2 - ADJUSTMENT KNOB
BSD-1600591021.A14
1600591021
|
-
|
|
|
|
3 - SPRING CLIP
BSD-1600290034.A34
1600290034
|
-
|
|
|
|
4/10 - SWITCH PLATE
BSD-1605190132.A18
1605190132
|
£3.80
|
£4.56
|
|
|
4/10/1 - SWITCH PLATE
BSD-1605190056.A11
1605190056
|
-
|
|
|
|
4/20/1 - SWITCH KIT
BSD-1607000863.A47
1607000863
|
£93.88
|
£112.65
|
|
|
4/30 - SWITCH
BSD-1607200131.A25
1607200131
|
-
|
|
|
|
4/40 - SWITCH BUTTON
BSD-1602025029.A7
1602025029
|
£2.61
|
£3.13
|
|
|
4/40/1 - SWITCH BUTTON
BSD-1602025028.A16
1602025028
|
-
|
|
|
|
4/50 - PROTECTIVE CAP
BSD-1605500207.A19
1605500207
|
-
|
|
|
|
4/50/1 - FRAME
BSD-1601015028.A9
1601015028
|
-
|
|
|
|
4/60 - OVAL-HEAD SCREW KT 4.0x14
BSD-1603425001.A24
1603425001
|
£2.52
|
£3.02
|
|
|
4/60/1 - THREAD-FORMING TAP. SCREW KT 4.0x14 MM
BSD-1603435039.A13
1603435039
|
-
|
|
|
|
4/70 - OVAL-HEAD SCREW 4x12 MM
BSD-2914211503.A25
2914211503
|
£2.52
|
£3.02
|
|
|
6 - CONNECTION PART
BSD-1605190060.A15
1605190060
|
-
|
|
|
|
7 - SUPPRESSION FILTER
BSD-1607328069.A5
1607328069
|
-
|
|
|
|
8 - REFERENCE PLATE
BSD-1601118936.A1
1601118936
|
-
|
|
|
|
9 - REFERENCE PLATE
BSD-1601118928.A13
1601118928
|
£3.80
|
£4.56
|
|
|
10 - REFERENCE PLATE
BSD-1601118933.A2
1601118933
|
-
|
|
|
|
11 - REFERENCE PLATE
BSD-1601118937.A0
1601118937
|
-
|
|
|
|
12 - COVER PLATE
BSD-1605500190.A20
1605500190
|
£2.52
|
£3.02
|
|
|
13 - HOUSING BASE
BSD-1605190092.A3
1605190092
|
-
|
|
|
|
15 - HOUSING COVER
BSD-1605190095.A3
1605190095
|
-
|
|
|
|
16 - INSERT
BSD-1605190055.A20
1605190055
|
-
|
|
|
|
17 - STICKER
BSD-1601118916.A21
1601118916
|
£3.34
|
£4.01
|
|
|
18 - NAMEPLATE
BSD-1601118934.A0
1601118934
|
-
|
|
|
|
29 - SWITCH
BSD-1607200134.A12
1607200134
|
£6.61
|
£7.93
|
|
|
30 - WIRING HARNESS
BSD-1604449010.A13
1604449010
|
£24.45
|
£29.34
|
|
|
33 - SWITCH SUPPORT
BSD-1605190059.A3
1605190059
|
£1.95
|
£2.34
|
|
|
42 - THREAD-FORMING TAP. SCREW TORX-T20
BSD-1603435054.A21
1603435054
|
£1.75
|
£2.10
|
|
|
101 - MOTOR 230V
BSD-1607220035.A13
1607220035
|
-
|
|
|
|
102 - TOOTHED GEAR Z=8
BSD-1606318011.A18
1606318011
|
£13.41
|
£16.09
|
|
|
106 - RING GEAR Z=112
BSD-1606334006.A8
1606334006
|
-
|
|
|
|
112 - TOOTHED GEAR Z=49
BSD-1606317088.A40
1606317088
|
-
|
|
|
|
113 - TOOTHED GEAR Z=23
BSD-1606318008.A16
1606318008
|
-
|
|
|
|
