1 - MOTOR HOUSING
BSD-1605102106.A42
1605102106
|
-
|
|
|
|
2 - STATOR 200V/300HZ
BSD-1604229161.A27
1604229161
|
-
|
|
|
|
4 - SEAL
BSD-1601015011.A69
1601015011
|
£3.80
|
£4.56
|
|
|
5 - GEAR HOUSING
BSD-1605806159.A7
1605806159
|
-
|
|
|
|
6 - BEARING FLANGE
BSD-1605805022.A41
1605805022
|
-
|
|
|
|
7 - CONICAL SPRING WASHER
BSD-1600521013.A54
1600521013
|
-
|
|
|
|
8 - ON-OFF SWITCH
BSD-1607200017.A8
1607200017
|
£102.57
|
£123.08
|
|
|
9 - CONTROL LEVER
BSD-1602026038.A77
1602026038
|
£5.30
|
£6.36
|
|
|
11 - GRINDING SPINDLE M14
BSD-1603523029.A6
1603523029
|
-
|
|
|
|
12 - GUIDE PULLEY
BSD-1600500014.A66
1600500014
|
-
|
|
|
|
13 - ELEC. CABLE W/CONNECTION
BSD-3604462043.A42
3604462043
|
£54.42
|
£65.30
|
|
|
15 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A432
1600703009
|
£5.58
|
£6.70
|
|
|
16 - FASTENING CLAMP
BSD-1601303003.A216
1601303003
|
£2.16
|
£2.59
|
|
|
17 - SEALING PLATE
BSD-1600113003.A87
1600113003
|
£2.80
|
£3.36
|
|
|
18 - SEAL RING
BSD-1600209009.A126
1600209009
|
£6.52
|
£7.83
|
|
|
19 - O-RING 45x3MM
BSD-1900210146.A62
1900210146
|
£4.26
|
£5.11
|
|
|
20 - SEALING DISK
BSD-1600108048.A3
1600108048
|
£1.75
|
£2.10
|
|
|
21 - PLAIN WASHER
BSD-2100551000.A55
2100551000
|
-
|
|
|
|
22 - SHIM 0.1 MM
BSD-1600101616.A141
1600101616
|
£2.61
|
£3.13
|
|
|
22 - SHIM 0.2 MM
BSD-1600101617.A55
1600101617
|
£1.75
|
£2.10
|
|
|
22 - SHIM 0.3 MM
BSD-1600101618.A197
1600101618
|
£2.61
|
£3.13
|
|
|
22 - SHIM 0.05 MM
BSD-1600101619.A55
1600101619
|
£2.16
|
£2.59
|
|
|
23 - SHIM 0.05 MM
BSD-1600102638.A111
1600102638
|
£3.34
|
£4.01
|
|
|
23 - SHIM 0.1 MM
BSD-1600102639.A123
1600102639
|
-
|
|
|
|
23 - SHIM 0.15 MM
BSD-1600102640.A111
1600102640
|
-
|
|
|
|
24 - NAMEPLATE
BSD-3601106053.A259
3601106053
|
£5.30
|
£6.36
|
|
|
26 - O-RING
BSD-1120210000.A38
1120210000
|
-
|
|
|
|
27 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A90
1600910010
|
£45.67
|
£54.80
|
|
|
28 - GROOVE BALL BEARING 17x47x14
BSD-1900900352.A289
1900900352
|
£27.23
|
£32.68
|
|
|
29 - SET SCREW
BSD-1603402004.A84
1603402004
|
£2.61
|
£3.13
|
|
|
30 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1893
2910021118
|
£1.75
|
£2.10
|
|
|
31 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x50-8.8
BSD-2910141213.A1
2910141213
|
£2.61
|
£3.13
|
|
|
32 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x40-8.8
BSD-2910141209.A60
2910141209
|
£2.61
|
£3.13
|
|
|
33 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x25-8.8
BSD-2910141164.A93
2910141164
|
£2.16
|
£2.59
|
|
|
34 - HEX SOCKET HEAD CAP SCREW DIN 912-M5X16-8.8
BSD-2910141158.A66
2910141158
|
£1.75
|
£2.10
|
|
|
35 - RETAINING RING dia22 MM
BSD-2916620011.A203
2916620011
|
£1.75
|
£2.10
|
|
|
36 - SPRING WASHER DIN 137-A4
BSD-1600150006.A64
1600150006
|
-
|
|
|
|
37 - CLAMPING SADDLE
BSD-3601321001.A591
3601321001
|
£3.72
|
£4.47
|
|
|
38 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A599
3603133001
|
£2.61
|
£3.13
|
|
|
39 - PAN HEAD SCREW DIN 85-MS-M 4x12
BSD-2910110122.A137
2910110122
