4 - COVERING HOOD
BSD-1609202376.A4
1609202376
|
-
|
|
|
|
4/10 - SWITCH BUTTON
BSD-1609203721.A32
1609203721
|
-
|
|
|
|
6 - TAPPING SCREW DIN 7983-ST3.9x19-C-H
BSD-2910612519.A39
2910612519
|
-
|
|
|
|
9 - TAPPING SCREW DIN 7971-B2.9x19
BSD-2910211208.A34
2910211208
|
-
|
|
|
|
10 - CLAMP
BSD-1609201659.A37
1609201659
|
-
|
|
|
|
11 - NAMEPLATE
BSD-1601110887.A0
1601110887
|
-
|
|
|
|
15 - CARBON-BRUSH SET
BSD-1609201664.A7
1609201664
|
-
|
|
|
|
17 - AIR-DEFLECTOR RING
BSD-1609201666.A54
1609201666
|
-
|
|
|
|
20 - SEAL RING
BSD-1609201669.A117
1609201669
|
£5.87
|
£7.04
|
|
|
20/1 - SEAL RING
BSD-1609202374.A36
1609202374
|
-
|
|
|
|
22 - SUCTION BLOWER 220V
BSD-1609202695.A35
1609202695
|
-
|
|
|
|
23 - AIR FILTER
BSD-1609201672.A5
1609201672
|
-
|
|
|
|
25 - AIR FILTER
BSD-1609201674.A58
1609201674
|
-
|
|
|
|
26 - INTERMEDIATE FLANGE
BSD-1609202375.A3
1609202375
|
-
|
|
|
|
28 - AIR FILTER
BSD-1609202377.A3
1609202377
|
-
|
|
|
|
31 - TAPPING SCREW DIN 7981-B3.5x25
BSD-2910611015.A235
2910611015
|
£1.84
|
£2.21
|
|
|
32 - REFERENCE PLATE
BSD-1601110572.A11
1601110572
|
-
|
|
|
|
35 - TAPPING SCREW 3.5x32 MM
BSD-1609201681.A57
1609201681
|
-
|
|
|
|
35 - TAPPING SCREW DIN 7981-B3.5x25
BSD-2910611015.A234
2910611015
|
£1.84
|
£2.21
|
|
|
36 - AUTOMATIC SWITCHING UNIT
BSD-1609203C05.A50
1609203C05
|
-
|
|
|
|
37 - INTERMEDIATE HOUSING
BSD-1609201715.A15
1609201715
|
-
|
|
|
|
38 - FLOAT
BSD-1609200952.A95
1609200952
|
-
|
|
|
|
39 - SUCTION BASKET
BSD-1609201684.A42
1609201684
|
-
|
|
|
|
43 - AIR FILTER dia 148x188x165 MM
BSD-1609201636.A33
1609201636
|
-
|
|
|
|
43/20 - STAR KNOB
BSD-1609202200.A34
1609202200
|
-
|
|
|
|
43/30 - REFERENCE PLATE
BSD-1609110830.A3
1609110830
|
-
|
|
|
|
47 - BENT-LEVER CLOSURE
BSD-1609201690.A50
1609201690
|
-
|
|
|
|
47/20 - SOCKET HEAD CAP SCREW DIN 84-AM6x12-8.8
BSD-2910021193.A26
2910021193
|
£1.84
|
£2.21
|
|
|
47/30 - HEX NUT DIN 934-M6-8-A
BSD-2915011007.A815
2915011007
|
-
|
|
|
|
51 - IMPELLER
BSD-1609201691.A13
1609201691
|
-
|
|
|
|
51/50 - HEX NUT DIN 934-M8-8-A
BSD-2915011009.A43
2915011009
|
£2.61
|
£3.13
|
|
|
52 - DUST CONTAINER
BSD-1609201716.A18
1609201716
|
-
|
|
|
|
54 - IMPELLER
BSD-1609202221.A51
1609202221
|
-
|
|
|
|
54/42 - PLAIN WASHER dia4.2xdia11x1.2MM
BSD-1609202726.A138
1609202726
|
£1.75
|
£2.10
|
|
|
54/56 - TAPPING SCREW DIN 7981-B4.2x19
BSD-2910611027.A29
2910611027
|
-
|
|
|
|
55 - REFERENCE PLATE
BSD-1601110573.A0
1601110573
