2 - STATOR 220V/360HZ
BSD-1604229105.A0
1604229105
|
-
|
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209002.A146
1600209002
|
£5.30
|
£6.36
|
|
|
6 - GRINDING SPINDLE
BSD-3603523032.A20
3603523032
|
£54.42
|
£65.30
|
|
|
7 - SEAL RING
BSD-1600290020.A248
1600290020
|
£1.75
|
£2.10
|
|
|
10 - O-RING 45x3MM
BSD-1900210146.A20
1900210146
|
£4.26
|
£5.11
|
|
|
15 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A361
1600703009
|
£5.58
|
£6.70
|
|
|
19 - CONTROL LEVER
BSD-1602026030.A264
1602026030
|
£10.10
|
£12.12
|
|
|
19/1 - FELT WASHER
BSD-1600205008.A90
1600205008
|
£1.75
|
£2.10
|
|
|
22 - NAMEPLATE
BSD-3601106053.A93
3601106053
|
£5.30
|
£6.36
|
|
|
25 - FASTENING CLAMP
BSD-1601303003.A223
1601303003
|
£2.16
|
£2.59
|
|
|
26 - O-RING 66.0x3.0 MM
BSD-1600210005.A196
1600210005
|
£2.80
|
£3.36
|
|
|
27 - SHIM
BSD-3600100075.A16
3600100075
|
£11.30
|
£13.56
|
|
|
27 - SHIM
BSD-3600100076.A32
3600100076
|
£11.30
|
£13.56
|
|
|
27 - SHIM
BSD-3600100077.A16
3600100077
|
£12.04
|
£14.45
|
|
|
28 - SPRING RETAINING RING
BSD-3603435038.A8
3603435038
|
£2.61
|
£3.13
|
|
|
29 - SEALING PLATE
BSD-1600113003.A63
1600113003
|
£2.80
|
£3.36
|
|
|
30 - SEALING DISK
BSD-1600108055.A263
1600108055
|
£1.75
|
£2.10
|
|
|
32 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A216
2910110120
|
£1.75
|
£2.10
|
|
|
33 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A68
1600910010
|
£45.67
|
£54.80
|
|
|
34 - GROOVE BALL BEARING
BSD-3600905138.A5
3600905138
|
-
|
|
|
|
35 - RETAINING RING dia22 MM
BSD-2916620011.A176
2916620011
|
£1.75
|
£2.10
|
|
|
36 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x25-8.8
BSD-2910141164.A82
2910141164
|
£2.16
|
£2.59
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x20-8.8
BSD-2910141162.A55
2910141162
|
£2.16
|
£2.59
|
|
|
38 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A109
2910141166
|
£1.75
|
£2.10
|
|
|
39 - SOCKET HEAD CAP SCREW
BSD-3603450008.A97
3603450008
|
£2.16
|
£2.59
|
|
|
40 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A477
2910211006
|
£1.75
|
£2.10
|
|
|
41 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1855
2910021118
|
£1.75
|
£2.10
|
|
|
42 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A747
2916011005
|
£1.75
|
£2.10
|
|
|
43 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-8.8
BSD-2910021120.A19
2910021120
|
£1.75
|
£2.10
|
|
|
44 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A215
2910110120
|
£1.75
|
£2.10
|
|
|
45 - CLAMPING SADDLE
BSD-3601321001.A737
3601321001
|
£3.72
|
£4.47
|
|
|
46 - THREAD-FORMING TAP. SCREW
BSD-3603435004.A43
3603435004
|
£2.80
|
£3.36
|
|
|
47 - SPRING WASHER dia4.2 MM
BSD-3600150006.A513
3600150006
|
£2.61
|
£3.13
|
|
|
48 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A644
3603133001
|
£2.61
|
£3.13
|
|
|
51 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A746
