2 - STATOR 200V/300HZ.135V/200HZ
BSD-1604229099.A5
1604229099
|
£410.78
|
£492.94
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209002.A19
1600209002
|
£5.30
|
£6.36
|
|
|
6 - GRINDING SPINDLE
BSD-3603523032.A12
3603523032
|
£54.42
|
£65.30
|
|
|
7 - SEAL RING
BSD-1600290020.A196
1600290020
|
£1.75
|
£2.10
|
|
|
10 - O-RING 45x3MM
BSD-1900210146.A72
1900210146
|
£4.26
|
£5.11
|
|
|
15 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A570
1600703009
|
£5.58
|
£6.70
|
|
|
19 - CONTROL LEVER
BSD-1602026030.A70
1602026030
|
£10.10
|
£12.12
|
|
|
19/1 - FELT WASHER
BSD-1600205008.A175
1600205008
|
£1.75
|
£2.10
|
|
|
22 - NAMEPLATE
BSD-3601106053.A480
3601106053
|
£5.30
|
£6.36
|
|
|
25 - FASTENING CLAMP
BSD-1601303003.A305
1601303003
|
£2.16
|
£2.59
|
|
|
26 - O-RING 66.0x3.0 MM
BSD-1600210005.A279
1600210005
|
£2.80
|
£3.36
|
|
|
27 - SHIM
BSD-3600100075.A39
3600100075
|
£11.30
|
£13.56
|
|
|
27 - SHIM
BSD-3600100076.A9
3600100076
|
£11.30
|
£13.56
|
|
|
27 - SHIM
BSD-3600100077.A39
3600100077
|
£12.04
|
£14.45
|
|
|
28 - SPRING RETAINING RING
BSD-3603435038.A44
3603435038
|
£2.61
|
£3.13
|
|
|
29 - SEALING PLATE
BSD-1600113003.A146
1600113003
|
£2.80
|
£3.36
|
|
|
30 - SEALING DISK
BSD-1600108055.A148
1600108055
|
£1.75
|
£2.10
|
|
|
31 - SHIM 0.1 MM
BSD-1600101616.A115
1600101616
|
£2.61
|
£3.13
|
|
|
31 - SHIM 0.2 MM
BSD-1600101617.A83
1600101617
|
£1.75
|
£2.10
|
|
|
31 - SHIM 0.3 MM
BSD-1600101618.A171
1600101618
|
£2.61
|
£3.13
|
|
|
31 - SHIM 0.05 MM
BSD-1600101619.A81
1600101619
|
£2.16
|
£2.59
|
|
|
32 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A17
2910110120
|
£1.75
|
£2.10
|
|
|
33 - NEEDLE BEARING dia22x11.3 MM
BSD-1600910010.A219
1600910010
|
£45.67
|
£54.80
|
|
|
34 - GROOVE BALL BEARING
BSD-3600905138.A24
3600905138
|
-
|
|
|
|
35 - RETAINING RING dia22 MM
BSD-2916620011.A304
2916620011
|
£1.75
|
£2.10
|
|
|
36 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x25-8.8
BSD-2910141164.A45
2910141164
|
£2.16
|
£2.59
|
|
|
37 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x20-8.8
BSD-2910141162.A28
2910141162
|
£2.16
|
£2.59
|
|
|
38 - HEX SOCKET HEAD CAP SCREW DIN 912-M 5x30-8.8
BSD-2910141166.A148
2910141166
|
£1.75
|
£2.10
|
|
|
39 - SOCKET HEAD CAP SCREW
BSD-3603450008.A13
3603450008
|
£2.16
|
£2.59
|
|
|
40 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A636
2910211006
|
£1.75
|
£2.10
|
|
|
41 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1417
2910021118
|
£1.75
|
£2.10
|
|
|
42 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A444
2916011005
|
£1.75
|
£2.10
|
|
|
43 - SOCKET HEAD CAP SCREW DIN 84-AM4x10-8.8
BSD-2910021120.A34
2910021120
|
£1.75
|
£2.10
|
|
|
44 - PAN HEAD SCREW DIN 85-AM4x10-MS
BSD-2910110120.A16
2910110120
|
£1.75
|
£2.10
|
|
|
45 - CLAMPING SADDLE
BSD-3601321001.A358
3601321001
|
£3.72
|
£4.47
|
|
|
46 - THREAD-FORMING TAP. SCREW
BSD-3603435004.A17
3603435004
|
£2.80
|
£3.36
|
|
|
47 - SPRING WASHER dia4.2 MM
BSD-3600150006.A696
3600150006
|
£2.61
|
£3.13
|
|
|
48 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A428