|
£1.75
|
£2.10
|
|
|
40 - O-RING 74.0x3.0 MM
BSD-1600210006.A102
1600210006
|
£1.75
|
£2.10
|
|
|
41 - FELT WASHER
BSD-1600205027.A56
1600205027
|
£1.75
|
£2.10
|
|
|
42 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1894
2910021118
|
£1.75
|
£2.10
|
|
|
43 - GROMMET
BSD-1600306000.A31
1600306000
|
£1.95
|
£2.34
|
|
|
44 - PROTECTIVE COVER
BSD-1600502004.A9
1600502004
|
£4.26
|
£5.11
|
|
|
45 - SEAL
BSD-1601015011.A68
1601015011
|
£3.80
|
£4.56
|
|
|
57 - BEARING HOUSING
BSD-1605820145.A2
1605820145
|
-
|
|
|
|
58 - BEARING COVER
BSD-1600501019.A424
1600501019
|
£23.86
|
£28.63
|
|
|
59 - COVER DISC
BSD-1600501024.A70
1600501024
|
£16.41
|
£19.69
|
|
|
60 - FELT DISC
BSD-1600108018.A76
1600108018
|
£2.61
|
£3.13
|
|
|
61 - GROOVE BALL BEARING
BSD-3600900022.A43
3600900022
|
£21.68
|
£26.01
|
|
|
62 - GROOVE BALL BEARING 12x28x8
BSD-1900905121.A312
1900905121
|
£18.96
|
£22.75
|
|
|
63 - TORX FLAT-HEAD SCREW M4x20
BSD-3603435051.A72
3603435051
|
£1.75
|
£2.10
|
|
|
64 - RETAINING RING 12 DIN 9045
BSD-2916600007.A93
2916600007
|
£2.80
|
£3.36
|
|
|
65 - BEVEL GEAR Z=27
BSD-1606333048.A19
1606333048
|
-
|
|
|
|
66 - BEVEL GEAR Z=38
BSD-1606333049.A1
1606333049
|
-
|
|
|
|
67 - HEX NUT M12x1.5 MM
BSD-1603300009.A108
1603300009
|
£1.75
|
£2.10
|
|
|
70 - REFERENCE PLATE
BSD-3601119236.A1584
3601119236
|
£3.72
|
£4.47
|
|
|
651 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A518
1907950007
|
£5.30
|
£6.36
|
|
|
652 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A438
1607950061
|
£5.42
|
£6.50
|
|
|
653 - AUXILIARY HANDLE M14
BSD-1602025022.A727
1602025022
|
£13.41
|
£16.09
|
|
|
653 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A254
1602025030
|
£18.96
|
£22.75
|
|
|
654 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A456
2607950511
|
£4.26
|
£5.11
|
|
|
655 - PROTECTIVE COVER dia180 MM
BSD-1605510199.A185
1605510199
|
-
|
|
|
|
656 - CLAMPING-FLANGE dia45 MM
BSD-2600501006.A366
2600501006
|
£16.43
|
£19.72
|
|
|
657 - ROUND NUT M14
BSD-2603345004.A317
2603345004
|
£6.52
|
£7.83
|
|
|
752 - ON-OFF SWITCH
BSD-1607200006.A131
1607200006
|
£81.81
|
£98.17
|
|
|
752/1 - SOCKET HEAD CAP SCREW DIN 84-AM3x10-4.8
BSD-2910001052.A60
2910001052
|
£2.16
|
£2.59
|
|
|
752/2 - EXTENSION SPRING
BSD-1604650009.A6
1604650009
|
£1.75
|
£2.10
|
|
|
752/3 - COMPRESSION SPRING
BSD-1604617001.A9
1604617001
|
£2.80
|
£3.36
|
|
|
752/4 - PAN HEAD SCREW DIN 85-AM4x8-4.8
BSD-2910091118.A335
2910091118
|
£1.75
|
£2.10
|
|
|
752/6 - LOCKING WASHER DIN 6799-2.3
BSD-2916080005.A274
2916080005
|
-
|
|
|
|
752/7 - DETENT ROLLER
BSD-1603200007.A59
1603200007
|
-
|
|
|
|
753 - FIXING PLATE
BSD-3601023015.A131
3601023015
|
£21.68
|
£26.01
|
|
|
754 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A536
2916690003
|
£1.75
|
£2.10
|
|
|
755 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1897
2910021118
|
£1.75
|
£2.10
|
|
|
800 - HANDLE
BSD-1605132067.A124
1605132067
|
-
|
|
|
|
802 - ASSEMBLY OF SERVICE PARTS
BSD-3607031146.A0
3607031146
|
-
|
|
|
