1 - MOTOR HOUSING
BSD-1605108124.A62
1605108124
|
-
|
|
|
|
2 - FIELD 230V
BSD-1604220245.A29
1604220245
|
-
|
|
|
|
2/8 - TERMINAL LUG 1.5-4x4
BSD-1901350003.A196
1901350003
|
£1.75
|
£2.10
|
|
|
6 - GROMMET dia9.2-dia12x120 MM
BSD-3600703011.A894
3600703011
|
£2.80
|
£3.36
|
|
|
7 - FASTENING CLAMP
BSD-1601302013.A116
1601302013
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110003.A43
1601110003
|
-
|
|
|
|
11 - SUPPRESSION FILTER
BSD-1607328034.A401
1607328034
|
£4.26
|
£5.11
|
|
|
15 - SEAL
BSD-1600113002.A325
1600113002
|
£1.75
|
£2.10
|
|
|
16 - BRUSH HOLDER
BSD-1604336008.A92
1604336008
|
£21.52
|
£25.83
|
|
|
17 - COVER PLATE
BSD-1601037009.A6
1601037009
|
-
|
|
|
|
19 - CONTROL LEVER
BSD-1602026058.A25
1602026058
|
-
|
|
|
|
19/8 - FELT WASHER
BSD-1600205019.A234
1600205019
|
£1.75
|
£2.10
|
|
|
20 - BEARING COVER
BSD-1605808054.A103
1605808054
|
-
|
|
|
|
21 - COVER DISC
BSD-1600102012.A42
1600102012
|
-
|
|
|
|
22 - GRINDING SPINDLE M14. L=101 MM
BSD-1603523090.A54
1603523090
|
-
|
|
|
|
23 - SEALING DISK
BSD-1600108055.A216
1600108055
|
£1.75
|
£2.10
|
|
|
25 - GROMMET
BSD-1600306001.A342
1600306001
|
£2.61
|
£3.13
|
|
|
27 - NEEDLE-ROLLER BEARING dia14 MM
BSD-2600910001.A859
2600910001
|
£4.26
|
£5.11
|
|
|
28 - RUBBER RING dia41xdia37x11 MM
BSD-1600206028.A26
1600206028
|
-
|
|
|
|
29 - GUIDE PULLEY
BSD-1600502013.A47
1600502013
|
-
|
|
|
|
30 - SPRING RETAINING RING
BSD-1600119004.A12
1600119004
|
£2.80
|
£3.36
|
|
|
31 - SPIRAL SPRING
BSD-1604652015.A230
1604652015
|
£2.80
|
£3.36
|
|
|
32 - ROTARY SHAFT LIP SEAL
BSD-1600290008.A178
1600290008
|
£2.61
|
£3.13
|
|
|
34 - SHIM 0.1 MM
BSD-1600190004.A203
1600190004
|
-
|
|
|
|
34 - SHIM 0.2 MM
BSD-1600190005.A80
1600190005
|
£1.32
|
£1.58
|
|
|
35 - TAB WASHER
BSD-1601030022.A182
1601030022
|
£1.75
|
£2.10
|
|
|
36 - RUBBER RING
BSD-1600206015.A34
1600206015
|
£2.16
|
£2.59
|
|
|
40 - SPRING WASHER dia32.3xdia43.5x0.6 MM
BSD-1600150009.A75
1600150009
|
£2.80
|
£3.36
|
|
|
41 - SEALING CAP
BSD-1605500089.A225
1605500089
|
-
|
|
|
|
42 - HANDLE
BSD-1605132093.A7
1605132093
|
-
|
|
|
|
45 - HOLDING BRACKET
BSD-1601331032.A47
1601331032
|
-
|
|
|
|
50 - GROOVE BALL BEARING 6203-2 Z DIN 625
BSD-1900905227.A134
1900905227
|
-
|
|
|
|
52 - GROOVE BALL BEARING 37x12x12
BSD-1600900028.A20
1600900028
|
-
|
|
|
|
53 - GROOVE BALL BEARING
BSD-1600900029.A153
1600900029
|
-
|
|
|
|
54 - SOCKET HEAD CAP SCREW DIN 84-AM4x8-8.8
BSD-2910021118.A1063
2910021118
|
£1.75
|
£2.10
|
|
|
55 - TAPPING SCREW DIN 7971-BZ2.9x13
BSD-2910211006.A667
2910211006
|
£1.75
|
£2.10
|
|
|
56 - PLAIN WASHER DIN 433-3.2-ST 50
BSD-2916011005.A525
2916011005
|
£1.75
|
£2.10
|
|
|
57 - SOCKET HEAD CAP SCREW DIN 84-AM5x15-5.8
BSD-2910011157.A14
2910011157
|
-
|
|
|
|
58 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A284
2910211020
|
£2.16
|
£2.59
|
|
|
59 - SCREW B 4.8x45 MM
BSD-3603415560.A78
3603415560
|
£1.75
|
£2.10
|
|
|
60 - TAPPING SCREW DIN 7971-ST4.8x25-F
BSD-2910211036.A187
2910211036
|
£1.75
|
£2.10
|
|
|