114 - DRIVE SHAFT
BSD-1603124130.A0
1603124130
|
-
|
|
|
|
115 - CUTTING HEAD
BSD-1608584013.A0
1608584013
|
-
|
|
|
|
116 - COUNTER BAR
BSD-1602388034.A4
1602388034
|
£21.52
|
£25.83
|
|
|
117 - FRICTION WASHER
BSD-1600100032.A6
1600100032
|
£1.66
|
£1.99
|
|
|
118 - SCRAPER
BSD-1601034040.A37
1601034040
|
£7.78
|
£9.33
|
|
|
119 - FRICTION WASHER
BSD-1600100030.A6
1600100030
|
-
|
|
|
|
120 - FRICTION WASHER
BSD-1600100027.A15
1600100027
|
£2.33
|
£2.80
|
|
|
122 - SCRAPER
BSD-1601034040.A38
1601034040
|
£7.78
|
£9.33
|
|
|
125 - RETAINING RING 10 DIN 9045
BSD-2916600006.A9
2916600006
|
£1.75
|
£2.10
|
|
|
126 - SPRING RETAINING RING DIN 471 18x1.2MM
BSD-2916650009.A25
2916650009
|
£1.75
|
£2.10
|
|
|
127 - CARRIER
BSD-1606490040.A22
1606490040
|
£5.87
|
£7.04
|
|
|
129 - ADJUSTING SCREW
BSD-1603490004.A34
1603490004
|
£2.80
|
£3.36
|
|
|
130 - THREAD-FORMING TAP. SCREW M6x25 MM
BSD-1603414010.A68
1603414010
|
£1.75
|
£2.10
|
|
|
131 - HOLDING PLATE
BSD-1601329028.A24
1601329028
|
£1.75
|
£2.10
|
|
|
133 - SEAL
BSD-1600290035.A5
1600290035
|
-
|
|
|
|
135 - LOCKING WASHER DIN 6799-12-FST
BSD-2916080014.A41
2916080014
|
£1.75
|
£2.10
|
|
|
652 - CATCHER CONTAINER
BSD-1605411031.A31
1605411031
|
£11.30
|
£13.56
|
|
|
653 - OFFSET SCREWDRIVER SW5
BSD-1607950057.A26
1607950057
|
£3.34
|
£4.01
|
|
|
667 - SUPPORTING FRAME
BSD-1600795012.A3
1600795012
|
-
|
|
|
|
668 - AXLE
BSD-1607000303.A3
1607000303
|
-
|
|
|
|
669 - WHEEL
BSD-1609351093.A0
1609351093
|
-
|
|
|
|
670 - CONNECTOR
BSD-1606491001.A5
1606491001
|
-
|
|
|
|
671 - SWITCH KIT
BSD-1607000863.A31
1607000863
|
£93.88
|
£112.65
|
|
|
673 - PLAIN WASHER
BSD-1600190030.A39
1600190030
|
£1.75
|
£2.10
|
|
|
675 - PARTS SET
BSD-1607000832.A1
1607000832
|
-
|
|
|
|
677 - CAP NUT DIN 1587-M6-M-6
BSD-2915151001.A36
2915151001
|
£4.75
|
£5.70
|
|
|
681 - PAD
BSD-1600390016.A3
1600390016
|
-
|
|
|
|
804 - GEAR HOUSING
BSD-1607000817.A10
1607000817
|
-
|
|
|
|
805 - BEARING FLANGE
BSD-1607000813.A1
1607000813
|
-
|
|
|
|
808 - PLANETARY-GEAR CARRIER
BSD-1607000874.A16
1607000874
|
£19.45
|
£23.34
|
|
|
809 - PLANETARY-GEAR CARRIER
BSD-1607000820.A16
1607000820
|
£21.68
|
£26.01
|
|
|
814 - UPPER HOUSING
BSD-1605190094.A1
1605190094
|
-
|
|
|
|
842 - SWITCH KIT
BSD-1607000863.A32
1607000863
|
£93.88
|
£112.65
|
|