3603133001
|
£2.61
|
£3.13
|
|
|
51 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A443
2916011005
|
£1.75
|
£2.10
|
|
|
55 - BEVEL GEAR Z=46
BSD-1606333051.A31
1606333051
|
£93.88
|
£112.65
|
|
|
60 - SEALING CORD
BSD-1601014000.A10
1601014000
|
£2.80
|
£3.36
|
|
|
68 - GROMMET
BSD-1600306001.A253
1600306001
|
£2.61
|
£3.13
|
|
|
71 - ROTOR WITHOUT WINDING
BSD-1604080032.A49
1604080032
|
£195.26
|
£234.31
|
|
|
72 - BEARING COVER
BSD-1600501019.A508
1600501019
|
£23.86
|
£28.63
|
|
|
73 - BEARING FLANGE
BSD-3605820064.A88
3605820064
|
£68.42
|
£82.10
|
|
|
74 - GROOVE BALL BEARING
BSD-3600905095.A39
3600905095
|
£21.52
|
£25.83
|
|
|
75 - TORX FLAT-HEAD SCREW M4x20
BSD-3603435051.A3
3603435051
|
£1.75
|
£2.10
|
|
|
76 - GROOVE BALL BEARING 7x22x7
BSD-3600905147.A63
3600905147
|
£13.12
|
£15.75
|
|
|
77 - O-RING 22x2 MM
BSD-1900210321.A105
1900210321
|
£5.30
|
£6.36
|
|
|
78 - FELT DISC
BSD-1600108018.A163
1600108018
|
£2.61
|
£3.13
|
|
|
79 - COVER DISC
BSD-1600501024.A23
1600501024
|
£16.41
|
£19.69
|
|
|
89 - END SPLICE
BSD-3604477008.A63
3604477008
|
£1.75
|
£2.10
|
|
|
91 - SEAL RING
BSD-1600209004.A30
1600209004
|
£2.80
|
£3.36
|
|
|
92 - BEVEL GEAR Z=22
BSD-1606333050.A19
1606333050
|
£410.78
|
£492.94
|
|
|
94 - SET SCREW
BSD-1603402002.A110
1603402002
|
£1.75
|
£2.10
|
|
|
95 - SET SCREW
BSD-1603402004.A135
1603402004
|
£2.61
|
£3.13
|
|
|
96 - MANUFACTURER'S NAMEPLATE
BSD-3601110047.A243
3601110047
|
£2.80
|
£3.36
|
|
|
99 - REFERENCE PLATE
BSD-3601119236.A1147
3601119236
|
£3.72
|
£4.47
|
|
|
652 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A101
1607950061
|
£5.42
|
£6.50
|
|
|
653 - PROTECTIVE COVER dia180 MM
BSD-1600A00XL9.A53
1600A00XL9
|
£21.52
|
£25.83
|
|
|
654 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A710
2605703014
|
£7.36
|
£8.83
|
|
|
655 - ROUND NUT M14
BSD-1603345043.A489
1603345043
|
£8.67
|
£10.41
|
|
|
656 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A653
2607950511
|
£4.26
|
£5.11
|
|
|
657 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A649
1602025030
|
£18.96
|
£22.75
|
|
|
700/1 - AUXILIARY HANDLE
BSD-160202507H.A528
160202507H
|
£11.30
|
£13.56
|
|
|
700/2 - ADAPTER M8/M14
BSD-3603523013.A109
3603523013
|
£16.41
|
£19.69
|
|
|
701/1 - FAST LOCKING FLANGE M14. SDS-CLIC
BSD-1603340027.A388
1603340027
|
£46.82
|
£56.18
|
|
|
801 - MOTOR HOUSING
BSD-3605102079.A57
3605102079
|
£179.37
|
£215.24
|
|
|
805 - GEAR HOUSING
BSD-3607030321.A8
3607030321
|
£283.50
|
£340.20
|
|
|
809/01 - BEARING FLANGE
BSD-3607030376.A36
3607030376
|
£120.11
|
£144.13
|
|
|
809/02 - BEARING FLANGE
BSD-3607030375.A38
3607030375
|
£195.26
|
£234.31
|
|
|
810 - SEAL KIT
BSD-1607000039.A11
1607000039
|
£13.12
|
£15.75
|
|
|
811 - SEAL KIT
BSD-1607000044.A20
1607000044
|
£9.49
|
£11.39
|
|
|
814 - HANDLE
BSD-3605132048.A27
3605132048
|
£63.50
|
£76.20
|
|
|
816 - ELEC. CABLE W/CONNECTION
BSD-3607030236.A42
3607030236
|
£61.98
|
£74.38
|
|
|
817 - SWITCH KIT
BSD-1607000036.A144
1607000036
|
-
|
|
|
|
867 - SEALING PLATE
BSD-1602388007.A236
1602388007
|
£12.04
|
£14.45
|
|
