1 - HOUSING SECTION
BSD-2605104868.A0
2605104868
|
-
|
|
|
|
2 - FIELD 240V
BSD-2604220411.A12
2604220411
|
£22.76
|
£27.31
|
|
|
3 - ARMATURE 220-230V
BSD-2604010648.A13
2604010648
|
-
|
|
|
|
3/60 - FAN
BSD-1606610116.A164
1606610116
|
£2.64
|
£3.17
|
|
|
4 - ON-OFF SWITCH
BSD-2607200261.A6
2607200261
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05 VV-F
BSD-1604460427.A114
1604460427
|
£12.04
|
£14.45
|
|
|
6 - GROMMET dia7 MM
BSD-2600703007.A208
2600703007
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2794
2601035001
|
£1.84
|
£2.21
|
|
|
9 - STICKER
BSD-2601118203.A0
2601118203
|
-
|
|
|
|
10 - CARBON-BRUSH SET
BSD-2607014001.A74
2607014001
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A71
1607328028
|
£5.57
|
£6.68
|
|
|
13 - NEEDLE BEARING
BSD-2600910005.A17
2600910005
|
-
|
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-2600905052.A309
2600905052
|
£7.72
|
£9.27
|
|
|
16 - BRUSH HOLDER
BSD-2604449026.A18
2604449026
|
£1.84
|
£2.21
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2082
2603410001
|
£1.84
|
£2.21
|
|
|
19 - SCREW 4x16
BSD-2603490022.A2629
2603490022
|
£1.84
|
£2.21
|
|
|
25 - TOOTHED BELT
BSD-2604736001.A23
2604736001
|
£10.61
|
£12.73
|
|
|
26 - RUBBER RING
BSD-1600206025.A248
1600206025
|
£2.16
|
£2.59
|
|
|
27 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A197
2603490017
|
£2.27
|
£2.72
|
|
|
28 - TAB WASHER
BSD-1600190016.A36
1600190016
|
-
|
|
|
|
29 - AIR-DEFLECTOR RING
BSD-2600290004.A10
2600290004
|
£2.16
|
£2.59
|
|
|
30 - COVERING HOOD
BSD-2605500163.A6
2605500163
|
£11.30
|
£13.56
|
|
|
33 - ADJUSTING SLIDE
BSD-2608000012.A6
2608000012
|
-
|
|
|
|
34 - BASE PLATE
BSD-1608000091.A13
1608000091
|
-
|
|
|
|
35 - NEEDLE BEARING dia8xdia12x10 MM
BSD-1610910057.A81
1610910057
|
£2.80
|
£3.36
|
|
|
36 - HEX SCREW DIN 933-M6x40-8.8
BSD-2911061209.A2
2911061209
|
-
|
|
|
|
37 - HANDLE
BSD-2602026041.A5
2602026041
|
-
|
|
|
|
38 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A410
2607950004
|
£1.84
|
£2.21
|
|
|
39 - ROUND NUT M6
BSD-2603342006.A20
2603342006
|
£1.84
|
£2.21
|
|
|
40 - NUT M 8
BSD-2603342010.A6
2603342010
|
£2.74
|
£3.29
|
|
|
41 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A159
2915011007
|
-
|
|
|
|
42 - TOOTHED BELT WHEEL Z= 18
BSD-2606625001.A6
2606625001
|
£3.99
|
£4.79
|
|
|
43 - TOOTHED BELT WHEEL Z=28
BSD-2606625002.A11
2606625002
|
£6.85
|
£8.22
|
|
|
44 - CONNECTING CABLE L = 288 MM
BSD-2604448062.A51
2604448062
|
£1.38
|
£1.66
|
|
|
45 - PLAIN WASHER
BSD-2600100029.A5
2600100029
|
-
|
|
|
|
46 - PLAIN WASHER DIN 125-A 6.4-ST
BSD-2916011014.A408
2916011014
|
£1.84
|
£2.21
|
|
|
47 - COMPRESSION SPRING
BSD-2604611010.A7
2604611010
|
£2.27
|
£2.72
|
|
|
50 - PLANER HEAD
BSD-2608584002.A12
2608584002
|
-
|
|
|
|
51 - PRESSURE PLATE
BSD-2602316000.A20
2602316000
|
-
|
|
|
|
52 - CLAMPING JAW
BSD-2605510007.A16
2605510007
|
-
|
|
|
|
54 - HEX SOCKET HEAD CAP SCREW
BSD-2603414027.A11
2603414027
|
-
|
|
|
|
55 - PLANING KNIFE
BSD-1608635039.A0
1608635039
|
-
|
|
|
