BSD-1600341000.A4
1600341000
|
-
|
|
|
|
16 - GROOVE BALL BEARING 12x28x8
BSD-1900900287.A119
1900900287
|
£21.68
|
£26.01
|
|
|
17 - RETAINING RING 12 DIN 9045
BSD-2916600007.A157
2916600007
|
£2.80
|
£3.36
|
|
|
18 - RUBBER RING
BSD-1600206015.A45
1600206015
|
£2.16
|
£2.59
|
|
|
19 - HANDLE
BSD-3605132035.A64
3605132035
|
£40.80
|
£48.96
|
|
|
20 - SEAL
BSD-1601015011.A97
1601015011
|
£3.80
|
£4.56
|
|
|
21 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A534
1600703009
|
£5.58
|
£6.70
|
|
|
23 - SEALING PLATE
BSD-1600113003.A130
1600113003
|
£2.80
|
£3.36
|
|
|
24 - ON-OFF SWITCH
BSD-1607200017.A25
1607200017
|
£102.57
|
£123.08
|
|
|
25 - FASTENING CLAMP
BSD-1601303003.A337
1601303003
|
£2.16
|
£2.59
|
|
|
26 - CONTROL LEVER
BSD-1602026038.A155
1602026038
|
£5.30
|
£6.36
|
|
|
27 - SEALING DISK dia18xdia10x4 MM
BSD-1600108024.A9
1600108024
|
£1.75
|
£2.10
|
|
|
30 - NAMEPLATE
BSD-3601106053.A416
3601106053
|
£5.30
|
£6.36
|
|
|
31 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A389
3603133001
|
£2.61
|
£3.13
|
|
|
32 - SPRING LOCK WASHER DIN 127-B12
BSD-2916680011.A23
2916680011
|
-
|
|
|
|
33 - LIFTING EYE BOLT DIN 580-M 8
BSD-2912521237.A3
2912521237
|
£11.78
|
£14.13
|
|
|
34 - AUXILIARY HANDLE M14
BSD-1602025022.A14
1602025022
|
£13.41
|
£16.09
|
|
|
34 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A658
1602025030
|
£18.96
|
£22.75
|
|
|
35 - CLAMPING SADDLE
BSD-3601321001.A390
3601321001
|
£3.72
|
£4.47
|
|
|
36 - SPRING WASHER dia4.2 MM
BSD-3600150006.A671
3600150006
|
£2.61
|
£3.13
|
|
|
37 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A55
2910110120
|
£1.75
|
£2.10
|
|
|
38 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1386
2910021118
|
£1.75
|
£2.10
|
|
|
39 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A259
2910021125
|
£1.75
|
£2.10
|
|
|
40 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x20-8.8
BSD-2910141201.A33
2910141201
|
£2.61
|
£3.13
|
|
|
41 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x40-8.8
BSD-2910141209.A74
2910141209
|
£2.61
|
£3.13
|
|
|
42 - MANUFACTURER'S NAMEPLATE
BSD-3601110104.A7
3601110104
|
£5.01
|
£6.01
|
|
|
43 - END SPLICE
BSD-3604477008.A81
3604477008
|
£1.75
|
£2.10
|
|
|
44 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1385
2910021118
|
£1.75
|
£2.10
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1027
3601119236
|
£3.72
|
£4.47
|
|
|
651 - SINGLE-HEAD ENG. WRENCH DIN 894 SW24
BSD-1907950513.A96
1907950513
|
£16.41
|
£19.69
|
|
|
652 - SINGLE-HEAD ENG. WRENCH SW 14
BSD-1907950508.A115
1907950508
|
£14.91
|
£17.89
|
|
|
700 - CLAMPING FLANGE
BSD-3605703052.A1
3605703052
|
-
|
|
|
|
701 - ROUND NUT
BSD-3605703053.A7
3605703053
|
-
|
|
|
|
752 - ON-OFF SWITCH
BSD-1607200006.A144
1607200006
|
£81.81
|
£98.17
|
|
|
752/1 - SOCKET HEAD CAP SCREW DIN 84-AM3x10-4.8
BSD-2910001052.A100
2910001052
|
£2.16
|
£2.59
|
|
|
752/2 - EXTENSION SPRING
BSD-1604650009.A67
1604650009
|
£1.75
|
£2.10
|
|
|
752/4 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A398
2910091118
|
£1.75
|
£2.10
|
|
|
752/7 - DETENT ROLLER
BSD-1603200007.A71
1603200007
|
-
|
|
|
|
753 - FIXING PLATE
BSD-3601023015.A210
3601023015
|
£21.68
|
£26.01
|
|
|
754 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A341
2916690003
|
£1.75
|
£2.10
|
|
|
755 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1384
2910021118
|
£1.75
|
£2.10
|
|
