2 - FIELD 220-240V
BSD-2604220515.A53
2604220515
|
£21.68
|
£26.01
|
|
|
3/50 - FAN
BSD-2606610022.A109
2606610022
|
£4.26
|
£5.11
|
|
|
4 - SWITCH
BSD-1607200172.A6
1607200172
|
-
|
|
|
|
6 - GROMMET dia7.3-dia8.6x76 MM
BSD-2600703018.A25
2600703018
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-1611035005.A316
1611035005
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110A37.A6
1611110A37
|
£1.75
|
£2.10
|
|
|
10 - BRUSH PLATE
BSD-2605807060.A159
2605807060
|
-
|
|
|
|
11 - REFERENCE PLATE
BSD-1611110A38.A0
1611110A38
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328040.A22
1607328040
|
£6.52
|
£7.83
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A387
1610905025
|
£6.52
|
£7.83
|
|
|
15 - DAMPING RUBBER
BSD-1610026001.A78
1610026001
|
£1.75
|
£2.10
|
|
|
27 - STRIKER
BSD-1618710076.A16
1618710076
|
£6.61
|
£7.93
|
|
|
30 - DRIVE LEVER
BSD-1611911000.A28
1611911000
|
-
|
|
|
|
34 - BEARING PIN
BSD-1613100021.A94
1613100021
|
£2.33
|
£2.80
|
|
|
46 - STRAIGHT PIN
BSD-1613160022.A21
1613160022
|
£1.75
|
£2.10
|
|
|
53 - NEEDLE BEARING
BSD-1610910077.A21
1610910077
|
£4.26
|
£5.11
|
|
|
57 - ROLLER THRUST BEARING
BSD-1610920009.A79
1610920009
|
£3.34
|
£4.01
|
|
|
62 - O-RING 18.0x2.5 MM
BSD-1610210125.A13
1610210125
|
£1.95
|
£2.34
|
|
|
72 - SHIM WASHER 1.0 MM
BSD-1610100007.A7
1610100007
|
£1.75
|
£2.10
|
|
|
74 - SEALING FRAME
BSD-1611015040.A38
1611015040
|
-
|
|
|
|
75 - SEALING FRAME
BSD-1611015041.A0
1611015041
|
£1.95
|
£2.34
|
|
|
76 - SEALING FRAME
BSD-1611015042.A46
1611015042
|
-
|
|
|
|
77 - RETAINING RING
BSD-1614601026.A27
1614601026
|
£1.75
|
£2.10
|
|
|
78 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A655
1903230010
|
£1.75
|
£2.10
|
|
|
86 - CONNECTING CABLE L=85 MM
BSD-2604448147.A46
2604448147
|
£1.75
|
£2.10
|
|
|
87 - CONNECTING CABLE L=115MM
BSD-2604448096.A61
2604448096
|
-
|
|
|
|
88 - CONNECTING CABLE L=88 MM
BSD-2604448034.A293
2604448034
|
£1.75
|
£2.10
|
|
|
89 - CABLE L=173 MM
BSD-2604448060.A156
2604448060
|
-
|
|
|
|
92 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A110
2912401021
|
£1.75
|
£2.10
|
|
|
93 - TAPPING SCREW DIN7981-ST3.9x16-C-Z
BSD-2912401019.A146
2912401019
|
£1.75
|
£2.10
|
|
|
94 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A1318
2603490017
|
£2.16
|
£2.59
|
|
|
95 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1110
2603410001
|
£1.75
|
£2.10
|
|
|
110 - REFERENCE PLATE
BSD-1601118B75.A3
1601118B75
|
£1.95
|
£2.34
|
|
|
202 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A836
2915011007
|
-
|
|
|
|
203 - WING SCREW M6x(15)55
BSD-1613480007.A390
1613480007
|
£1.75
|
£2.10
|
|
|
205 - CLAMPING PLATE M6
BSD-2608040014.A273
2608040014
|
-
|
|
|
|
206 - WING SCREW M6x20 MM
BSD-1613480008.A20
1613480008
|
£1.75
|
£2.10
|
|
|
651 - AUXILIARY HANDLE
BSD-2602025094.A90
2602025094
|
£7.36
|
£8.83
|
|
|
652 - DEPTH-GAUGE
BSD-2609005615.A226
2609005615
|
£4.26
|
£5.11
|
|
|
702 - PARTS SET
BSD-1617000133.A16
1617000133
|
-
|
|
|
|
702/10/2 - RETAINING RING
BSD-2604601004.A499
2604601004
|
£1.75
|
£2.10
|
|
|
702/30 - SCREWDRIVER BIT
BSD-2607000248.A10
2607000248
|
-
|
|
|
|
703 - DUST TRAY
BSD-1615439003.A27
1615439003
|
-
|
|
|
|
703/30 - RUBBER BUSHING dia5-7 MM
BSD-1610312001.A120
1610312001
|
-
|
|
|
|
703/651 - RUBBER BUSHING dia8-10 MM
BSD-1610312002.A19
1610312002
|
-
|
|
|
|
754 - DRILL HOLDER
BSD-2607000122.A209
2607000122
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-1617000362.A17
1617000362
|
-
|
|
|
|
803 - ARMATURE 220-230V
BSD-1614010144.A15
1614010144
|
-
|
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1614460026.A96
1614460026
|
£18.96
|
£22.75
|
|
|
806 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A572
1900452012
|
£1.75
|
£2.10
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A265
160111A3H5
|
£2.61
|
£3.13
|
|
|
810/04 - CARBON-BRUSH SET
BSD-1617014136.A38
1617014136
|
£12.04
|
£14.45
|
|
|
810/06 - RATCHET CAP
BSD-2601322017.A118
2601322017
|
£1.75
|
£2.10
|
|
|
810/06 - RATCHET CAP
BSD-2601322013.A265
2601322013
|
£1.75
|
£2.10
|
|
|
814 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A161
1610905048
|
£8.67
|
£10.41
|
|
|
816 - CHANGE-OVER SWITCH
BSD-2607200231.A313
2607200231
|
£16.41
|
£19.69
|
|
|
821 - HAMMER PIPE
BSD-1617000388.A0
1617000388
|
-
|
|
|
|
824 - JACK SHAFT
BSD-1617000301.A27
1617000301
|
-
|
|
|
|
844 - CLAMP HANDLE
BSD-1617000322.A8
1617000322
|
£3.72
|
£4.47
|
|
|
850 - BUSHING
BSD-1617000975.A85
1617000975
|
£6.61
|
£7.93
|
|
|
856 - KEY CHUCK
BSD-1618571029.A17
1618571029
|
£63.50
|
£76.20
|
|
|
857 - KEYLESS CHUCK
BSD-1617000332.A24
1617000332
|
£93.88
|
£112.65
|
|
|
858 - CHUCK WRENCH SG2
BSD-2607950007.A1276
2607950007
|
£6.52
|
£7.83
|
|
|
870 - QUICK-CHANGE COLLET CHUCK
BSD-1617000327.A27
1617000327
|
£63.50
|
£76.20
|
|
|
870/34 - PROTECTIVE CAP
BSD-1610508047.A271
1610508047
|
£2.29
|
£2.75
|
|
