1 - MOTOR HOUSING
BSD-3615102508.A0
3615102508
|
-
|
|
|
|
2 - UN. FLANGE-MTD. MOTOR 220-240V
BSD-1617220076.A0
1617220076
|
£412.57
|
£495.08
|
|
|
4 - SWITCH
BSD-1617200048.A97
1617200048
|
£19.91
|
£23.89
|
|
|
4/10 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A118
2910011088
|
£1.84
|
£2.21
|
|
|
5 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A189
1607000228
|
£23.86
|
£28.63
|
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A195
1610703053
|
£2.74
|
£3.29
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A774
3600703011
|
£2.94
|
£3.53
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A762
1601302018
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110713.A0
1611110713
|
-
|
|
|
|
13 - GROOVE BALL BEARING
BSD-2610909310.A7
2610909310
|
£17.22
|
£20.67
|
|
|
14 - NEEDLE-ROLLER BEARING
BSD-1610910089.A18
1610910089
|
-
|
|
|
|
15 - FAN
BSD-1616610078.A6
1616610078
|
-
|
|
|
|
16 - RATCHET SLEEVE
BSD-1610499022.A6
1610499022
|
£3.91
|
£4.69
|
|
|
17 - RETAINING SNAP RING
BSD-1610590004.A14
1610590004
|
£12.04
|
£14.45
|
|
|
18 - SPRING RETAINING RING
BSD-1610119010.A25
1610119010
|
£3.91
|
£4.69
|
|
|
18/1 - SPRING RETAINING RING
BSD-1610119010.A26
1610119010
|
£3.91
|
£4.69
|
|
|
19 - CLAMPING-FLANGE
BSD-1615700034.A2
1615700034
|
£70.24
|
£84.29
|
|
|
20 - TOOLHOLDER
BSD-1618597067.A6
1618597067
|
£81.81
|
£98.17
|
|
|
21 - PROTECTIVE CAP
BSD-1610508025.A15
1610508025
|
£4.48
|
£5.37
|
|
|
22 - PROTECTION SLEEVE
BSD-1610499023.A14
1610499023
|
£3.72
|
£4.47
|
|
|
23 - STOP SLEEVE
BSD-1610521011.A7
1610521011
|
£19.91
|
£23.89
|
|
|
25 - STOPPING DEVICE
BSD-1612300025.A15
1612300025
|
£9.11
|
£10.93
|
|
|
26 - INDEXING DISK
BSD-1610290027.A5
1610290027
|
£3.91
|
£4.69
|
|
|
27 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x30-10.9
BSD-2910151246.A20
2910151246
|
£2.74
|
£3.29
|
|
|
28 - COMPRESSION SPRING
BSD-1614621002.A1
1614621002
|
£2.16
|
£2.59
|
|
|
29 - COMPRESSION SPRING
BSD-1614621003.A19
1614621003
|
£2.80
|
£3.36
|
|
|
30 - O-RING 79.5x2.65 MM
BSD-1610210147.A15
1610210147
|
£2.74
|
£3.29
|
|
|
31 - DAMPING RING
BSD-1610290026.A15
1610290026
|
£2.80
|
£3.36
|
|
|
34 - SPACER TUBE
BSD-1610390029.A16
1610390029
|
£19.91
|
£23.89
|
|
|
35 - HAMMER PIPE
BSD-1615806108.A2
1615806108
|
£75.79
|
£90.95
|
|
|
36 - O-RING 64.0x2.5 MM
BSD-1610210127.A14
1610210127
|
£1.84
|
£2.21
|
|
|
37 - O-RING 35.0x3.0 MM
BSD-1610210128.A6
1610210128
|
£2.27
|
£2.72
|
|
|
38 - COVERING HOOD
BSD-1615190070.A3
1615190070
|
£18.96
|
£22.75
|
|
|
39 - ROTARY SHAFT LIP SEAL
BSD-1600A01MK9.A2
1600A01MK9
|
-
|
|
|
|
41 - STRIKER PIN
