3 - ROTOR WITHOUT WINDING
BSD-1614081030.A6
1614081030
|
£187.56
|
£225.07
|
|
|
4 - BEARING FLANGE
BSD-1615808089.A1
1615808089
|
£156.22
|
£187.46
|
|
|
5 - GROOVE BALL BEARING 15x35x11
BSD-1610900028.A0
1610900028
|
£19.45
|
£23.34
|
|
|
6 - SUPPORTING DISC DIN 988-S25x35x2
BSD-2916280021.A11
2916280021
|
£1.32
|
£1.58
|
|
|
7 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A59
2916660014
|
£1.75
|
£2.10
|
|
|
8 - FAN
BSD-1616610028.A12
1616610028
|
£51.22
|
£61.47
|
|
|
9 - HEX NUT DIN 985-M12X1
BSD-1613313000.A15
1613313000
|
£2.80
|
£3.36
|
|
|
11 - FELT WASHER
BSD-1610108009.A12
1610108009
|
-
|
|
|
|
12 - SUPPORTING DISC 2.5 MM
BSD-1610103004.A0
1610103004
|
-
|
|
|
|
13 - NEEDLE-ROLLER BEARING
BSD-1610910093.A1
1610910093
|
£37.27
|
£44.72
|
|
|
15 - NEEDLE-ROLLER BEARING D35xD47x17
BSD-1610910091.A6
1610910091
|
£33.74
|
£40.49
|
|
|
19 - ECCENTRIC SHAFT
BSD-1616110033.A1
1616110033
|
£149.42
|
£179.31
|
|
|
21 - CYLINDRICAL GEAR Z=46
BSD-1616318011.A1
1616318011
|
£120.11
|
£144.13
|
|
|
22 - CYLINDRICAL GEAR Z=50/18
BSD-1616328040.A1
1616328040
|
-
|
|
|
|
23 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913005.A13
1610913005
|
£8.67
|
£10.41
|
|
|
24 - GEAR COVER
BSD-1615500329.A0
1615500329
|
£179.37
|
£215.24
|
|
|
25 - CONNECTING ROD
BSD-1612001040.A13
1612001040
|
£72.18
|
£86.62
|
|
|
26 - NEEDLE-ROLLER BEARING D25xD37x17
BSD-1610910092.A17
1610910092
|
£31.64
|
£37.97
|
|
|
27 - O-RING 36.0x5.0 MM
BSD-1610210033.A12
1610210033
|
£2.61
|
£3.13
|
|
|
28 - HAMMER PISTON
BSD-1618700043.A1
1618700043
|
£357.27
|
£428.72
|
|
|
30 - RETAINING RING dia54.2xdia2.8
BSD-1614601039.A13
1614601039
|
£2.16
|
£2.59
|
|
|
32 - O-RING 60x4 MM
BSD-1900210156.A4
1900210156
|
£8.67
|
£10.41
|
|
|
33 - PISTON PIN
BSD-3613101500.A0
3613101500
|
£7.36
|
£8.83
|
|
|
34 - STRIKER
BSD-1618710039.A13
1618710039
|
£63.50
|
£76.20
|
|
|
35 - SEAL RING
BSD-1610209007.A5
1610209007
|
£8.67
|
£10.41
|
|
|
36 - O-RING 80x3 MM
BSD-1900210166.A25
1900210166
|
£5.30
|
£6.36
|
|
|
37 - GUIDE TUBE
BSD-1615806053.A1
1615806053
|
£438.57
|
£526.28
|
|
|
38 - GUIDE BUSHING
BSD-1610220009.A13
1610220009
|
£21.68
|
£26.01
|
|
|
39 - COMPRESSION SPRING
BSD-1614619005.A12
1614619005
|
£6.52
|
£7.83
|
|
|
40 - INTERMEDIATE FLANGE
BSD-1615700017.A12
1615700017
|
£135.25
|
£162.30
|
|
|
41 - O-RING 17.3x17.7 MM
BSD-1610210008.A4
1610210008
|
£5.58
|
£6.70
|
|
|
42 - STRIKER PIN
BSD-1613123003.A13
1613123003
|
£120.11
|
£144.13
|
|
|
44 - RETAINING BRACKET
BSD-1618045026.A33
1618045026
|
£179.37
|
£215.24
|
|
|
45 - LOCKING BOLT
BSD-1613103004.A11
1613103004
|
£54.42
|
£65.30
|
|
|
46 - SLOTTED SPRING PIN 8x55 DIN 1481
BSD-2917760187.A11
2917760187
|
£2.80
|
£3.36
|
|
|
47 - O-RING 100x3 MM
