1 - HOUSING SECTION
BSD-2605104987.A0
2605104987
|
-
|
|
|
|
2 - FIELD 240V
BSD-1604220362.A4
1604220362
|
-
|
|
|
|
3 - ARMATURE 240V
BSD-1604010289.A1
1604010289
|
-
|
|
|
|
3/60 - FAN
BSD-1606610122.A114
1606610122
|
£2.80
|
£3.36
|
|
|
4 - SWITCH
BSD-2607200084.A120
2607200084
|
£10.10
|
£12.12
|
|
|
5 - POWER SUPPLY CORD AUS 2.6m 2 x 0.75mm PVC
BSD-2604460074.A1
2604460074
|
£21.52
|
£25.83
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A792
2600703012
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A479
2600703011
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A413
2600703013
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2829
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601110403.A4
2601110403
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A93
1607328028
|
£5.30
|
£6.36
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A603
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A275
2600905052
|
£7.36
|
£8.83
|
|
|
16 - BRUSH HOLDER
BSD-2604337002.A15
2604337002
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2124
2603410001
|
£1.75
|
£2.10
|
|
|
19 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A562
2910611019
|
£2.80
|
£3.36
|
|
|
20 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A473
1601110481
|
£2.16
|
£2.59
|
|
|
25 - INTERMEDIATE RING
BSD-1600502011.A423
1600502011
|
£2.61
|
£3.13
|
|
|
26 - INTERMEDIATE RING
BSD-1600206026.A81
1600206026
|
£1.75
|
£2.10
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A90
2600910001
|
£4.26
|
£5.11
|
|
|
28 - TOOTHED BELT WHEEL Z=19
BSD-1606625026.A1
1606625026
|
-
|
|
|
|
29 - TOOTHED BELT WHEEL Z=43
BSD-1606625025.A35
1606625025
|
-
|
|
|
|
30 - RUBBER RING
BSD-1600206025.A254
1600206025
|
£2.16
|
£2.59
|
|
|
31 - TOOTHED BELT 14 MM. Z=85
BSD-2604736002.A12
2604736002
|
£10.10
|
£12.12
|
|
|
32 - GEAR COVER
BSD-3605500024.A6
3605500024
|
-
|
|
|
|
33 - SCALE WINDOW
BSD-1601099010.A7
1601099010
|
-
|
|
|
|
34 - GRADUATED DIAL
BSD-2606621001.A15
2606621001
|
-
|
|
|
|
35 - COVERING HOOD
BSD-3605510012.A18
3605510012
|
£3.80
|
£4.56
|
|
|
36 - BASE PLATE
BSD-3608000001.A5
3608000001
|
-
|
|
|
|
37 - ADJUSTING SLIDE
BSD-3601320001.A17
3601320001
|
-
|
|
|
|
38 - RUBBER BAND
BSD-1601006006.A36
1601006006
|
-
|
|
|
|
39 - PROTECTIVE COVER
BSD-1605510142.A30
1605510142
|
-
|
|
|
|
41 - AIR-DEFLECTOR RING
BSD-3600290011.A0
3600290011
|
-
|
|
|
|
42 - SPIRAL SPRING
BSD-2604652008.A128
2604652008
|
-
|
|
|
|
43 - COMPRESSION SPRING
BSD-1604619017.A112
1604619017
|
£2.16
|
£2.59
|
|
|
44 - PROTECTIVE COVER
BSD-1605510139.A38
1605510139
|
-
|
|
|
|
45 - COMPRESSION SPRING
BSD-1604651007.A19
1604651007
|
-
|
|
|
|
46 - ADJUSTING SLIDE
BSD-3608000002.A0
3608000002
|
-
|
|
|
|
47 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A218
2603490017
|
£2.16
|
£2.59
|
|
|
48 - TAB WASHER
BSD-1600190016.A50
1600190016
|
-
|
|
|
|
49 - HANDLE COVER
BSD-3605500023.A0
3605500023
|
-
|
|
|
|
50 - SHIM
BSD-2600100033.A19
2600100033
|
-
|
|
|
|
51 - TAB WASHER
BSD-2600190008.A17
2600190008
|
-
|
|
|
|
52 - SHIM 0.5 MM
BSD-2600100588.A105
2600100588
|
£1.75
|
£2.10
|
|
|
54 - OFFSET SCREWDRIVER DIN 911. SW3
BSD-1907950004.A74
1907950004
|
£5.58
|
£6.70
|
|
|
55 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A274