BSD-1618710071.A13
1618710071
|
£22.76
|
£27.31
|
|
|
41 - STRIKER PIN
BSD-1618710071.A14
1618710071
|
£22.76
|
£27.31
|
|
|
43 - BEARING COVER
BSD-3615808501.A0
3615808501
|
-
|
|
|
|
54 - CONTROL DISC
BSD-1610190019.A1
1610190019
|
£9.11
|
£10.93
|
|
|
55 - CONTROL BUSHING
BSD-1610420005.A14
1610420005
|
£21.68
|
£26.01
|
|
|
56 - HAMMER PISTON
BSD-1618700064.A14
1618700064
|
£12.64
|
£15.17
|
|
|
57 - STRIKER
BSD-1618710062.A7
1618710062
|
£59.53
|
£71.44
|
|
|
70 - CONNECTING ROD
BSD-1612001033.A14
1612001033
|
£12.64
|
£15.17
|
|
|
71 - STRAIGHT PIN
BSD-1613101006.A14
1613101006
|
£2.94
|
£3.53
|
|
|
72 - ECCENTRIC COG WHEEL Z=60
BSD-1616317045.A3
1616317045
|
£73.75
|
£88.50
|
|
|
75 - HANDLE
BSD-1615132051.A5
1615132051
|
£37.27
|
£44.72
|
|
|
76 - CONTROL LEVER
BSD-1612026049.A20
1612026049
|
£3.28
|
£3.94
|
|
|
77 - SHIFT PLATE
BSD-1612026063.A0
1612026063
|
£8.67
|
£10.41
|
|
|
82 - LIGHT CONDUCTOR
BSD-1615510000.A25
1615510000
|
£2.27
|
£2.72
|
|
|
84 - AUXILIARY HANDLE
BSD-160202508D.A6
160202508D
|
£19.91
|
£23.89
|
|
|
86 - HEX SCREW
BSD-2911021267.A7
2911021267
|
£3.91
|
£4.69
|
|
|
87 - CLAMPING BAND
BSD-1611316010.A3
1611316010
|
£6.52
|
£7.83
|
|
|
88 - STAR KNOB M8
BSD-1619P16922.A11
1619P16922
|
£6.45
|
£7.74
|
|
|
89 - CLAMPING PIECE
BSD-1600A00748.A27
1600A00748
|
£2.80
|
£3.36
|
|
|
103 - O-RING 30.0x5.0 MM
BSD-1610210122.A14
1610210122
|
£6.52
|
£7.83
|
|
|
104 - O-RING 22.0x11.0 MM
BSD-1610210123.A6
1610210123
|
£2.94
|
£3.53
|
|
|
111 - BUSHING
BSD-3610501500.A20
3610501500
|
£22.76
|
£27.31
|
|
|
112 - THREADED RING
BSD-3613461500.A6
3613461500
|
£12.64
|
£15.17
|
|
|
113 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A168
1613435009
|
£1.75
|
£2.10
|
|
|
114 - O-RING 30x2 MM
BSD-1900210130.A40
1900210130
|
£3.72
|
£4.47
|
|
|
115 - PROTECTIVE CAP
BSD-1610508027.A18
1610508027
|
£2.94
|
£3.53
|
|
|
122 - NEEDLE-ROLLER ASSEMBLY
BSD-1617000403.A24
1617000403
|
£21.68
|
£26.01
|
|
|
123 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913013.A19
1610913013
|
£9.11
|
£10.93
|
|
|
124/1 - THRUST BEARING DISC
BSD-1610101608.A22
1610101608
|
£2.27
|
£2.72
|
|
|
125 - TORX OVAL-HEAD SCREW 5.5x25
BSD-1613435010.A14
1613435010
|
£2.27
|
£2.72
|
|
|
126 - TAPPING SCREW DIN 7971-ST3.9x16-F
BSD-2910211019.A596
2910211019
|
£1.84
|
£2.21
|
|
|
127 - MICROENCAPSULATED SCREW DIN 912-M 5x12-8.8
BSD-2914551117.A9
2914551117
|
£1.84
|
£2.21
|
|
|
129 - SCREW AND WASHER ASSEMBLY 6.3x32
BSD-1613433001.A35
1613433001
|
£1.84
|
£2.21
|
|
|
130 - STICKER
BSD-1601110265.A361
1601110265
|
-
|
|
|
|
131 - MANUFACTURER'S NAMEPLATE
BSD-1611110714.A0
1611110714
|
