2 - FIELD 220-230V
BSD-1604220354.A26
1604220354
|
£33.74
|
£40.49
|
|
|
5 - POWER SUPPLY CORD
BSD-3604460018.A7
3604460018
|
-
|
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A84
2600703013
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-2601035001.A1478
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110483.A166
1601110483
|
£2.61
|
£3.13
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A481
1607328028
|
£5.30
|
£6.36
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A1215
2600905032
|
£5.30
|
£6.36
|
|
|
14 - BALL BEARING 9x26x8
BSD-1900905025.A100
1900905025
|
£21.52
|
£25.83
|
|
|
16 - BRUSH HOLDER
BSD-3604336001.A14
3604336001
|
-
|
|
|
|
20 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1270
2603410001
|
£1.75
|
£2.10
|
|
|
23 - SEALING CAP
BSD-3605500084.A49
3605500084
|
-
|
|
|
|
24 - PROTECTIVE SHIELD
BSD-3602311018.A39
3602311018
|
-
|
|
|
|
25 - GEAR COVER
BSD-3605500082.A7
3605500082
|
£14.72
|
£17.67
|
|
|
26 - PROTECTIVE COVER
BSD-3605500037.A41
3605500037
|
-
|
|
|
|
27 - COVER STRIP
BSD-3601012000.A29
3601012000
|
-
|
|
|
|
28 - INTERMEDIATE RING
BSD-1600502011.A166
1600502011
|
£2.61
|
£3.13
|
|
|
32 - CONICAL SPRING WASHER
BSD-3600190007.A35
3600190007
|
-
|
|
|
|
33 - INTERMEDIATE RING
BSD-1600206026.A52
1600206026
|
£1.75
|
£2.10
|
|
|
34 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A63
1600290016
|
£2.61
|
£3.13
|
|
|
35 - INTERMEDIATE RING
BSD-1600300090.A134
1600300090
|
£3.72
|
£4.47
|
|
|
36 - CYLINDRICAL GEAR Z=41
BSD-3606317021.A32
3606317021
|
-
|
|
|
|
37 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A573
1600910018
|
£5.30
|
£6.36
|
|
|
38 - DRIVE SHAFT
BSD-3603124011.A33
3603124011
|
-
|
|
|
|
39 - SINTERED-METAL BUSHING L16G7x22R6x16DIN1850
BSD-1900322047.A0
1900322047
|
£3.80
|
£4.56
|
|
|
41 - SPRING RETAINING RING DIN 471-12x1-FSt
BSD-2916650003.A307
2916650003
|
£1.75
|
£2.10
|
|
|
42 - ROTARY SHAFT LIP SEAL
BSD-1600283003.A75
1600283003
|
£4.26
|
£5.11
|
|
|
43 - OIL RESERVOIR
BSD-3607030320.A31
3607030320
|
-
|
|
|
|
47 - STUD BOLT
BSD-3603121004.A14
3603121004
|
-
|
|
|
|
48 - SWIVELLING LEVER
BSD-3601990001.A38
3601990001
|
-
|
|
|
|
55 - COILED SPRING
BSD-3604651002.A11
3604651002
|
£1.32
|
£1.58
|
|
|
56 - PVC-INSULATED CABLE
BSD-3604431014.A9
3604431014
|
-
|
|
|
|
57 - CONNECTING CABLE L=180 MM
BSD-3604431012.A46
3604431012
|
-
|
|
|
|
58 - BLADE TERMINAL
BSD-1604477005.A161
1604477005
|
£2.61
|
£3.13
|
|
|
61 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A679
2915011007
|
-
|
|
|
|
62 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A216
2910611019
|
£2.80
|
£3.36
|
|
|
63 - SOCKET HEAD CAP SCREW
BSD-3603410001.A36
3603410001
|
-
|
|
|
|
64 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x25-8.8
BSD-2910141203.A88
2910141203
|
£1.75
|
£2.10
|
|
|
67 - TAPPING SCREW DIN 7971-B 3.9x19
BSD-2910211220.A136
2910211220
|
-
|
|
|
|
68 - THREAD-FORMING TAP. SCREW DIN 7500-CM 5x12-ST
BSD-2914411403.A39
2914411403
|
-
|
|
|
|
69 - COVER PLATE
BSD-3600000006.A55
3600000006
|
-
|
|
|
|
70 - SINTERED-METAL BUSHING J8G7x12r6x6DIN1850
BSD-1900301010.A20
1900301010
|
-
|
|
|
|
71 - HOSE
BSD-3600703001.A40
3600703001
|
-
|
|
|
|
72 - BALL DIN 5401-4 MM-III-ST
BSD-1903230007.A119
1903230007
|
£1.75
|
£2.10
|
|
|
74 - CONNECTING CABLE L=260 MM
BSD-3604431013.A8
3604431013
|
-
|
|
|
|
75 - COMPRESSION SPRING
BSD-3604630000.A14
3604630000
|
-
|
|
|
|
78 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A10
1907950006
|
£4.26
|
£5.11
|
|
|
79 - REFERENCE PLATE
BSD-3601119019.A9
3601119019
|
-
|
|
|
|
80 - REFERENCE PLATE
BSD-3601119021.A6
3601119021
|
-
|
|
|
|
87 - PLAIN WASHER 0.5 MM
BSD-1600101023.A130
1600101023
|
£1.75
|
£2.10
|
|
|
88 - DETENT PIN
BSD-3603121003.A43
3603121003
|
-
|
|
|
|
90 - MICROENCAPSULATED SCREW DIN 84-AM4x12-8.8
BSD-2914552107.A27
2914552107
|
£1.75
|
£2.10
|
|
|
90 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A447
2910211006
|
£1.75
|
£2.10
|
|
|
91 - OIL RESERVOIR
BSD-3607030320.A26
3607030320
|
-
|
|
|
|
650 - PROTECTIVE COVER
BSD-3605500038.A17
3605500038
|
-
|
|
|
|
745 - GUIDE RAIL 350 MM
BSD-3602317035.A11
3602317035
|
£33.45
|
£40.14
|
|
|
746 - SAW CHAIN 350 MM
BSD-3604730003.A18
3604730003
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014129.A13
1607014129
|
£16.41
|
£19.69
|
|
|
801 - SPIRAL SPRING
BSD-2604652008.A51
2604652008
|
-
|
|
|
|
804 - ON-OFF SWITCH
BSD-1607000231.A36
1607000231
|
£18.96
|
£22.75
|
|
|
805 - MOTOR HOUSING
BSD-3605108137.A14
3605108137
|
-
|
|
|
|
821 - HOUSING SECTION
BSD-3605190163.A31
3605190163
|
£51.22
|
£61.47
|
|
|
830 - ARMATURE 220V
BSD-3604010037.A22
3604010037
|
-
|
|
|
|
831 - AIR-DEFLECTOR RING
BSD-3600591002.A21
3600591002
|
-
|
|
|
|
840 - SPROCKET WHEEL
BSD-3607031199.A22
3607031199
|
-
|
|
|
|
844 - OIL RESERVOIR
BSD-3607030320.A25
3607030320
|
-
|
|
|
|
853 - BRAKING DEVICE
BSD-3607031182.A9
3607031182
|
-
|
|
|
|
873 - SPINDLE WITH GEAR Z=38
BSD-3606317031.A9
3606317031
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A2643
160111A3H3
|
£2.61
|
£3.13
|
|
