1 - HOUSING SECTION
BSD-2605104323.A0
2605104323
|
-
|
|
|
|
2 - FIELD 230-240V
BSD-2604220507.A11
2604220507
|
£15.49
|
£18.59
|
|
|
3 - ARMATURE 220V
BSD-2604010750.A4
2604010750
|
-
|
|
|
|
3/50 - FAN
BSD-2606610055.A64
2606610055
|
£4.26
|
£5.11
|
|
|
4 - ON-OFF SWITCH
BSD-2607200376.A20
2607200376
|
-
|
|
|
|
5 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H05VV-F
BSD-2604460125.A63
2604460125
|
£8.49
|
£10.19
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703031.A9
2600703031
|
-
|
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2232
2601035001
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-2601110978.A0
2601110978
|
-
|
|
|
|
13 - NEEDLE BEARING
BSD-2600917002.A98
2600917002
|
£3.72
|
£4.47
|
|
|
14 - GROOVE BALL BEARING
BSD-2600905034.A32
2600905034
|
£13.12
|
£15.75
|
|
|
16 - BRUSH PLATE
BSD-2604337118.A74
2604337118
|
£23.86
|
£28.63
|
|
|
18 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A1740
2603410001
|
£1.84
|
£2.21
|
|
|
19 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A180
2603490021
|
£1.84
|
£2.21
|
|
|
25 - PLAIN WASHER DIN 315-M8-GT-C
BSD-2600100041.A125
2600100041
|
£1.84
|
£2.21
|
|
|
26 - FAN
BSD-2606610057.A6
2606610057
|
-
|
|
|
|
27 - CARRIER
BSD-2600328016.A4
2600328016
|
-
|
|
|
|
28 - SQUARE NUT DIN 562-M6-04
BSD-2915121006.A12
2915121006
|
£2.61
|
£3.13
|
|
|
29 - WASHER
BSD-2600190059.A4
2600190059
|
£3.34
|
£4.01
|
|
|
29 - SPRING RETAINING RING
BSD-2600116014.A11
2600116014
|
£1.84
|
£2.21
|
|
|
30 - GROOVE BALL BEARING 15x35x11
BSD-2600905111.A15
2600905111
|
£12.64
|
£15.17
|
|
|
35 - HEX SOCKET HEAD CAP SCREW DIN 7984-M6x16-10.9
BSD-2910975197.A8
2910975197
|
-
|
|
|
|
36 - O-RING 5.0x1.5 MM
BSD-1900210000.A293
1900210000
|
£1.84
|
£2.21
|
|
|
37 - BEARING SLEEVE
BSD-2600222002.A45
2600222002
|
-
|
|
|
|
38 - CONNECTING CABLE L=115 MM
BSD-2604448109.A80
2604448109
|
£1.75
|
£2.10
|
|
|
39 - CABLE L=103MM
BSD-2604448140.A10
2604448140
|
£1.32
|
£1.58
|
|
|
40 - DAMPING PLATE
BSD-2601022000.A231
2601022000
|
£1.75
|
£2.10
|
|
|
41 - CABLE L=233 MM
BSD-1614431010.A39
1614431010
|
£3.72
|
£4.47
|
|
|
42 - PLAIN WASHER
BSD-2600190150.A15
2600190150
|
-
|
|
|
|
43 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A675
2603490023
|
£1.84
|
£2.21
|
|
|
654 - DUST BAG
BSD-2605411019.A1
2605411019
|
-
|
|
|
|
655 - FITTING
BSD-2605702012.A7
2605702012
|
-
|
|
|
|
656 - OFFSET SCREWDRIVER DIN 911-4
BSD-2607950004.A265
2607950004
|
£1.84
|
£2.21
|
|
|
750 - HANDLE M6x15 MM
BSD-2602026046.A27
2602026046
|
-
|
|
|
|
751 - BACKING PAD dia 115 MM
BSD-2608601065.A15
2608601065
|
£10.10
|
£12.12
|
|
|
752 - SUCTION HOOD dia 115 MM
BSD-2600282008.A1
2600282008
|
-
|
|
|
|
754 - POLISHING CAP dia 125 MM
BSD-2608610006.A0
2608610006
|
-
|
|
|
|
755 - POLISHING SPONGE dia 125 MM
BSD-2608613008.A1
2608613008
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3HC.A222
160111A3HC
|
£2.74
|
£3.29
|
|
|
816/04 - CARBON-BRUSH SET
BSD-2604321917.A50
2604321917
|
-
|
|
|
|
816/05 - COMPRESSION SPRING
BSD-2604610026.A16
2604610026
|
£2.61
|
£3.13
|
|
|
816/06 - RATCHET CAP
BSD-2601329051.A27
2601329051
|
£2.33
|
£2.80
|
|
|
816/06 - RATCHET CAP
BSD-2601322013.A460
2601322013
|
£1.84
|
£2.21
|
|