-
|
|
|
|
136 - TORX OVAL-HEAD SCREW M6x30
BSD-1613490029.A1
1613490029
|
£1.75
|
£2.10
|
|
|
137 - O-RING 41.0x2.5 MM
BSD-1610210129.A1
1610210129
|
£3.91
|
£4.69
|
|
|
138 - O-RING 32.0x2.5 MM
BSD-1610210130.A6
1610210130
|
£7.72
|
£9.27
|
|
|
139 - FELT WASHER
BSD-1610108020.A5
1610108020
|
£9.11
|
£10.93
|
|
|
140 - TORX OVAL-HEAD SCREW 5.5x25
BSD-1613435010.A15
1613435010
|
£2.27
|
£2.72
|
|
|
141 - ROTARY SHAFT LIP SEAL
BSD-1610290028.A16
1610290028
|
£3.91
|
£4.69
|
|
|
142 - BUSHING
BSD-1610300063.A17
1610300063
|
£16.41
|
£19.69
|
|
|
143 - RETAINING RING DIN 7993 A 30
BSD-2916540017.A37
2916540017
|
£2.27
|
£2.72
|
|
|
144 - SUPPORTING DISC
BSD-1610102029.A6
1610102029
|
£3.91
|
£4.69
|
|
|
650 - CARRYING CASE
BSD-1615438246.A0
1615438246
|
-
|
|
|
|
652 - COLD CHISEL dia 25x400 MM
BSD-1618600207.A0
1618600207
|
-
|
|
|
|
661 - OIL SPRAY TIN
BSD-1615439012.A25
1615439012
|
£11.87
|
£14.24
|
|
|
784 - AUXILIARY HANDLE dia50 MM
BSD-2602025076.A0
2602025076
|
£29.49
|
£35.39
|
|
|
801 - UN. FLANGE-MTD. MOTOR 220-240V
BSD-1617220076.A1
1617220076
|
£412.57
|
£495.08
|
|
|
803 - UN. FLANGE-MTD. MOTOR 220-240V
BSD-1617220076.A2
1617220076
|
£412.57
|
£495.08
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A2974
160111A3H3
|
£2.74
|
£3.29
|
|
|
823 - NEEDLE-ROLLER ASSEMBLY
BSD-1617000403.A23
1617000403
|
£21.68
|
£26.01
|
|
|
824 - BALL DIN 5401-6.5MM-III-ST
BSD-1617000240.A14
1617000240
|
£3.91
|
£4.69
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000969.A1
1617000969
|
£195.26
|
£234.31
|
|
|
842 - BRUSH HOLDER
BSD-1614336016.A3
1614336016
|
-
|
|
|
|
842/030 - SPIRAL SPRING
BSD-1604652015.A327
1604652015
|
£2.94
|
£3.53
|
|
|
842/050 - CARBON-BRUSH SET
BSD-1617014126.A30
1617014126
|
£15.65
|
£18.78
|
|
|
842/080 - TAPPING SCREW DIN 7981-ST3.5x16-C-H
BSD-2910611012.A54
2910611012
|
-
|
|
|
|
845 - HOUSING COVER
BSD-1617000418.A1
1617000418
|
£12.64
|
£15.17
|
|
|
880 - SPEED GOVERNOR 220-240V
BSD-1617233026.A26
1617233026
|
£49.16
|
£58.99
|
|
|
884 - AUXILIARY HANDLE
BSD-1602025097.A5
1602025097
|
£42.84
|
£51.41
|
|
|
886 - HEX SCREW DIN 931-M8x130-8.8
BSD-2911011270.A54
2911011270
|
£4.48
|
£5.37
|
|
|
887 - CLAMPING BAND dia50 MM
BSD-1617000188.A6
1617000188
|
£10.61
|
£12.73
|
|
|
889 - CLAMPING PIECE
BSD-1618040053.A5
1618040053
|
£3.91
|
£4.69
|
|
|
890 - CATCH DISK
BSD-1610190053.A28
1610190053
|
£2.49
|
£2.99
|
|
|
895 - OIL RETURN RING
BSD-3613344500.A16
3613344500
|
£10.61
|
£12.73
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000246.A0
1617000246
|
-
|
|
|
|
898 - WEAR AND TEAR PART SET
BSD-1617000247.A0
1617000247
|
-
|
|
|
