1 - HOUSING SECTION
BSD-2605104982.A1
2605104982
|
-
|
|
|
|
2 - ARMATURE 220-240V
BSD-2604010558.A1
2604010558
|
-
|
|
|
|
3 - BEARING BRACKET
BSD-2605807906.A4
2605807906
|
-
|
|
|
|
5 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A183
2600905021
|
£8.67
|
£10.41
|
|
|
6 - SCREW AND WASHER ASSEMBLY DIN7985-M4x18Z1-4.8
BSD-2914500009.A51
2914500009
|
-
|
|
|
|
8 - GUIDE SLEEVE
BSD-2600400024.A83
2600400024
|
£2.94
|
£3.53
|
|
|
9 - SUPPORTING DISC
BSD-2600103013.A26
2600103013
|
£1.32
|
£1.58
|
|
|
10 - FIELD 230V
BSD-2604220392.A46
2604220392
|
£25.05
|
£30.06
|
|
|
11 - SUPPRESSOR BOX
BSD-2604465035.A0
2604465035
|
-
|
|
|
|
13 - SINTERED-METAL BUSHING
BSD-1600301900.A225
1600301900
|
-
|
|
|
|
13/1 - FELT WASHER
BSD-1600205023.A212
1600205023
|
£1.38
|
£1.66
|
|
|
15 - O-RING 8.0x2.5 MM
BSD-1610210014.A206
1610210014
|
-
|
|
|
|
16 - HOLDING SPRING
BSD-1619P09928.A41
1619P09928
|
£1.75
|
£2.10
|
|
|
17 - ECCENTRIC COG WHEEL Z=39
BSD-2606319070.A6
2606319070
|
-
|
|
|
|
18 - SPRING WASHER
BSD-2600150050.A36
2600150050
|
£1.84
|
£2.21
|
|
|
19 - SHIM 0.5 MM
BSD-2600102658.A61
2600102658
|
£1.38
|
£1.66
|
|
|
19 - SHIM 0.2 MM
BSD-2600102656.A9
2600102656
|
£1.32
|
£1.58
|
|
|
20 - COUNTERWEIGHT
BSD-2601098005.A10
2601098005
|
£3.80
|
£4.56
|
|
|
21 - SHIM 0.3 MM
BSD-2600101083.A22
2600101083
|
-
|
|
|
|
22 - FORK LEVER
BSD-2601923003.A10
2601923003
|
-
|
|
|
|
23 - SHIM 0.3 MM
BSD-2600101654.A36
2600101654
|
£2.33
|
£2.80
|
|
|
24 - LOCKING WASHER DIN 6799-5-FSt
BSD-2916080008.A70
2916080008
|
-
|
|
|
|
25 - FIXING PLATE
BSD-2601030006.A80
2601030006
|
-
|
|
|
|
26 - LIFTING ROD
BSD-2600780038.A14
2600780038
|
-
|
|
|
|
27 - CLAMP SCREW
BSD-2603400000.A118
2603400000
|
£4.26
|
£5.11
|
|
|
28 - SINTERED-METAL BUSHING
BSD-2600302006.A25
2600302006
|
-
|
|
|
|
29 - SWITCH
BSD-2607200084.A82
2607200084
|
£10.10
|
£12.12
|
|
|
29 - SWITCH
BSD-2607200260.A359
2607200260
|
£11.87
|
£14.24
|
|
|
29 - SWITCH
BSD-2607200184.A50
2607200184
|
-
|
|
|
|
30 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1632
2603410001
|
£1.84
|
£2.21
|
|
|
31 - SUPPRESSION CAPACITOR
BSD-2607329120.A6
2607329120
|
-
|
|
|
|
32 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460427.A80
1604460427
|
£12.04
|
£14.45
|
|
|
33 - GROMMET dia6.4-dia7.5x75 MM
BSD-1600703016.A157
1600703016
|
£1.75
|
£2.10
|
|
|
33 - GROMMET dia9.5 MM
BSD-2600703006.A38
2600703006
|
-
|
|
|
|
34 - CABLE CLIP
BSD-2601035001.A2120
2601035001
|
£1.84
|
£2.21
|
|
|
35 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A484
2910611019
|
£2.94
|
£3.53
|
|
|
36 - NAMEPLATE
BSD-2601105051.A39
2601105051
|
-
|
|
|
|
37 - BASE PLATE
BSD-2601016012.A6
2601016012
|
£9.11
|
£10.93
|