BSD-1900210172.A12
1900210172
|
£10.10
|
£12.12
|
|
|
48 - SEALING CAP
BSD-1610516007.A16
1610516007
|
£14.75
|
£17.70
|
|
|
50 - PROTECTION SLEEVE
BSD-3600421500.A17
3600421500
|
£2.61
|
£3.13
|
|
|
51 - CORD GUARD
BSD-1610703019.A1
1610703019
|
£4.75
|
£5.70
|
|
|
52 - FAN COVER
BSD-1615500328.A1
1615500328
|
£218.41
|
£262.09
|
|
|
53 - COVERING HOOD
BSD-1600A00C0N.A0
1600A00C0N
|
£72.18
|
£86.62
|
|
|
55 - POWER SUPPLY CORD 5m 4 x 1.5mm H07RN-F
BSD-1614462074.A1
1614462074
|
£102.57
|
£123.08
|
|
|
56 - GROMMET
BSD-1610703011.A33
1610703011
|
£14.91
|
£17.89
|
|
|
57 - SWITCH COVER
BSD-1615500212.A13
1615500212
|
£11.30
|
£13.56
|
|
|
58 - SWITCH
BSD-1617200108.A16
1617200108
|
£59.53
|
£71.44
|
|
|
59 - INTERMEDIATE PLATE
BSD-1615700041.A12
1615700041
|
£93.88
|
£112.65
|
|
|
62 - SWITCH-PAWL
BSD-1612026011.A4
1612026011
|
£6.52
|
£7.83
|
|
|
63 - HANDLE
BSD-1615132010.A12
1615132010
|
£37.27
|
£44.72
|
|
|
64 - RUBBER TORSION-BAR
BSD-1616334000.A20
1616334000
|
£27.23
|
£32.68
|
|
|
65 - TOOTHED SHAFT
BSD-1613060005.A15
1613060005
|
£54.42
|
£65.30
|
|
|
67 - SPRING RETAINING RING DIN 472 52x2MM
BSD-2916660023.A57
2916660023
|
£5.30
|
£6.36
|
|
|
68 - RUBBER BUFFER
BSD-1613465001.A13
1613465001
|
£5.58
|
£6.70
|
|
|
69 - INTERMEDIATE PLATE
BSD-1615700042.A10
1615700042
|
£103.14
|
£123.77
|
|
|
70 - HANDLE
BSD-1615132011.A0
1615132011
|
£37.27
|
£44.72
|
|
|
71 - NAMEPLATE
BSD-1611104002.A5
1611104002
|
£1.32
|
£1.58
|
|
|
74 - DISC SPRING DIN 2093-A25X12.2X1.5
BSD-2916160009.A13
2916160009
|
£3.72
|
£4.47
|
|
|
75 - COMPRESSION SPRING
BSD-3614640501.A0
3614640501
|
£10.10
|
£12.12
|
|
|
76 - FASTENING CLAMP
BSD-1611302012.A1
1611302012
|
-
|
|
|
|
86 - BEARING BOLT
BSD-1610300033.A2
1610300033
|
£21.52
|
£25.83
|
|
|
87 - GROOVE BALL BEARING 25x52x15
BSD-1610900027.A11
1610900027
|
£27.23
|
£32.68
|
|
|
88 - ROTARY SHAFT LIP SEAL
BSD-1610283016.A6
1610283016
|
£10.10
|
£12.12
|
|
|
90 - SPRING LOCK WASHER
BSD-1610151007.A1
1610151007
|
£1.75
|
£2.10
|
|
|
94 - SEALING PLATE
BSD-1611015021.A24
1611015021
|
£2.80
|
£3.36
|
|
|
95 - CONNECTING CABLE
BSD-1614441000.A1
1614441000
|
-
|
|
|
|
97 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A339
2915011007
|
-
|
|
|
|
99 - HEX NUT DIN 985-10-M10x1
BSD-3613313500.A1
3613313500
|
£2.80
|
£3.36
|
|
|
102 - TAPPING SCREW DIN 7971-BZ4.2x13
BSD-2910211025.A75
2910211025
|
£1.75
|
£2.10
|
|
|
103 - OVAL-HEAD SCREW DIN 7985-M4x25-8.8
BSD-2910951132.A71
2910951132
|
-
|
|
|
|
104 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x20-8.8
BSD-2910141201.A203
2910141201
|
£2.61
|
£3.13
|
|
|
105 - MICROENCAPSULATED SCREW DIN 912-M6X30-8.8
BSD-2914551188.A10
2914551188
|
£2.80
|
£3.36
|
|
|
