2 - FIELD 230V
BSD-1614220182.A11
1614220182
|
£18.96
|
£22.75
|
|
|
4 - ON-OFF SWITCH
BSD-1617200515.A7
1617200515
|
£16.39
|
£19.67
|
|
|
5 - POWER SUPPLY CORD CH 2.65m 2 x 1.0mm H07 RN-F
BSD-1604460448.A32
1604460448
|
£18.96
|
£22.75
|
|
|
6 - GROMMET dia7.3-dia8.6x76 MM
BSD-2600703018.A52
2600703018
|
£2.61
|
£3.13
|
|
|
7 - CABLE CLIP
BSD-1611035007.A13
1611035007
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE PBH 2000 RE
BSD-1619P00861.A1
1619P00861
|
£3.34
|
£4.01
|
|
|
9 - MANUFACTURER'S NAMEPLATE PBH 2000 SRE
BSD-1619P00860.A4
1619P00860
|
£3.34
|
£4.01
|
|
|
10 - MANUFACTURER'S NAMEPLATE
BSD-1619P00830.A5
1619P00830
|
£2.52
|
£3.02
|
|
|
12 - SUPPRESSION FILTER
BSD-1617328032.A58
1617328032
|
£7.36
|
£8.83
|
|
|
14 - BEARING BRACKET
BSD-1615806187.A33
1615806187
|
£2.16
|
£2.59
|
|
|
15 - DAMPING RUBBER
BSD-2603100056.A266
2603100056
|
£1.75
|
£2.10
|
|
|
17 - SEALING FRAME
BSD-1611015054.A16
1611015054
|
£6.52
|
£7.83
|
|
|
19 - O-RING 22.0x2.5 MM
BSD-1610210184.A33
1610210184
|
£1.75
|
£2.10
|
|
|
21 - HAMMER PIPE
BSD-1615806188.A15
1615806188
|
£27.23
|
£32.68
|
|
|
22 - PINION
BSD-1616317073.A1
1616317073
|
£4.75
|
£5.70
|
|
|
23 - CYLINDRICAL GEAR
BSD-1616317070.A16
1616317070
|
£8.67
|
£10.41
|
|
|
24 - TRANSMISSION SHAFT
BSD-1613101010.A15
1613101010
|
£5.58
|
£6.70
|
|
|
25 - COUPLING HUB
BSD-1616409023.A10
1616409023
|
£2.80
|
£3.36
|
|
|
27 - STRIKER
BSD-1618710085.A25
1618710085
|
£10.10
|
£12.12
|
|
|
28 - STRIKER PIN
BSD-1613124084.A33
1613124084
|
£4.26
|
£5.11
|
|
|
29 - PISTON PIN
BSD-1613100034.A41
1613100034
|
£2.80
|
£3.36
|
|
|
31 - RETAINING RING
BSD-1614601053.A16
1614601053
|
£1.75
|
£2.10
|
|
|
33 - SWITCHING ELEMENT
BSD-1610322013.A2
1610322013
|
£1.95
|
£2.34
|
|
|
34 - BALL BEARING 8x22x6
BSD-1610905034.A17
1610905034
|
£6.52
|
£7.83
|
|
|
36 - HOLDING PLATE
BSD-1610551008.A34
1610551008
|
£2.61
|
£3.13
|
|
|
37 - GUIDE DISC
BSD-1610100016.A121
1610100016
|
£1.75
|
£2.10
|
|
|
38 - CYLINDRICAL GEAR
BSD-1619P13665.A16
1619P13665
|
£7.36
|
£8.83
|
|
|
39 - RETAINING RING
BSD-1614601055.A16
1614601055
|
£1.75
|
£2.10
|
|
|
40 - STRAIGHT PIN
BSD-1613100032.A42
1613100032
|
£1.75
|
£2.10
|
|
|
41 - RATCHET DISC
BSD-1610102072.A42
1610102072
|
£5.58
|
£6.70
|
|
|
42 - PLAIN BEARING
BSD-1610301004.A16
1610301004
|
£3.72
|
£4.47
|
|
|
44 - SUPPORT DISC
BSD-1610190054.A13
1610190054
|
£2.49
|
£2.99
|
|
|
46 - COMPRESSION SPRING
BSD-1614630002.A15
1614630002
|
£3.72
|
£4.47
|
|
|
47 - BALL BEARING
BSD-1610905035.A14
1610905035
|
£18.96
|
£22.75
|
|
|
48 - RETAINING RING
BSD-1614601054.A24
1614601054
|
£1.75
|
£2.10
|
|
|
