3 - SWITCH BUTTON
BSD-1609201656.A16
1609201656
|
-
|
|
|
|
4 - COVERING HOOD
BSD-1609202376.A12
1609202376
|
-
|
|
|
|
5 - SOCKET
BSD-1609200948.A17
1609200948
|
£21.52
|
£25.83
|
|
|
6 - TAPPING SCREW DIN 7983-ST3.9x19-C-H
BSD-2910612519.A27
2910612519
|
-
|
|
|
|
8 - ON-OFF SWITCH
BSD-1609201658.A19
1609201658
|
-
|
|
|
|
9 - TAPPING SCREW DIN 7971-B2.9x19
BSD-2910211208.A28
2910211208
|
-
|
|
|
|
10 - CLAMP
BSD-1609201659.A43
1609201659
|
-
|
|
|
|
11 - NAMEPLATE
BSD-1601110408.A0
1601110408
|
-
|
|
|
|
15 - CABLE
BSD-1609201665.A10
1609201665
|
-
|
|
|
|
16 - CABLE
BSD-1609201665.A11
1609201665
|
-
|
|
|
|
17 - AIR-DEFLECTOR RING
BSD-1609201666.A58
1609201666
|
-
|
|
|
|
20 - SEAL RING
BSD-1609201669.A113
1609201669
|
£5.87
|
£7.04
|
|
|
22 - SUCTION BLOWER 220V
BSD-1609202695.A31
1609202695
|
-
|
|
|
|
23 - AIR FILTER
BSD-1609201672.A9
1609201672
|
-
|
|
|
|
25 - AIR FILTER
BSD-1609201674.A54
1609201674
|
-
|
|
|
|
26 - INTERMEDIATE FLANGE
BSD-1609201714.A14
1609201714
|
-
|
|
|
|
31 - TAPPING SCREW DIN 7981-B3.5x25
BSD-2910611015.A217
2910611015
|
£1.84
|
£2.21
|
|
|
32 - MANUFACTURER'S NAMEPLATE
BSD-1601110388.A0
1601110388
|
-
|
|
|
|
35 - TAPPING SCREW 3.5x32 MM
BSD-1609201681.A62
1609201681
|
-
|
|
|
|
36 - AUTOMATIC SWITCHING UNIT
BSD-1609203C05.A60
1609203C05
|
-
|
|
|
|
37 - INTERMEDIATE HOUSING
BSD-1609201715.A3
1609201715
|
-
|
|
|
|
38 - FLOAT
BSD-1609200952.A105
1609200952
|
-
|
|
|
|
39 - SUCTION BASKET
BSD-1609201684.A37
1609201684
|
-
|
|
|
|
43 - AIR FILTER dia 148x188x165 MM
BSD-1609201636.A21
1609201636
|
-
|
|
|
|
43/20 - STAR KNOB
BSD-1609202200.A31
1609202200
|
-
|
|
|
|
47 - BENT-LEVER CLOSURE
BSD-1609201690.A55
1609201690
|
-
|
|
|
|
47/20 - SOCKET HEAD CAP SCREW DIN 84-AM6x12-8.8
BSD-2910021193.A11
2910021193
|
£1.84
|
£2.21
|
|
|
47/30 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A830
2915011007
|
-
|
|
|
|
51 - IMPELLER
BSD-1609201691.A8
1609201691
|
-
|
|
|
|
51/50 - HEX NUT DIN 934-M8-8-A
BSD-2915011009.A28
2915011009
|
£2.61
|
£3.13
|
|
|
52 - DUST CONTAINER
BSD-1609201716.A35
1609201716
|
-
|
|
|
|
54 - IMPELLER
BSD-1609202221.A63
1609202221
|
-
|
|
|
|
54 - IMPELLER
BSD-1609201693.A12
1609201693
|
-
|
|
|
|
54/42 - PLAIN WASHER dia4.2xdia11x1.2MM
BSD-1609202726.A58
1609202726
|
£1.75
|
£2.10
|
|
|
54/55 - PLAIN WASHER DIN 125-A 8.4-ST
BSD-2916011016.A70
2916011016
|
£1.84
|
£2.21
|
|