61 - SOCKET HEAD CAP SCREW DIN 84-AM5x20-5.8
BSD-2910011162.A199
2910011162
|
£1.75
|
£2.10
|
|
|
62 - HEX NUT M12x1.5 MM
BSD-1603300009.A147
1603300009
|
£1.75
|
£2.10
|
|
|
63 - TAPPING SCREW B4.8x85 MM
BSD-1603429001.A100
1603429001
|
-
|
|
|
|
66 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A275
2910211018
|
£1.75
|
£2.10
|
|
|
69 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A183
2910211011
|
£1.75
|
£2.10
|
|
|
100 - GROOVED RING
BSD-1600390011.A85
1600390011
|
-
|
|
|
|
105 - STICKER
BSD-1601110240.A55
1601110240
|
-
|
|
|
|
650/10 - AUXILIARY HANDLE M14
BSD-1602025022.A218
1602025022
|
£13.41
|
£16.09
|
|
|
650/10 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A481
1602025030
|
£18.96
|
£22.75
|
|
|
650/11 - PIN-TYPE FACE-WRENCH
BSD-1607950061.A15
1607950061
|
£5.42
|
£6.50
|
|
|
650/12 - CLAMPING-FLANGE dia45 MM
BSD-2600501006.A218
2600501006
|
£16.43
|
£19.72
|
|
|
650/13 - ROUND NUT M14
BSD-2603345004.A247
2603345004
|
£6.52
|
£7.83
|
|
|
650/14 - OFFSET SCREWDRIVER DIN 911;SW6
BSD-1907950007.A430
1907950007
|
£5.30
|
£6.36
|
|
|
652 - PROTECTIVE COVER dia180 MM
BSD-1605510176.A53
1605510176
|
-
|
|
|
|
652/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x18-8.8
BSD-2910141240.A185
2910141240
|
£1.32
|
£1.58
|
|
|
700 - PARTS SET
BSD-1607000149.A9
1607000149
|
-
|
|
|
|
702 - UNION dia32.3xdia34.9x75 MM
BSD-1600309009.A89
1600309009
|
-
|
|
|
|
702/10 - WING NUT DIN 315-M8-GT-C
BSD-2915191007.A24
2915191007
|
£3.72
|
£4.47
|
|
|
702/11 - PLAIN WASHER DIN 125-A 8.4-ST
BSD-2916011016.A49
2916011016
|
£1.75
|
£2.10
|
|
|
702/20 - HEX SOCKET HEAD CAP SCREW DIN 912-M8x18-8.8
BSD-2910141240.A184
2910141240
|
£1.32
|
£1.58
|
|
|
703 - PARTS SET
BSD-1607000140.A38
1607000140
|
-
|
|
|
|
703/11 - HEX SCREW M14x16x1.5 MM
BSD-2603450007.A192
2603450007
|
£5.58
|
£6.70
|
|
|
712 - PARTS SET dia180 MM
BSD-1607000176.A5
1607000176
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A193
1607014103
|
£14.91
|
£17.89
|
|
|
801 - CONNECTING CABLE
BSD-1604440004.A162
1604440004
|
-
|
|
|
|
802 - CROWN GEAR Z=51
BSD-1606333210.A23
1606333210
|
-
|
|
|
|
803 - BEVEL GEAR Z=18
BSD-1606333209.A7
1606333209
|
-
|
|
|
|
806 - ARMATURE 220V
BSD-1604012044.A0
1604012044
|
-
|
|
|
|
807 - PARTS SET
BSD-1607000917.A18
1607000917
|
-
|
|
|
|
807 - PARTS SET
BSD-1607000913.A25
1607000913
|
-
|
|
|
|
813 - PARTS SET
BSD-1607000161.A8
1607000161
|
-
|
|
|
|
817 - COVER PLATE
BSD-1601037006.A93
1601037006
|
-
|
|
|
|
817/029 - O-RING 79.0x1.78 MM
BSD-1600210033.A346
1600210033
|
£1.75
|
£2.10
|
|
|
818 - PROFILE STRIP 3.4x7x240 MM
BSD-1601014005.A170
1601014005
|
-
|
|
|
|
828 - RETAINING SNAP RING
BSD-1600206019.A42
1600206019
|
-
|
|
|
|
831 - ON-OFF SWITCH
BSD-1607200097.A35
1607200097
|
-
|
|
|
|
835 - POWER SUPPLY CORD EU 4.15m 2 x 1.5mm H07 RN-F
BSD-1607000228.A630
1607000228
|
£23.86
|
£28.63
|
|
|
852 - GROOVE BALL BEARING 6203-TH/C3 DIN 625
BSD-1900900413.A98
1900900413
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A834
160111A3H3
|
£2.61
|
£3.13
|
|
