1 - HOUSING SECTION
BSD-2605104388.A5
2605104388
|
-
|
|
|
|
2 - FIELD 230-240V
BSD-2604220526.A14
2604220526
|
£21.68
|
£26.01
|
|
|
3 - ARMATURE 230V
BSD-2604010881.A4
2604010881
|
-
|
|
|
|
3/60 - FAN
BSD-2606610055.A36
2606610055
|
£4.26
|
£5.11
|
|
|
4 - SWITCH
BSD-2607200260.A80
2607200260
|
£11.30
|
£13.56
|
|
|
5 - POWER SUPPLY CORD I / BR 2.65m 2 x 1.0mm H05VV-F
BSD-2604460280.A8
2604460280
|
£14.91
|
£17.89
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A812
2600703017
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035004.A160
2601035004
|
£2.16
|
£2.59
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601117751.A0
2601117751
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A463
1607328028
|
£5.30
|
£6.36
|
|
|
13 - NEEDLE BEARING
BSD-2600917002.A66
2600917002
|
£3.72
|
£4.47
|
|
|
14 - GROOVE BALL BEARING
BSD-2600905034.A25
2600905034
|
£13.12
|
£15.75
|
|
|
16 - BRUSH PLATE
BSD-2604337118.A3
2604337118
|
£23.86
|
£28.63
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1131
2603410001
|
£1.75
|
£2.10
|
|
|
19 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A726
2603490021
|
£1.75
|
£2.10
|
|
|
25 - PLAIN WASHER DIN 315-M8-GT-C
BSD-2600100041.A26
2600100041
|
£1.75
|
£2.10
|
|
|
26 - FAN
BSD-2606610066.A1
2606610066
|
-
|
|
|
|
27 - CARRIER
BSD-2606490053.A4
2606490053
|
-
|
|
|
|
28 - SHIM 1.0 MM
BSD-2600000025.A5
2600000025
|
-
|
|
|
|
28 - SHIM 0.1 MM
BSD-2600000022.A2
2600000022
|
£1.75
|
£2.10
|
|
|
28 - SHIM 0.2 MM
BSD-2600000023.A5
2600000023
|
-
|
|
|
|
28 - SHIM 0.5 MM
BSD-2600000024.A2
2600000024
|
£1.75
|
£2.10
|
|
|
29 - SPRING RETAINING RING
BSD-2600116014.A29
2600116014
|
£1.75
|
£2.10
|
|
|
30 - GROOVE BALL BEARING 15x35x11
BSD-2600905111.A2
2600905111
|
£12.04
|
£14.45
|
|
|
32 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A135
1903230007
|
£1.75
|
£2.10
|
|
|
33 - BACKING PAD dia 150 MM
BSD-2608601049.A3
2608601049
|
-
|
|
|
|
35 - HEX SOCKET HEAD CAP SCREW DIN 7984-M8x12-8.8
BSD-2910130238.A3
2910130238
|
£1.75
|
£2.10
|
|
|
36 - RUBBER BUFFER
BSD-1603100036.A68
1603100036
|
£1.75
|
£2.10
|
|
|
40 - DAMPING PLATE
BSD-2601022000.A717
2601022000
|
£1.75
|
£2.10
|
|
|
42 - CONNECTING CABLE
BSD-2604448166.A5
2604448166
|
-
|
|
|
|
43 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1644
2603490023
|
£1.75
|
£2.10
|
|
|
44 - SEAL STRIP
BSD-2602380003.A47
2602380003
|
£1.32
|
£1.58
|
|
|
45 - HANDLE
BSD-2602025068.A8
2602025068
|
-
|
|
|
|
46 - ROUND-HEAD BOLT DIN 603-M6x110
BSD-2910285226.A42
2910285226
|
£1.75
|
£2.10
|
|
|
47 - WING NUT M6
BSD-1603339006.A160
1603339006
|
£2.52
|
£3.02
|
|
|
48 - PUSHER
BSD-2608005043.A5
2608005043
|
£1.75
|
£2.10
|
|
|
50 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A38
1907950006
|
£4.26
|
£5.11
|
|
|
51 - TOOTHED BELT WHEEL Z=18
BSD-2606625014.A7
2606625014
|
-
|
|
|
|
52 - TOOTHED BELT WHEEL Z=30
BSD-2606625015.A0
2606625015
|
-
|
|
|
|
53 - TOOTHED BELT
BSD-2604736009.A6
2604736009
|
£8.67
|
£10.41
|
|
|
55 - GROOVE BALL BEARING
BSD-2600923002.A4
2600923002
|
-
|
|
|
|
56 - SPEED GOVERNOR 230-240V
BSD-2608300008.A4
2608300008
|
-
|
|
|
|
57 - OUTPUT SHAFT
BSD-2603124116.A6
2603124116
|
-
|
|
|
|
58 - LEVER
BSD-2601901006.A1
2601901006
|
-
|
|
|
|
59 - COMPRESSION SPRING
BSD-2604610032.A1
2604610032
|
-
|
|
|
|
60 - SCREW 4x16
BSD-2603490022.A109
2603490022
|
£1.75
|
£2.10
|
|
|
653 - SET OF SANDING PAPERS
BSD-2608604098.A0
2608604098
|
-
|
|
|
|
654 - DUST CHAMBER
BSD-2605411129.A28
2605411129
|
£13.12
|
£15.75
|
|
|
655 - ADAPTER
BSD-2605702039.A3
2605702039
|
£5.30
|
£6.36
|
|
|
808 - NAMEPLATE
BSD-2601117762.A0
2601117762
|
-
|
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2604321917.A117
2604321917
|
-
|
|
|
|
816/05 - COMPRESSION SPRING
BSD-2604610026.A149
2604610026
|
£2.61
|
£3.13
|
|
|
816/06 - RATCHET CAP
BSD-2601329051.A139
2601329051
|
£2.33
|
£2.80
|
|
|
816/06/1 - RATCHET CAP
BSD-2601322013.A247
2601322013
|
£1.75
|
£2.10
|
|