|
54/56 - TAPPING SCREW DIN 7981-B4.2x19
BSD-2910611027.A63
2910611027
|
-
|
|
|
|
651 - SUCTION PIPE dia 49 MM. L=0.5 M
BSD-1609200968.A34
1609200968
|
£12.24
|
£14.69
|
|
|
652 - SUCTION NOZZLE dia 49 MM
BSD-1609200969.A45
1609200969
|
-
|
|
|
|
653 - SUCTION NOZZLE dia 49 MM. 350 MM
BSD-1609200970.A34
1609200970
|
£26.24
|
£31.49
|
|
|
653/10 - FLAT BRUSH
BSD-1609201109.A66
1609201109
|
-
|
|
|
|
653/20 - FLAT BRUSH
BSD-1609201110.A61
1609201110
|
-
|
|
|
|
654 - CREVICE NOZZLE dia 49 MM
BSD-1609200971.A88
1609200971
|
£7.87
|
£9.44
|
|
|
655 - SUCTION PIPE dia 49/35 MM
BSD-1609200976.A51
1609200976
|
£3.61
|
£4.33
|
|
|
700 - CREVICE NOZZLE dia 35 MM. L= 250 MM
BSD-2607000165.A119
2607000165
|
£5.24
|
£6.29
|
|
|
702 - REDUCTION SLEEVE dia 49/35 MM+3/4
BSD-1609200933.A59
1609200933
|
£7.21
|
£8.65
|
|
|
703 - PAPER BAG
BSD-1609201628.A2
1609201628
|
£14.69
|
£17.63
|
|
|
704 - DUST SEPARATOR
BSD-2607432010.A0
2607432010
|
-
|
|
|
|
704/20 - COMPRESSION SPRING
BSD-2609200056.A1
2609200056
|
-
|
|
|
|
705 - GUIDE BRACKET
BSD-1609201627.A61
1609201627
|
-
|
|
|
|
705/20 - PARTS SET
BSD-1609201661.A41
1609201661
|
-
|
|
|
|
706 - NOZZLE SET
BSD-1609201236.A5
1609201236
|
-
|
|
|
|
706/10 - AIR HOSE dia 35 MM. L=5 M
BSD-1609202230.A90
1609202230
|
£85.74
|
£102.89
|
|
|
706/20 - SUCTION BRUSH
BSD-1609201271.A27
1609201271
|
-
|
|
|
|
706/30 - SUCTION BRUSH
BSD-1609201272.A1
1609201272
|
-
|
|
|
|
706/40 - SUCTION BRUSH
BSD-1609201273.A27
1609201273
|
-
|
|
|
|
706/50 - REDUCTION SLEEVE dia 49/35 MM+3/4
BSD-1609200933.A60
1609200933
|
£7.21
|
£8.65
|
|
|
707 - AIR HOSE dia 35 MM. 2 M.1
BSD-2607000163.A69
2607000163
|
-
|
|
|
|
707/1 - AIR HOSE dia 35 MM. L=5 M
BSD-1609202230.A91
1609202230
|
£85.74
|
£102.89
|
|
|
708 - SUCTION NOZZLE dia 35 MM
BSD-1609201229.A71
1609201229
|
£17.49
|
£20.99
|
|
|
709 - SUCTION NOZZLE dia 35 MM
BSD-1609201230.A67
1609201230
|
£41.99
|
£50.39
|
|
|
710 - FLAT SUCTION NOZZLE dia 35 MM-200 MM
BSD-1609201231.A22
1609201231
|
-
|
|
|
|
711 - SUCTION PIPE dia 35 MM. L=0.5 M
BSD-1609201232.A44
1609201232
|
-
|
|
|
|
712 - UPHOLSTERY NOZZLE dia 35 MM
BSD-1609201233.A22
1609201233
|
-
|
|
|
|
713 - SUCTION BRUSH
BSD-1609201234.A44
1609201234
|
-
|
|
|
|
714 - SUCTION NOZZLE dia 49 MM
BSD-1609201235.A22
1609201235
|
-
|
|
|
|
750 - AIR HOSE dia 49 MM. 3 M.1
BSD-2607000167.A91
2607000167
|
£67.98
|
£81.57
|
|