49 - RETAINING RING
BSD-1619P00829.A2
1619P00829
|
£1.75
|
£2.10
|
|
|
50 - THRUST RING
BSD-1600A00FL3.A23
1600A00FL3
|
£2.80
|
£3.36
|
|
|
51 - SHIFT PLATE
BSD-1613231013.A2
1613231013
|
-
|
|
|
|
52 - COILED SPRING
BSD-1619P01789.A14
1619P01789
|
£1.75
|
£2.10
|
|
|
53 - PRESSURE DISC
BSD-1619P00828.A29
1619P00828
|
£1.75
|
£2.10
|
|
|
54 - GUIDE ROD
BSD-1613100033.A15
1613100033
|
£1.75
|
£2.10
|
|
|
55 - PROTECTIVE CAP
BSD-1610508052.A45
1610508052
|
£1.75
|
£2.10
|
|
|
60 - SPRING RETAINING RING
BSD-3600224038.A62
3600224038
|
£1.32
|
£1.58
|
|
|
63 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A122
1903230013
|
£2.16
|
£2.59
|
|
|
66 - BALL BEARING 8x22x7
BSD-1900905029.A243
1900905029
|
£21.52
|
£25.83
|
|
|
67 - BALL BEARING
BSD-1610905033.A13
1610905033
|
£8.67
|
£10.41
|
|
|
68 - PLAIN WASHER
BSD-1614601052.A15
1614601052
|
£1.75
|
£2.10
|
|
|
69 - CHANGE-OVER SWITCH
BSD-1613231025.A1
1613231025
|
£1.75
|
£2.10
|
|
|
71 - TAPPING SCREW
BSD-1619P00219.A34
1619P00219
|
£1.75
|
£2.10
|
|
|
72 - TORX OVAL-HEAD SCREW 3x10
BSD-1619P00220.A19
1619P00220
|
£1.75
|
£2.10
|
|
|
73 - TORX OVAL-HEAD SCREW
BSD-2914201483.A7
2914201483
|
£1.75
|
£2.10
|
|
|
651 - AUXILIARY HANDLE
BSD-2602025125.A57
2602025125
|
£10.10
|
£12.12
|
|
|
652 - DEPTH-GAUGE
BSD-2609005615.A90
2609005615
|
£4.26
|
£5.11
|
|
|
655 - KEY CHUCK
BSD-1618571031.A16
1618571031
|
£33.74
|
£40.49
|
|
|
655/872 - CHUCK WRENCH SG2
BSD-2607950007.A1682
2607950007
|
£6.52
|
£7.83
|
|
|
801 - HOUSING SET
BSD-1619P01770.A3
1619P01770
|
-
|
|
|
|
803 - ARMATURE 220-240V
BSD-1619P01771.A0
1619P01771
|
£46.82
|
£56.18
|
|
|
808 - NAMEPLATE
BSD-1619P01702.A0
1619P01702
|
-
|
|
|
|
816 - CARBON-BRUSH SET
BSD-1619P01777.A0
1619P01777
|
£11.30
|
£13.56
|
|
|
818 - INTERMEDIATE FLANGE
BSD-1619P01772.A25
1619P01772
|
£13.12
|
£15.75
|
|
|
820 - SWITCH BUTTON
BSD-1619P01782.A3
1619P01782
|
£3.72
|
£4.47
|
|
|
821 - HAMMER PIPE
BSD-1619P01773.A6
1619P01773
|
£41.62
|
£49.95
|
|
|
822 - TRANSMISSION SHAFT
BSD-1619P01774.A3
1619P01774
|
-
|
|
|
|
826 - HAMMER PISTON
BSD-1618700083.A41
1618700083
|
£10.82
|
£12.99
|
|
|
830 - DRIVE BEARING
BSD-1619P01775.A0
1619P01775
|
£21.68
|
£26.01
|
|
|
832 - RUBBER BUSHING
BSD-1610508051.A10
1610508051
|
£4.26
|
£5.11
|
|
|
856 - PROTECTION SLEEVE
BSD-1619P02182.A20
1619P02182
|
£11.30
|
£13.56
|
|
|
865 - O-RING 13.0x3.0 MM
BSD-1610210244.A14
1610210244
|
£2.16
|
£2.59
|
|
|
870 - CONNECTING CABLE
BSD-1619P01776.A48
1619P01776
|
£5.58
|
£6.70
|
|
|
871 - HOUSING SET
BSD-1619P01766.A1
1619P01766
|
£52.15
|
£62.58
|
|
|
891 - LOCK
BSD-1619P00832.A1
1619P00832
|
£1.75
|
£2.10
|
|
