2 - FIELD 230V
BSD-2604220392.A71
2604220392
|
£25.05
|
£30.06
|
|
|
3 - ARMATURE 220-230V
BSD-2604010604.A2
2604010604
|
-
|
|
|
|
4 - ON-OFF SWITCH
BSD-2607200147.A8
2607200147
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 0.4m 2 x 1.0mm H05 VV-F
BSD-1604460437.A48
1604460437
|
£7.72
|
£9.27
|
|
|
6 - GROMMET dia6.4-dia7.5x75 MM
BSD-1600703016.A87
1600703016
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A168
2600703007
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2900
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601110297.A3
2601110297
|
-
|
|
|
|
12 - SUPPRESSION CAPACITOR
BSD-2607329108.A17
2607329108
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A159
1607328028
|
£5.57
|
£6.68
|
|
|
13 - SINTERED-METAL BUSHING
BSD-1600301900.A119
1600301900
|
-
|
|
|
|
14 - GROOVE BALL BEARING dia9 MM
BSD-2600905003.A8
2600905003
|
-
|
|
|
|
16 - BRUSH HOLDER
BSD-2604330016.A6
2604330016
|
-
|
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2292
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A2699
2603490022
|
£1.84
|
£2.21
|
|
|
20 - STICKER
BSD-2601110637.A24
2601110637
|
-
|
|
|
|
25 - CABLE L=173 MM
BSD-2604448060.A189
2604448060
|
-
|
|
|
|
26 - CONNECTING CABLE
BSD-2604465044.A8
2604465044
|
-
|
|
|
|
27 - CONNECTING CABLE
BSD-2604448059.A11
2604448059
|
-
|
|
|
|
28 - CABLE L=249 MM
BSD-2604448057.A50
2604448057
|
£1.38
|
£1.66
|
|
|
29 - CABLE
BSD-2604448058.A0
2604448058
|
-
|
|
|
|
30 - CARB BRUSH HOLD W-SUPR
BSD-2604465076.A27
2604465076
|
-
|
|
|
|
31 - FELT WASHER
BSD-1600205023.A161
1600205023
|
£1.38
|
£1.66
|
|
|
32 - O-RING 8.0x2.5 MM
BSD-1610210014.A64
1610210014
|
-
|
|
|
|
34 - SPACER RING
BSD-2600200023.A21
2600200023
|
-
|
|
|
|
35 - SPRING RETAINING RING 30x1.2MM. DIN 472
BSD-2916660012.A10
2916660012
|
£1.75
|
£2.10
|
|
|
36 - GROOVE BALL BEARING
BSD-2600900003.A36
2600900003
|
-
|
|
|
|
37 - PLAIN WASHER 5-ST
BSD-2916021011.A24
2916021011
|
-
|
|
|
|
38 - SPRING LOCK WASHER DIN 128-A5-FST
BSD-2916690004.A75
2916690004
|
£1.75
|
£2.10
|
|
|
39 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-5.8
BSD-2910011154.A15
2910011154
|
£1.84
|
£2.21
|
|
|
40 - FELT DISC
BSD-2600005001.A4
2600005001
|
-
|
|
|
|
41 - FELT STRIP
BSD-2601005008.A27
2601005008
|
-
|
|
|
|
42 - SUPPORT CLAMP
BSD-2608040021.A1
2608040021
|
-
|
|
|
|
43 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A666
1907950006
|
£4.48
|
£5.37
|
|
|
44 - DAMPING PLATE
BSD-2601022000.A21
2601022000
|
£1.75
|
£2.10
|
|
|
45/1 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A234
2603490023
|
£1.84
|
£2.21
|
|
|
45/1 - SOCKET HEAD CAP SCREW DIN 84-AM4x18-5.8
BSD-2910011128.A9
2910011128
|
£1.84
|
£2.21
|
|
|
46 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A821
2916690003
|
£1.75
|
£2.10
|
|
|
46/1 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A822
2916690003
|
£1.75
|
£2.10
|
|
|
47 - PAN HEAD SCREW M 4x20 MM
BSD-2603410016.A7
2603410016
|
-
|
|
|
|
47 - PAN HEAD SCREW M4x22 MM
BSD-2603410018.A11
2603410018
|
£1.75
|
£2.10
|
|
|
49 - COUNTERSUNK-HEAD SCREW DIN 965-M4x12-8.8
BSD-2910871122.A59
2910871122
|
-
|
|
|
|
50 - HEX SOCKET HEAD CAP SCREW
BSD-2603414041.A10
2603414041
|
-
|
|
|
|
51 - ECCENTRIC DISC
BSD-2602210007.A1
2602210007
|
-
|
|
|
|
52 - FELT DISC
BSD-2600005002.A19
2600005002
|
-
|
|
|
|
53 - COUNTERSUNK-HEAD SCREW
BSD-2603421003.A1
2603421003
|
-
|
|
|
|
54 - FELT STRIP
BSD-2601005002.A17
2601005002
|
-
|
|
|
|
55 - GEAR COVER
BSD-2605500115.A6
2605500115
|
-
|
|
|
|
56 - INTERMEDIATE FLANGE
BSD-2605700078.A6
2605700078
|
-
|
|
|
|
57 - PAN HEAD SCREW
BSD-2603413004.A10
2603413004
|
-
|
|
|
|
58 - SHIM 1.0 MM
BSD-2600100647.A19
2600100647
|
£1.32
|
£1.58
|
|
|
59 - HEX NUT DIN 985-M6-8
BSD-2915061004.A77
2915061004
|
£1.75
|
£2.10
|
|
|
62 - GUIDE
BSD-2601038021.A2
2601038021
|
-
|
|
|
|
65 - SPRING RETAINING RING DIN 471 9x1MM
BSD-2916640006.A32
2916640006
|
£1.84
|
£2.21
|
|
|
67 - STICKER
BSD-2601110685.A5
2601110685
|
-
|
|
|
|
70 - FAN
BSD-2606610047.A70
2606610047
|
-
|
|
|
|
75 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x16-8.8
BSD-2910142197.A4
2910142197
|
-
|
|
|
|
76 - SPRING WASHER DIN 137-A 6-ST
BSD-2916060007.A48
2916060007
|
£1.84
|
£2.21
|
|
|
653 - AUXILIARY HANDLE
BSD-2602025059.A8
2602025059
|
-
|
|
|
|
654 - PROTECTIVE SHIELD
BSD-2607001111.A28
2607001111
|
-
|
|
|
|
700 - DUST BAG
BSD-1605411023.A46
1605411023
|
-
|
|
|
|
701 - OIL SPRAY TIN
BSD-1609200399.A51
1609200399
|
£9.18
|
£11.01
|
|
|
800 - .
BSD-0603299004.A7
0603299004
|
-
|
|
|
|
801 - HOUSING SECTION
BSD-2605104180.A6
2605104180
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321909.A6
2604321909
|
£8.92
|
£10.70
|
|
|
813 - SINTERED-METAL BUSHING
BSD-1600301900.A121
1600301900
|
-
|
|
|
|
833 - BEARING BRACKET
BSD-2605807910.A3
2605807910
|
-
|
|
|
|
848 - OVERLOAD CLUTCH
BSD-2606320031.A0
2606320031
|
-
|
|
|
|
860 - SET OF KNIVES
BSD-2607001040.A4
2607001040
|
-
|
|
|
|
860 - SET OF KNIVES
BSD-2607001040.A5
2607001040
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3588
160111A3H3
|
£2.74
|
£3.29
|
|
