1 - MOTOR HOUSING
BSD-1605108124.A63
1605108124
|
-
|
|
|
|
2 - FIELD 115V
BSD-1604220247.A11
1604220247
|
-
|
|
|
|
2/8 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A195
1901350003
|
£1.84
|
£2.21
|
|
|
4 - ON-OFF SWITCH
BSD-1607200089.A0
1607200089
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 2.5mm H07 RN-F
BSD-1604460202.A61
1604460202
|
£47.95
|
£57.54
|
|
|
6 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A499
1600703009
|
£5.87
|
£7.04
|
|
|
7 - FASTENING CLAMP
BSD-1601302013.A117
1601302013
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A44
1601110003
|
-
|
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328034.A400
1607328034
|
£4.48
|
£5.37
|
|
|
15 - SEAL
BSD-1600113002.A326
1600113002
|
£1.84
|
£2.21
|
|
|
16 - BRUSH HOLDER
BSD-1604336008.A91
1604336008
|
£22.60
|
£27.12
|
|
|
17 - COVER PLATE
BSD-1601037006.A94
1601037006
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026058.A26
1602026058
|
-
|
|
|
|
19/8 - FELT WASHER
BSD-1600205019.A233
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A104
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A43
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14. L=101 MM
BSD-1603523090.A53
1603523090
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A215
1600108055
|
£1.75
|
£2.10
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A857
2600910001
|
£4.48
|
£5.37
|
|
|
28 - RUBBER RING dia41xdia37x11 MM
BSD-1600206028.A28
1600206028
|
-
|
|
|
|
29 - GUIDE PULLEY
BSD-1600502013.A48
1600502013
|
-
|
|
|
|
30 - SPRING RETAINING RING
BSD-1600119004.A11
1600119004
|
£2.94
|
£3.53
|
|
|
31 - SPIRAL SPRING
BSD-1604652015.A231
1604652015
|
£2.94
|
£3.53
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A179
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A202
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A81
1600190005
|
£1.38
|
£1.66
|
|
|
35 - TAB WASHER
BSD-1601030022.A184
1601030022
|
£1.84
|
£2.21
|
|
|
36 - RUBBER RING
BSD-1600206015.A36
1600206015
|
£2.27
|
£2.72
|
|
|
40 - SPRING WASHER dia32.3xdia43.5x0.6 MM
BSD-1600150009.A76
1600150009
|
£2.80
|
£3.36
|
|
|
41 - SEALING CAP
BSD-1605500089.A228
1605500089
|
-
|
|
|
|
45 - HOLDING BRACKET
BSD-1601331032.A45
1601331032
|
-
|
|
|
|
50 - GROOVE BALL BEARING 6203-2 Z DIN 625
BSD-1900905227.A131
1900905227
|
-
|
|
|
|
52 - GROOVE BALL BEARING 37x12x12
BSD-1600900028.A22
1600900028
|
-
|
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A151
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1065
2910021118
|
£1.84
|
£2.21
|
|
|
55 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A618
2910211021
|
£1.75
|
£2.10
|
|
|
56 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A523
2916011005
|
£1.84
|
£2.21
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A16
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A286
2910211020
|
£2.16
|
£2.59
|
|
|
59 - SCREW B 4.8x45 MM
BSD-3603415560.A75
3603415560
|
£1.84
|
£2.21
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A197
2910011162
|
£1.84
|
£2.21
|
|
|
62 - HEX NUT M12x1.5 MM
BSD-1603300009.A146
1603300009
|
£1.75
|
£2.10
|
|
|
63 - TAPPING SCREW B4.8x85 MM
BSD-1603429001.A101
1603429001
|
-
|
|
|
|
66 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A273
2910211018
|
£1.75
|
£2.10
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A185
2910211011
|
£1.84
|
£2.21
|
|
|
78 - END SPLICE
BSD-1600452001.A2
1600452001
|
-
|
|
|
|
100 - GROOVED RING
BSD-1600390011.A83
1600390011
|
-
|
|
|
|
105 - STICKER
BSD-1601110240.A53
1601110240
|
-
|
|
|
|
150 - END SPLICE
BSD-3604477009.A288
3604477009
|
£2.61
|
£3.13
|
|
|
151 - HOLDING BELT
BSD-1604700002.A4
1604700002
|
-
|
|
|
|
650/10 - AUXILIARY HANDLE M14
BSD-1602025022.A220
1602025022
|
£13.41
|
£16.09
|
|
|
650/10 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A479
1602025030
|
£19.91
|
£23.89
|
|
|
650/11 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A13
1607950061
|
£5.69
|
£6.83
|
|
|
650/12 - CLAMPING-FLANGE dia45 MM
BSD-2600501006.A221
2600501006
|
£17.26
|
£20.71
|
|
|
650/13 - ROUND NUT M14
BSD-2603345004.A249
2603345004
|
£6.52
|
£7.83
|
|
|
650/14 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A427
1907950007
|
£5.57
|
£6.68
|
|
|
652/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x18-8.8
BSD-2910141240.A186
2910141240
|
£1.32
|
£1.58
|
|
|
702 - UNION dia32.3xdia34.9x75 MM
BSD-1600309009.A91
1600309009
|
-
|
|
|
|
702/10 - WING NUT DIN 315-M8-GT-C
BSD-2915191007.A26
2915191007
|
£3.72
|
£4.47
|
|
|
702/11 - PLAIN WASHER DIN 125-A 8.4-ST
BSD-2916011016.A51
2916011016
|
£1.84
|
£2.21
|
|
|
702/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x18-8.8
BSD-2910141240.A187
2910141240
|
£1.32
|
£1.58
|
|
|
703 - PARTS SET
BSD-1607000140.A40
1607000140
|
-
|
|
|
|
703/11 - HEX SCREW M14x16x1.5 MM
BSD-2603450007.A190
2603450007
|
£5.87
|
£7.04
|
|
|
712 - PARTS SET dia180 MM
BSD-1607000176.A4
1607000176
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A196
1607014103
|
£15.65
|
£18.78
|
|
|
801 - CONNECTING CABLE
BSD-1604440004.A164
1604440004
|
-
|
|
|
|
802 - CROWN GEAR Z=51
BSD-1606333210.A21
1606333210
|
-
|
|
|
|
803 - BEVEL GEAR Z=18
BSD-1606333209.A9
1606333209
|
-
|
|
|
|
806 - ARMATURE 100-115V
BSD-1604012046.A4
1604012046
|
-
|
|
|
|
807 - PARTS SET
BSD-1607000917.A16
1607000917
|
-
|
|
|
|
807 - PARTS SET
BSD-1607000913.A27
1607000913
|
-
|
|
|
|
813 - PARTS SET
BSD-1607000161.A9
1607000161
|
-
|
|
|
|
817 - COVER PLATE
BSD-1601037006.A90
1601037006
|
-
|
|
|
|
817/029 - O-RING 79.0x1.78 MM
BSD-1600210033.A344
1600210033
|
£1.84
|
£2.21
|
|
|
828 - RETAINING SNAP RING
BSD-1600206019.A40
1600206019
|
-
|
|
|
|
842 - PARTS SET
BSD-1607000187.A27
1607000187
|
-
|
|
|
|
852 - GROOVE BALL BEARING 6203-TH/C3 DIN 625
BSD-1900900413.A101
1900900413
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A837
160111A3H3
|
£2.74
|
£3.29
|
|