106 - MICROENCAPSULATED SCREW DIN 912-M6X55-8.8
BSD-2914551189.A1
2914551189
|
£1.75
|
£2.10
|
|
|
107 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x20-8.8
BSD-2910141242.A108
2910141242
|
£1.75
|
£2.10
|
|
|
108 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A182
2603490023
|
£1.75
|
£2.10
|
|
|
109 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x35-8.8
BSD-2910141248.A26
2910141248
|
£1.75
|
£2.10
|
|
|
110 - HEX SOCKET HEAD CAP SCREW DIN-M12x70-8.8
BSD-2910141356.A0
2910141356
|
£2.61
|
£3.13
|
|
|
111 - MICROENCAPSULATED SCREW DIN EN-24014-M12x110-12.9
BSD-2914550034.A1
2914550034
|
£3.72
|
£4.47
|
|
|
112 - TAPPING SCREW DIN 7971-ST4.8x25-C
BSD-2910211236.A1
2910211236
|
£1.75
|
£2.10
|
|
|
114 - ROUND-HEAD GROOVED PIN 2x6 DIN 1476-ST
BSD-2917721034.A60
2917721034
|
£1.75
|
£2.10
|
|
|
117 - PLAIN WASHER DIN 433-A13-ST 50
BSD-2916011019.A20
2916011019
|
£2.16
|
£2.59
|
|
|
135 - REFERENCE PLATE
BSD-3611119512.A1
3611119512
|
-
|
|
|
|
801 - MOTOR HOUSING
BSD-1617000856.A0
1617000856
|
£1111.70
|
£1334.04
|
|
|
802 - STATOR 115V/200HZ
BSD-1614229127.A0
1614229127
|
-
|
|
|
|
810 - SET SCREW M 8x16 DIN 417-5.8
BSD-2912051238.A2
2912051238
|
-
|
|
|
|
820 - NEEDLE-ROLLER BEARING D25xD37x17
BSD-1610910094.A0
1610910094
|
£27.31
|
£32.77
|
|
|
843 - TOOLHOLDER
BSD-1617000428.A13
1617000428
|
£458.51
|
£550.21
|
|
|
854 - SWITCH HOUSING
BSD-1617000891.A1
1617000891
|
£37.27
|
£44.72
|
|
|
858 - PROTECTIVE CAP
BSD-1610591001.A12
1610591001
|
£21.52
|
£25.83
|
|
|
859 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A153
2910091118
|
£1.75
|
£2.10
|
|
|
861 - FIXING PLATE
BSD-1617000429.A0
1617000429
|
£12.04
|
£14.45
|
|
|
885 - GREASE 1000 ML
BSD-1615430007.A12
1615430007
|
£68.42
|
£82.10
|
|
|
887 - WEAR AND TEAR PART SET
BSD-1617000444.A2
1617000444
|
£21.68
|
£26.01
|
|
|
888 - GREASE TUBE 225 ML
BSD-1615430001.A42
1615430001
|
£23.86
|
£28.63
|
|
|
889 - CLAMPING SADDLE
BSD-1617000156.A3
1617000156
|
£2.80
|
£3.36
|
|
|
8903 - ROTOR WITHOUT WINDING
BSD-1617000440.A0
1617000440
|
-
|
|
|
|
8913 - NEEDLE-ROLLER BEARING
BSD-1617000443.A0
1617000443
|
-
|
|
|
|
8914 - INNER RING
BSD-1610300066.A1
1610300066
|
-
|
|
|
|
8915 - NEEDLE-ROLLER BEARING
BSD-1617000441.A1
1617000441
|
£93.88
|
£112.65
|
|
|
8916 - SHIM WASHER 4.0 MM
BSD-1610102019.A1
1610102019
|
£3.72
|
£4.47
|
|
|
8918 - INNER RING
BSD-1610400036.A0
1610400036
|
-
|
|
|
|
8919 - ECCENTRIC SHAFT
BSD-1616110027.A7
1616110027
|
£167.68
|
£201.22
|
|
|
8926 - NEEDLE-ROLLER BEARING D20xD37x17
BSD-1610910035.A9
1610910035
|
£23.86
|
£28.63
|
|
|
8987 - WEAR AND TEAR PART SET
BSD-1617000444.A3
1617000444
|
£21.68
|
£26.01
|
|
|
8988 - GREASE TUBE 225 ML
BSD-1615430001.A43
1615430001
|
£23.86
|
£28.63
|
|
