Bosch PSS 180 AC / 0603366180 / EU 230 Volt Spare Parts

An exploded drawing and listing for the Bosch PSS 180 AC / 0603366180 / EU 230 Volt

	Ex VAT	Inc VAT
1 - HOUSING SECTION BSD-2605104642.A1 2605104642	£8.49	£10.19
2 - FIELD 230-240V BSD-2604220673.A1 2604220673	£14.75	£17.70
3 - ARMATURE 230-240V BSD-2604011276.A4 2604011276	£21.68	£26.01
4 - SWITCH BSD-2607200526.A14 2607200526	-
5 - POWER SUPPLY CORD EU 230V 2.7m 2 x 0.75mm H05 VV-F BSD-2604460259.A129 2604460259	£13.78	£16.54
6 - GROMMET BSD-2609002019.A40 2609002019	£2.74	£3.29
7 - TORX OVAL-HEAD SCREW 3x10 BSD-2603490017.A171 2603490017	£2.27	£2.72
9 - MANUFACTURER'S NAMEPLATE BSD-2601116146.A2 2601116146	-
10 - BRUSH PLATE BSD-2604337088.A9 2604337088	£11.87	£14.24
13 - GROOVE BALL BEARING BSD-2600905078.A52 2600905078	£6.52	£7.83
15 - FAN BSD-2606610113.A2 2606610113	£5.58	£6.70
19 - SCREW 4x16 BSD-2603490022.A2518 2603490022	£1.84	£2.21
21 - SANDER PLATE BSD-2608000238.A2 2608000238	-
24 - SEAL RING BSD-2600290039.A6 2600290039	£1.84	£2.21
25 - CONNECTING CABLE L=160 MM BSD-2604448247.A17 2604448247	-
26 - CONNECTING CABLE L=63 MM BSD-3604440527.A40 3604440527	£1.75	£2.10
28 - RUBBER BUFFER BSD-2609000549.A30 2609000549	£1.84	£2.21
50 - DUST CONTAINER BSD-2605411121.A38 2605411121	-
803 - ARMATURE 230V BSD-2604010988.A3 2604010988	-
808 - NAMEPLATE BSD-2601116601.A0 2601116601	-
811 - CARBON-BRUSH SET BSD-2604321925.A89 2604321925	£9.11	£10.93
817 - COVER PANEL BSD-2605500910.A4 2605500910	£5.26	£6.31
819 - GROOVE BALL BEARING 12x28x8 BSD-2600905045.A17 2600905045	£17.22	£20.67

Attribute Name	Value
Brand	Bosch