2916011005
|
£1.75
|
£2.10
|
|
|
55 - BEVEL GEAR Z=48
BSD-1606333087.A14
1606333087
|
£135.25
|
£162.30
|
|
|
60 - SEALING CORD
BSD-1601014000.A234
1601014000
|
£2.80
|
£3.36
|
|
|
67 - SEALING PLATE
BSD-1602388006.A1
1602388006
|
£5.58
|
£6.70
|
|
|
68 - GROMMET
BSD-1600306001.A171
1600306001
|
£2.61
|
£3.13
|
|
|
71 - ROTOR WITHOUT WINDING
BSD-1604080036.A8
1604080036
|
£357.27
|
£428.72
|
|
|
72 - BEARING COVER
BSD-1600501019.A388
1600501019
|
£23.86
|
£28.63
|
|
|
73 - BEARING FLANGE
BSD-3605820064.A26
3605820064
|
£68.42
|
£82.10
|
|
|
74 - GROOVE BALL BEARING
BSD-3600905095.A80
3600905095
|
£21.52
|
£25.83
|
|
|
75 - TORX FLAT-HEAD SCREW M4x20
BSD-3603435051.A30
3603435051
|
£1.75
|
£2.10
|
|
|
76 - GROOVE BALL BEARING 7x22x7
BSD-3600905147.A47
3600905147
|
£13.12
|
£15.75
|
|
|
77 - O-RING 22x2 MM
BSD-1900210321.A160
1900210321
|
£5.30
|
£6.36
|
|
|
78 - FELT DISC
BSD-1600108018.A65
1600108018
|
£2.61
|
£3.13
|
|
|
79 - COVER DISC
BSD-1600501024.A107
1600501024
|
£16.41
|
£19.69
|
|
|
80 - SHIM 0.1 MM
BSD-1600102633.A11
1600102633
|
£1.75
|
£2.10
|
|
|
81 - SHIM 0.15 MM
BSD-1600102634.A17
1600102634
|
£2.61
|
£3.13
|
|
|
83 - THREADED RING
BSD-1603344029.A61
1603344029
|
£68.42
|
£82.10
|
|
|
84 - SHIM 0.05 MM
BSD-1600102632.A18
1600102632
|
£2.16
|
£2.59
|
|
|
89 - END SPLICE
BSD-3604477008.A185
3604477008
|
£1.75
|
£2.10
|
|
|
91 - SEAL RING
BSD-1600209004.A78
1600209004
|
£2.80
|
£3.36
|
|
|
94 - SET SCREW
BSD-1603402002.A59
1603402002
|
£1.75
|
£2.10
|
|
|
95 - SET SCREW
BSD-1603402004.A65
1603402004
|
£2.61
|
£3.13
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A320
3601110047
|
£2.80
|
£3.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1667
3601119236
|
£3.72
|
£4.47
|
|
|
656 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A396
2607950511
|
£4.26
|
£5.11
|
|
|
657 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A245
1602025030
|
£18.96
|
£22.75
|
|
|
700/10 - AUXILIARY HANDLE
BSD-160202507H.A610
160202507H
|
£11.30
|
£13.56
|
|
|
700/20 - ADAPTER M8/M14
BSD-3603523013.A25
3603523013
|
£16.41
|
£19.69
|
|
|
801 - MOTOR HOUSING
BSD-3605102079.A79
3605102079
|
£179.37
|
£215.24
|
|
|
805 - GEAR HOUSING
BSD-3607030321.A19
3607030321
|
£283.50
|
£340.20
|
|
|
809/01 - BEARING FLANGE
BSD-3607030375.A74
3607030375
|
£195.26
|
£234.31
|
|
|
809/02 - BEARING FLANGE
BSD-3607030376.A25
3607030376
|
£120.11
|
£144.13
|
|
|
810 - SEAL KIT
BSD-1607000039.A56
1607000039
|
£13.12
|
£15.75
|
|
|
811 - SEAL KIT
BSD-1607000044.A33
1607000044
|
£9.49
|
£11.39
|
|
|
814 - HANDLE
BSD-3605132048.A152
3605132048
|
£63.50
|
£76.20
|
|
|
816 - ELEC. CABLE W/CONNECTION
BSD-3607030236.A7
3607030236
|
£61.98
|
£74.38
|
|
|
817 - SWITCH KIT
BSD-1607000036.A50
1607000036
|
-
|
|
|
|
867 - SEALING PLATE
BSD-1602388007.A308
1602388007
|
£12.04
|
£14.45
|
|
