2 - FIELD 110-120V
BSD-1614220180.A1
1614220180
|
£21.52
|
£25.83
|
|
|
3 - ARMATURE 110V
BSD-1614010233.A4
1614010233
|
£66.68
|
£80.01
|
|
|
3/5 - FAN
BSD-1616610094.A72
1616610094
|
£2.16
|
£2.59
|
|
|
3/13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A248
1610905025
|
£6.85
|
£8.22
|
|
|
3/14 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A438
1610905048
|
£8.67
|
£10.41
|
|
|
3/49 - END SHIELD
BSD-1615700044.A18
1615700044
|
£2.27
|
£2.72
|
|
|
4 - SWITCH
BSD-1617200137.A0
1617200137
|
-
|
|
|
|
6 - GROMMET dia7.3-dia8.6x66 MM
BSD-1600703034.A29
1600703034
|
£2.74
|
£3.29
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110W56.A0
1611110W56
|
£2.61
|
£3.13
|
|
|
10 - MANUFACTURER'S NAMEPLATE
BSD-1611110W57.A0
1611110W57
|
£2.61
|
£3.13
|
|
|
16 - BRUSH PLATE
BSD-1614336061.A78
1614336061
|
£19.91
|
£23.89
|
|
|
17 - SUPPRESSION FILTER
BSD-1614465011.A48
1614465011
|
£6.85
|
£8.22
|
|
|
19 - SWITCH CONTACT
BSD-1611329024.A9
1611329024
|
£1.84
|
£2.21
|
|
|
24 - TOOTHED SHAFT
BSD-1617000556.A16
1617000556
|
£42.84
|
£51.41
|
|
|
26 - HAMMER PISTON
BSD-1617000557.A72
1617000557
|
£38.47
|
£46.16
|
|
|
26/27 - STRIKER
BSD-1610311018.A30
1610311018
|
£18.96
|
£22.75
|
|
|
26/29 - PISTON PIN
BSD-1613105012.A455
1613105012
|
£3.91
|
£4.69
|
|
|
26/56 - O-RING
BSD-1610210187.A100
1610210187
|
£2.27
|
£2.72
|
|
|
26/71 - SHIM WASHER 1.2 MM
BSD-1610101011.A344
1610101011
|
£1.75
|
£2.10
|
|
|
30 - DRIVE BEARING
BSD-1615819028.A25
1615819028
|
£35.12
|
£42.15
|
|
|
30/35 - PLAIN BEARING
BSD-1610202024.A12
1610202024
|
£5.57
|
£6.68
|
|
|
31 - NEEDLE-ROLLER ASSEMBLY
BSD-1610913016.A42
1610913016
|
£3.72
|
£4.47
|
|
|
32 - CLAMP HANDLE
BSD-1612026118.A0
1612026118
|
£11.30
|
£13.56
|
|
|
32/46 - DRIVER PIN
BSD-1614690002.A161
1614690002
|
£1.84
|
£2.21
|
|
|
32/49 - SWITCH BUTTON
BSD-1612026035.A148
1612026035
|
£1.75
|
£2.10
|
|
|
32/76 - O-RING 10.5x2.7 MM
BSD-1610210046.A210
1610210046
|
£2.16
|
£2.59
|
|
|
32/83 - COMPRESSION SPRING
BSD-1614611006.A211
1614611006
|
£3.91
|
£4.69
|
|
|
36 - HOLDING PLATE
BSD-1611016003.A101
1611016003
|
£2.27
|
£2.72
|
|
|
41 - HOUSING COVER
BSD-1615500369.A2
1615500369
|
£8.67
|
£10.41
|
|
|
45 - AIR-DEFLECTOR RING
BSD-1610522013.A62
1610522013
|
£2.27
|
£2.72
|
|
|
48 - TAB WASHER
BSD-1611098008.A128
1611098008
|
£2.27
|
£2.72
|
|
|
54 - RUBBER BUSHING
BSD-1610502016.A106