2600905052
|
£7.36
|
£8.83
|
|
|
56 - SHIM 0.5 MM
BSD-3600100005.A17
3600100005
|
-
|
|
|
|
57 - CONNECTING CABLE L=238 MM
BSD-3604431005.A0
3604431005
|
-
|
|
|
|
58 - CONNECTING CABLE L=383 MM
BSD-3604431006.A24
3604431006
|
-
|
|
|
|
60 - DISC SPRING DIN 2093-A12.5-GR-1
BSD-2916160003.A11
2916160003
|
-
|
|
|
|
61 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A138
2915011007
|
-
|
|
|
|
62 - TAPPING SCREW DIN 7981-B 3.9x9.5
BSD-2910611017.A24
2910611017
|
-
|
|
|
|
63 - ADJUSTING NUT
BSD-3603342003.A0
3603342003
|
£1.75
|
£2.10
|
|
|
64 - HEX SCREW
BSD-3603450005.A38
3603450005
|
-
|
|
|
|
70 - PLANER HEAD
BSD-2603204900.A9
2603204900
|
-
|
|
|
|
71 - LEAF SPRING
BSD-1601234002.A18
1601234002
|
-
|
|
|
|
72 - PRESSURE BAR
BSD-2608040025.A9
2608040025
|
£37.32
|
£44.79
|
|
|
73 - SUPPORT CLAMP
BSD-1601330010.A3
1601330010
|
-
|
|
|
|
75 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A705
2910021125
|
£1.75
|
£2.10
|
|
|
76 - SET SCREW M 6x12 DIN 915-45H
BSD-2912081193.A20
2912081193
|
-
|
|
|
|
85 - SLOTTED SPRING PIN
BSD-1600410003.A24
1600410003
|
-
|
|
|
|
704 - CHIPS BAG
BSD-1605411022.A22
1605411022
|
£17.49
|
£20.99
|
|
|
704/10 - FITTING
BSD-1605190030.A18
1605190030
|
-
|
|
|
|
704/20 - CLAMPING PIECE
BSD-1605703073.A18
1605703073
|
-
|
|
|
|
704/30 - RETAINING BRACKET
BSD-2608045003.A24
2608045003
|
-
|
|
|
|
704/50 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A219
2603490017
|
£2.16
|
£2.59
|
|
|
705 - CONNECTING PIPE dia 35 MM
BSD-1607000154.A0
1607000154
|
-
|
|
|
|
706 - DEPTH-GAUGE
BSD-1608132006.A16
1608132006
|
£3.49
|
£4.19
|
|
|
706/10 - STOP BRACKET
BSD-1601331039.A23
1601331039
|
-
|
|
|
|
706/20 - WING SCREW M 6x16 MM
BSD-2603480003.A62
2603480003
|
£2.61
|
£3.13
|
|
|
706/30 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A359
2916011014
|
£1.75
|
£2.10
|
|
|
706/40 - O-RING 4.0x1.5 MM
BSD-1610210043.A61
1610210043
|
£1.75
|
£2.10
|
|
|
707 - WIDTH STOP
BSD-1608132007.A7
1608132007
|
-
|
|
|
|
707/10 - O-RING 4.0x1.5 MM
BSD-1610210043.A60
1610210043
|
£1.75
|
£2.10
|
|
|
707/20 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A358
2916011014
|
£1.75
|
£2.10
|
|
|
707/30 - WING SCREW M 6x16 MM
BSD-2603480003.A61
2603480003
|
£2.61
|
£3.13
|
|
|
707/40 - STOP BRACKET
BSD-1601332018.A13
1601332018
|
£3.72
|
£4.47
|
|
|
707/50 - ROUND-HEAD BOLT DIN 603-M6x25
BSD-2910281203.A203
2910281203
|
£2.61
|
£3.13
|
|
|
707/60 - WING NUT M6
BSD-1603339006.A327
1603339006
|
£2.52
|
£3.02
|
|
|
707/70 - ROUND-HEAD BOLT M6x15 DIN 603
BSD-2910281196.A6
2910281196
|
-
|
|
|
|
707/80 - STOP PLATE
BSD-1608000092.A36
1608000092
|
-
|
|
|
|
707/90 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A189
2916011010
|
£1.75
|
£2.10
|
|
|
707/100 - TUBULAR RIVET B 4x0.5x15 DIN 734
BSD-2917190492.A37
2917190492
|
-
|
|
|
|
707/110 - STOP BRACKET
BSD-1608000093.A13
1608000093
|
-
|
|
|
|
774 - PLANING KNIFE
BSD-2607000096.A19
2607000096
|
£7.57
|
£9.08
|
|
|
774 - CORRUGATED BLADE
BSD-1607000152.A5
1607000152
|
-
|
|
|
|
774 - CORRUGATED BLADE
BSD-1607000179.A5
1607000179
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014129.A107
1607014129
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3471
160111A3H3
|
£2.61
|
£3.13
|
|