|
|
38 - ROLLER LEVER
BSD-2601321900.A35
2601321900
|
-
|
|
|
|
39 - ROLLER LEVER
BSD-2601321901.A4
2601321901
|
-
|
|
|
|
41 - HEX NUT DIN 439-BM 4-04
BSD-2915051104.A39
2915051104
|
-
|
|
|
|
42 - HEX NUT
BSD-2603300009.A15
2603300009
|
-
|
|
|
|
43 - SOCKET HEAD CAP SCREW DIN 84-AM4x12-8.8
BSD-2910021122.A372
2910021122
|
£2.27
|
£2.72
|
|
|
44 - PROFILE BEADING
BSD-2602317025.A31
2602317025
|
-
|
|
|
|
46 - STICKER
BSD-2601110206.A3
2601110206
|
-
|
|
|
|
47 - STICKER
BSD-2601110207.A1
2601110207
|
-
|
|
|
|
48 - DAMPING PLATE
BSD-2601022000.A282
2601022000
|
£1.75
|
£2.10
|
|
|
49 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST
BSD-2912401020.A234
2912401020
|
£2.16
|
£2.59
|
|
|
50 - TAPPING SCREW DIN 7981-BZ3.9x9.5-A2
BSD-2910611417.A2
2910611417
|
-
|
|
|
|
51 - CONNECTING CABLE L = 298 MM
BSD-2604448032.A5
2604448032
|
-
|
|
|
|
52 - NEEDLE ROLLER A 3x9.8G2DIN 5402
BSD-1903201041.A41
1903201041
|
-
|
|
|
|
53 - SUPPORT PLATE
BSD-2602316900.A6
2602316900
|
-
|
|
|
|
54 - COMPRESSION SPRING
BSD-2604613000.A70
2604613000
|
£1.84
|
£2.21
|
|
|
56 - GUIDE
BSD-2601000034.A0
2601000034
|
-
|
|
|
|
57 - STRAIGHT PIN DIN 6325-4M6x24
BSD-2917530101.A44
2917530101
|
£2.80
|
£3.36
|
|
|
58 - STRAIGHT PIN 4M6x12DIN6325
BSD-2917530095.A25
2917530095
|
-
|
|
|
|
59 - SHIM 0.5 MM
BSD-2600101612.A345
2600101612
|
£1.84
|
£2.21
|
|
|
62 - NEEDLE BEARING
BSD-2600917900.A125
2600917900
|
£9.11
|
£10.93
|
|
|
63 - CONNECTING CABLE L = 278 MM
BSD-2604448012.A83
2604448012
|
£1.38
|
£1.66
|
|
|
64 - SEALING PLATE
BSD-2601015006.A14
2601015006
|
-
|
|
|
|
65 - SEALING PLATE
BSD-2601015900.A39
2601015900
|
-
|
|
|
|
66 - SWITCH HANDLE
BSD-2602026035.A23
2602026035
|
-
|
|
|
|
67 - RATCHET CAP
BSD-2600590006.A266
2600590006
|
£1.84
|
£2.21
|
|
|
68 - RATCHET CAP
BSD-2600590006.A267
2600590006
|
£1.84
|
£2.21
|
|
|
69 - SHIM 0.5 MM
BSD-2600100568.A3
2600100568
|
£1.84
|
£2.21
|
|
|
69 - SHIM 0.3 MM
BSD-2600100570.A102
2600100570
|
£1.84
|
£2.21
|
|
|
72 - STICKER
BSD-2601110041.A67
2601110041
|
-
|
|
|
|
73 - SPEED GOVERNOR 220-240V
BSD-2607230008.A1
2607230008
|
-
|
|
|
|
74 - CARB BRUSH HOLD W-SUPR
BSD-2604465076.A45
2604465076
|
-
|
|
|
|
75 - CONNECTING CABLE L=243 MM
BSD-2604448033.A29
2604448033
|
-
|
|
|
|
77 - SUPPORT PLATE
BSD-2601098006.A23
2601098006
|
£1.84
|
£2.21
|
|
|
78 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A831
2603490017
|
£2.27
|
£2.72
|
|
|
80 - REFERENCE PLATE
BSD-2601110307.A1
2601110307
|
-
|
|
|
|
85 - FAN
BSD-2606610047.A125
2606610047
|
-
|
|
|
|
812 - CARBON-BRUSH SET
BSD-2604321904.A215
2604321904
|
£10.61
|
£12.73
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A4540
160111A3H3
|
£2.74
|
£3.29
|
|