|
-
|
|
|
|
703 - PAPER BAG
BSD-1609201628.A5
1609201628
|
£14.69
|
£17.63
|
|
|
704 - DUST SEPARATOR
BSD-2607432010.A45
2607432010
|
-
|
|
|
|
705 - GUIDE BRACKET
BSD-1609201627.A30
1609201627
|
-
|
|
|
|
705/20 - PARTS SET
BSD-1609201661.A30
1609201661
|
-
|
|
|
|
750 - AIR HOSE dia 35 MM. 2 M.1
BSD-2607000163.A19
2607000163
|
-
|
|
|
|
750/1 - AIR HOSE dia 35 MM. L=5 M
BSD-1609202230.A64
1609202230
|
£85.74
|
£102.89
|
|
|
751 - SETTING TUBE dia 35 MM
BSD-2607000164.A56
2607000164
|
£23.68
|
£28.42
|
|
|
752 - SUCTION PIPE dia 35 MM. 0.5 M
BSD-2607000162.A62
2607000162
|
£29.38
|
£35.25
|
|
|
753 - SUCTION NOZZLE dia 35 MM
BSD-2607000170.A73
2607000170
|
£13.78
|
£16.53
|
|
|
754 - SUCTION NOZZLE dia 35 MM
BSD-1609390478.A71
1609390478
|
£34.99
|
£41.99
|
|
|
754/10 - FLAT BRUSH
BSD-1609390493.A79
1609390493
|
£21.68
|
£26.01
|
|
|
754/20 - FLAT BRUSH
BSD-1609390494.A22
1609390494
|
-
|
|
|
|
754/30 - STRIP BRUSH
BSD-1609390495.A79
1609390495
|
£16.41
|
£19.69
|
|
|
755 - CREVICE NOZZLE dia 35 MM. L= 250 MM
BSD-2607000165.A19
2607000165
|
£5.24
|
£6.29
|
|
|
756 - SUCTION NOZZLE dia 35 MM
BSD-1609201229.A119
1609201229
|
£17.49
|
£20.99
|
|
|
757 - SUCTION NOZZLE dia 35 MM
BSD-1609201230.A23
1609201230
|
£41.99
|
£50.39
|
|
|
759 - SUCTION NOZZLE dia 35 MM
BSD-2607000166.A73
2607000166
|
£9.18
|
£11.01
|
|
|
759/20 - BRUSH INSERT
BSD-1609202534.A6
1609202534
|
£2.80
|
£3.36
|
|
|
761 - SUCTION BRUSH dia 35 MM
BSD-1609390481.A10
1609390481
|
£8.74
|
£10.49
|
|
|
762 - SUCTION NOZZLE dia 35 MM
BSD-2607000168.A62
2607000168
|
-
|
|
|
|
764 - FITTING dia 25x35 MM
BSD-1600499005.A111
1600499005
|
£6.66
|
£7.99
|
|
|
765 - REDUCTION SLEEVE dia 49/35 MM+3/4
BSD-1609200933.A113
1609200933
|
£7.21
|
£8.65
|
|
|
780 - AIR HOSE dia 49 MM. 3 M.1
BSD-2607000167.A17
2607000167
|
£67.98
|
£81.57
|
|
|
782 - SUCTION PIPE dia 49 MM. L=0.5 M
BSD-1609200968.A99
1609200968
|
£12.24
|
£14.69
|
|
|
783 - SUCTION NOZZLE dia 49 MM
BSD-2607000169.A2
2607000169
|
-
|
|
|
|
784 - SUCTION NOZZLE dia 49 MM. 350 MM
BSD-1609200970.A92
1609200970
|
£26.24
|
£31.49
|
|
|
784/10 - FLAT BRUSH
BSD-1609201109.A87
1609201109
|
-
|
|
|
|
784/20 - FLAT BRUSH
BSD-1609201110.A40
1609201110
|
-
|
|
|
|
786 - CREVICE NOZZLE dia 49 MM
BSD-1609200971.A29
1609200971
|
£7.87
|
£9.44
|
|
|
787 - SUCTION PIPE dia 49/35 MM
BSD-1609200976.A117
1609200976
|
£3.61
|
£4.33
|
|
|
788 - SUCTION NOZZLE dia 49 MM
BSD-1609201235.A72
1609201235
|
-
|
|
|