1610502016
|
£1.84
|
£2.21
|
|
|
55 - SEAL RING 53.0x7.0 MM
BSD-1610290226.A8
1610290226
|
£3.72
|
£4.47
|
|
|
57 - O-RING 24.0x2.5 MM
BSD-1610210068.A311
1610210068
|
£1.75
|
£2.10
|
|
|
63 - NEEDLE BEARING dia30xdia37x12 MM
BSD-1610910063.A1
1610910063
|
£5.87
|
£7.04
|
|
|
64/1 - SUPPORTING DISC
BSD-1610190060.A63
1610190060
|
£2.27
|
£2.72
|
|
|
66 - PLAIN BEARING
BSD-1610202021.A128
1610202021
|
£2.74
|
£3.29
|
|
|
68 - ROTARY SHAFT LIP SEAL
BSD-1610283036.A11
1610283036
|
£7.72
|
£9.27
|
|
|
76 - THREAD-FORMING TAP. SCREW
BSD-160343000A.A9
160343000A
|
£1.84
|
£2.21
|
|
|
77 - TORX OVAL-HEAD SCREW 4x25
BSD-2603490024.A1056
2603490024
|
£1.84
|
£2.21
|
|
|
78 - SCREW 4x16
BSD-2603490022.A2949
2603490022
|
£1.84
|
£2.21
|
|
|
79 - THREAD-FORMING TAP. SCREW
BSD-1613435023.A159
1613435023
|
£1.84
|
£2.21
|
|
|
80 - SCREW
BSD-1613435043.A104
1613435043
|
£1.84
|
£2.21
|
|
|
96 - RETAINING RING
BSD-1614601046.A14
1614601046
|
£1.84
|
£2.21
|
|
|
101 - CONNECTING CABLE
BSD-1614449014.A43
1614449014
|
£2.16
|
£2.59
|
|
|
102 - CONNECTING CABLE
BSD-1614449015.A107
1614449015
|
£1.84
|
£2.21
|
|
|
103 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A508
2603490017
|
£2.27
|
£2.72
|
|
|
106 - PLAIN BEARING
BSD-1614611022.A33
1614611022
|
£2.74
|
£3.29
|
|
|
106/105 - COMPRESSION SPRING
BSD-1614611021.A60
1614611021
|
£1.75
|
£2.10
|
|
|
321/22 - CYLINDRICAL GEAR
BSD-1616312004.A160
1616312004
|
£12.64
|
£15.17
|
|
|
321/28 - STRIKER PIN
BSD-1613124082.A23
1613124082
|
£18.96
|
£22.75
|
|
|
321/34 - SUPPORTING DISC
BSD-1610190067.A200
1610190067
|
£2.16
|
£2.59
|
|
|
321/37 - STRAIGHT PIN DIN6325-2.5x12-RIKO
BSD-1613100019.A82
1613100019
|
£1.84
|
£2.21
|
|
|
321/38 - CATCH DISK
BSD-1600A008AG.A147
1600A008AG
|
£3.72
|
£4.47
|
|
|
321/42 - THRUST RING
BSD-1610290099.A36
1610290099
|
£5.57
|
£6.68
|
|
|
321/46 - GUIDE BUSHING
BSD-1610390066.A25
1610390066
|
£12.04
|
£14.45
|
|
|
321/50 - COMPRESSION SPRING
BSD-1614611020.A33
1614611020
|
£2.80
|
£3.36
|
|
|
321/58 - O-RING
BSD-1610210178.A24
1610210178
|
£1.84
|
£2.21
|
|
|
321/59 - SHAFT SEAL
BSD-1600A009VC.A129
1600A009VC
|
£2.80
|
£3.36
|
|
|
321/60 - O-RING 9.0x3.5 MM
BSD-1610210176.A32
1610210176
|
£1.84
|
£2.21
|
|
|
321/72 - RETAINING RING
BSD-1604601027.A175
1604601027
|
£1.75
|
£2.10
|
|
|
321/82 - RETAINING RING
BSD-1614601034.A24
1614601034
|
£2.27
|
£2.72
