2 - FIELD 230-240V
BSD-2604220480.A33
2604220480
|
£21.68
|
£26.01
|
|
|
3/50 - FAN
BSD-2606610049.A139
2606610049
|
£2.16
|
£2.59
|
|
|
4 - ON-OFF SWITCH
BSD-2607200261.A15
2607200261
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1604460403.A128
1604460403
|
£16.41
|
£19.69
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A193
2600703007
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2766
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601110803.A4
2601110803
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A134
1607328028
|
£5.30
|
£6.36
|
|
|
13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A634
1610905025
|
£6.52
|
£7.83
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A234
2600905052
|
£7.36
|
£8.83
|
|
|
16 - BRUSH HOLDER
BSD-2604449027.A61
2604449027
|
£1.75
|
£2.10
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2143
2603410001
|
£1.75
|
£2.10
|
|
|
19 - SCREW 4x16
BSD-2603490022.A2616
2603490022
|
£1.75
|
£2.10
|
|
|
20 - MANUFACTURER'S NAMEPLATE
BSD-1601110481.A484
1601110481
|
£2.16
|
£2.59
|
|
|
25 - SHIM 0.5 MM
BSD-2600100588.A123
2600100588
|
£1.75
|
£2.10
|
|
|
26 - TOOTHED BELT WHEEL Z=19
BSD-2600324009.A22
2600324009
|
£2.52
|
£3.02
|
|
|
27 - TOOTHED BELT WHEEL Z=43
BSD-2606625009.A43
2606625009
|
£3.34
|
£4.01
|
|
|
28 - TOOTHED BELT 14 MM
BSD-1604736004.A13
1604736004
|
-
|
|
|
|
29 - RUBBER RING
BSD-1600206025.A270
1600206025
|
£2.16
|
£2.59
|
|
|
30 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A256
2603490017
|
£2.16
|
£2.59
|
|
|
31 - TAB WASHER
BSD-1600190016.A58
1600190016
|
-
|
|
|
|
32 - AIR-DEFLECTOR RING
BSD-1600591006.A5
1600591006
|
-
|
|
|
|
33 - GEAR COVER
BSD-1605510140.A7
1605510140
|
-
|
|
|
|
36 - PROTECTIVE COVER
BSD-1605510142.A14
1605510142
|
-
|
|
|
|
37 - ADJUSTING DISC
BSD-2608000059.A19
2608000059
|
-
|
|
|
|
39 - GRADUATED DIAL
BSD-2606621001.A33
2606621001
|
-
|
|
|
|
40 - HEX SCREW
BSD-3603450005.A3
3603450005
|
-
|
|
|
|
41 - REC CT-SUNK TAPPING SCREW DIN7982-ST3.9x19-C-H
BSD-2910601320.A21
2910601320
|
£1.32
|
£1.58
|
|
|
42 - COMPRESSION SPRING
BSD-1604619017.A56
1604619017
|
£2.16
|
£2.59
|
|
|
43 - ADJUSTING NUT
BSD-3603342003.A35
3603342003
|
£1.75
|
£2.10
|
|
|
44 - SHIM 0.5 MM
BSD-3600100005.A21
3600100005
|
-
|
|
|
|
47 - PROTECTIVE COVER
BSD-1605510139.A15
1605510139
|
-
|
|
|
|
48 - COMPRESSION SPRING
BSD-1604651007.A44
1604651007
|
-
|
|
|
|
49 - CONNECTING CABLE L = 288 MM
BSD-2604448062.A44
2604448062
|
£1.32
|
£1.58
|
|
|
50 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A211
2915011007
|
-
|
|
|
|
51 - ADJUSTING SLIDE
BSD-1601099011.A19
1601099011
|
-
|
|
|
|
52 - RUBBER BAND
BSD-1601006006.A16
1601006006
|
-
|
|
|
|
53 - SQUARE NUT M6
BSD-2603320004.A95
2603320004
|
£1.75
|
£2.10
|
|
|
54 - SINGLE-HEAD ENG. WRENCH
BSD-2607950504.A63
2607950504
|
£2.52
|
£3.02
|
|
|
55 - INTERMEDIATE RING
BSD-1600502011.A416
1600502011
|
£2.61
|
£3.13
|
|
|
56 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A118
2600910001
|
£4.26
|
£5.11
|
|
|
58 - SLOTTED SPRING PIN 3x5 DIN 1481
BSD-2917760073.A28
2917760073
|
-
|
|
|
|
59 - HANDLE PLATE
BSD-2605500086.A3
2605500086
|
-
|
|
|
|
59 - HANDLE COVER
BSD-2605500087.A1
2605500087
|
-
|
|
|
|
60 - SHIM 0.8 MM
BSD-1610100605.A59
1610100605
|
-
|
|
|
|
61 - SCALE WINDOW
BSD-1601099010.A21
1601099010
|
-
|
|
|
|
62 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A237
2600905052
|
£7.36
|
£8.83
|
|
|
63 - SHIM 0.2 MM
BSD-1600100632.A363
1600100632
|
£1.75
|
£2.10
|
|
|
72 - SQUARE NUT M8
BSD-2603320003.A24
2603320003
|
£1.75
|
£2.10
|
|
|
73 - ROUND NUT M6
BSD-2603342006.A28
2603342006
|
£1.75
|
£2.10
|
|
|
75 - RUBBER BUFFER
BSD-1603100036.A1
1603100036
|
£1.75
|
£2.10
|
|
|
211 - REFERENCE PLATE
BSD-1601110058.A184
1601110058
|
£1.75
|
£2.10
|
|
|
771 - GRIP-SPRING TENSIONING E
BSD-2608040039.A40
2608040039
|
£21.68
|
£26.01
|
|
|
774 - PLANING KNIFE
BSD-2607000096.A37
2607000096
|
£7.57
|
£9.08
|
|
|
801 - HOUSING SECTION
BSD-2605104888.A4
2605104888
|
-
|
|
|
|
803 - ARMATURE 230V
BSD-2604010763.A24
2604010763
|
-
|
|
|
|
810 - CARBON-BRUSH SET
BSD-2604321905.A217
2604321905
|
£11.30
|
£13.56
|
|
|
834 - COVERING HOOD
BSD-1605510141.A14
1605510141
|
-
|
|
|
|
870 - PLANER HEAD
BSD-2603204903.A1
2603204903
|
-
|
|
|
|
877 - COVER
BSD-2605510036.A17
2605510036
|
-
|
|
|
|
885 - SLOTTED SPRING PIN
BSD-1600410003.A30
1600410003
|
-
|
|
|
|
886 - SET SCREW
BSD-2603400014.A20
2603400014
|
-
|
|
|
|
887 - HEX SCREW
BSD-2603450005.A7
2603450005
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A3437
160111A3H3
|
£2.61
|
£3.13
|
|