|
|
|
321/83 - RETAINING RING A22 DIN 7993
BSD-1604601028.A77
1604601028
|
£1.84
|
£2.21
|
|
|
356/217 - COUNTERSUNK-HEAD SCREW M6x23
BSD-2603421229.A262
2603421229
|
£1.84
|
£2.21
|
|
|
390/89 - GUIDE SLEEVE
BSD-1600A00NC8.A66
1600A00NC8
|
£2.74
|
£3.29
|
|
|
390/90 - COLLAR SLEEVE
BSD-1610590016.A67
1610590016
|
£4.48
|
£5.37
|
|
|
390/91 - BACKUP RING
BSD-1610200033.A66
1610200033
|
£2.94
|
£3.53
|
|
|
390/95 - COMPRESSION SPRING
BSD-1614643016.A15
1614643016
|
£2.27
|
£2.72
|
|
|
390/97 - RETAINING RING
BSD-1614601047.A67
1614601047
|
£1.75
|
£2.10
|
|
|
651 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A341
1613001009
|
£3.91
|
£4.69
|
|
|
801 - MOTOR HOUSING
BSD-1617000V68.A3
1617000V68
|
£33.74
|
£40.49
|
|
|
806 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A227
1900452012
|
£1.75
|
£2.10
|
|
|
808 - NAMEPLATE
BSD-160111A3HD.A37
160111A3HD
|
£2.74
|
£3.29
|
|
|
811 - CARBON-BRUSH SET
BSD-1617000525.A53
1617000525
|
£11.87
|
£14.24
|
|
|
820 - INTERMEDIATE FLANGE
BSD-16170006DX.A5
16170006DX
|
£31.79
|
£38.15
|
|
|
821 - PIPE
BSD-1617000V42.A7
1617000V42
|
£63.50
|
£76.20
|
|
|
822 - AUXILIARY HANDLE
BSD-1612025067.A1
1612025067
|
£18.96
|
£22.75
|
|
|
822/120 - AUXILIARY HANDLE
BSD-1612025069.A3
1612025069
|
£6.52
|
£7.83
|
|
|
822/124 - CLAMPING BAND dia50 MM
BSD-1611316021.A198
1611316021
|
£2.80
|
£3.36
|
|
|
822/125 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A594
1613490002
|
£4.48
|
£5.37
|
|
|
822/802 - SUPPORT CLAMP
BSD-1617000476.A14
1617000476
|
£2.80
|
£3.36
|
|
|
823 - TOOTHED SHAFT
BSD-1617000579.A33
1617000579
|
£39.61
|
£47.53
|
|
|
825 - TOOL HOLDING FIXTURE
BSD-1617000895.A87
1617000895
|
£49.16
|
£58.99
|
|
|
825/203 - PROTECTIVE CAP
BSD-1610508047.A61
1610508047
|
£2.41
|
£2.89
|
|
|
828 - STRIKER PIN
BSD-1617000V43.A25
1617000V43
|
£40.80
|
£48.96
|
|
|
833 - HOLDING JACKET
BSD-1610590018.A15
1610590018
|
£4.75
|
£5.70
|
|
|
840 - GEAR HOUSING
BSD-1617000V69.A2
1617000V69
|
£42.84
|
£51.41
|
|
|
861 - SWITCHING ELEMENT
BSD-1615820097.A31
1615820097
|
£5.30
|
£6.36
|
|
|
864 - SUPPORTING DISC
BSD-1617000A07.A75
1617000A07
|
£11.87
|
£14.24
|
|
|
883 - RETAINING RING A22 DIN 7993
BSD-1604601028.A78
1604601028
|
£1.84
|
£2.21
|
|
|
890 - GUIDE SLEEVE
BSD-1617000V41.A73
1617000V41
|
£11.87
|
£14.24
|
|
|
891 - HAMMER PIPE
BSD-1617000876.A2
1617000876
|
£80.61
|
£96.73
|
|
