2 - FIELD 220-230V
BSD-2604220429.A72
2604220429
|
£23.86
|
£28.63
|
|
|
3/50 - FAN
BSD-1616610072.A116
1616610072
|
£2.27
|
£2.72
|
|
|
4 - SWITCH
BSD-2607200204.A5
2607200204
|
-
|
|
|
|
5 - POWER SUPPLY CORD
BSD-1614460131.A3
1614460131
|
-
|
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A652
2600703011
|
£2.94
|
£3.53
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A628
2600703013
|
£2.61
|
£3.13
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A557
2600703012
|
£2.94
|
£3.53
|
|
|
7 - CABLE CLIP
BSD-2601035001.A2970
2601035001
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1611110405.A2
1611110405
|
-
|
|
|
|
10 - MANUFACTURER'S NAMEPLATE
BSD-1611110406.A0
1611110406
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328028.A204
1607328028
|
£5.57
|
£6.68
|
|
|
17 - HOUSING COVER
BSD-1615132034.A25
1615132034
|
£5.26
|
£6.31
|
|
|
18 - AIR-DEFLECTOR RING
BSD-1610522008.A62
1610522008
|
£1.84
|
£2.21
|
|
|
20 - INTERMEDIATE FLANGE
BSD-1615700037.A128
1615700037
|
£40.80
|
£48.96
|
|
|
21 - RATCHET SLEEVE SDS-PLUS
BSD-1616490058.A110
1616490058
|
£218.41
|
£262.09
|
|
|
22 - CYLINDRICAL GEAR Z=46
BSD-1616320007.A71
1616320007
|
£7.36
|
£8.83
|
|
|
23 - CYLINDRICAL GEAR Z=6/21
BSD-1616320002.A130
1616320002
|
£24.45
|
£29.34
|
|
|
24 - TOOTHED SHAFT Z=6/10
BSD-1613060010.A32
1613060010
|
£54.42
|
£65.30
|
|
|
26 - HAMMER PISTON
BSD-1618700052.A75
1618700052
|
£13.78
|
£16.54
|
|
|
28 - STRIKER PIN
BSD-1613124026.A82
1613124026
|
£2.80
|
£3.36
|
|
|
29 - PISTON PIN
BSD-1613105012.A192
1613105012
|
£3.91
|
£4.69
|
|
|
30 - DRIVE BEARING
BSD-1615819005.A22
1615819005
|
£31.64
|
£37.97
|
|
|
31 - SUPPORT DISC 0.8 MM
BSD-1610100003.A75
1610100003
|
£1.84
|
£2.21
|
|
|
32 - CLAMP HANDLE
BSD-1612026023.A144
1612026023
|
£2.74
|
£3.29
|
|
|
34 - PROTECTIVE CAP L=17 MM. SDS-PLUS
BSD-1610508008.A25
1610508008
|
£2.27
|
£2.72
|
|
|
35 - RUBBER RING
BSD-1610206021.A71
1610206021
|
£1.84
|
£2.21
|
|
|
37 - DAMPING BUSHING
BSD-1610390011.A20
1610390011
|
£3.72
|
£4.47
|
|
|
38 - SUPPORTING DISC
BSD-1610102022.A0
1610102022
|
£2.16
|
£2.59
|
|
|
39 - STRAIGHT PIN
BSD-1613100013.A159
1613100013
|
£2.16
|
£2.59
|
|
|
40 - HOLDING SPRING
BSD-1614690001.A144
1614690001
|
£1.84
|
£2.21
|
|
|
41 - ROLLER-CAGE ASSEMBLY
BSD-1610920003.A59
1610920003
|
£4.26
|
£5.11
|
|
|
44 - COMPRESSION SPRING
BSD-1614633001.A12
1614633001
|
£2.52
|
£3.02
|
|
|
45 - COMPRESSION SPRING
BSD-1614614001.A74
1614614001
|
£1.84
|
£2.21
|
|
|
49 - CABLE L=130 MM
BSD-2604448005.A226
2604448005
|
£1.84
|
£2.21
|
|
|
54 - O-RING 24.0x2.5 MM
BSD-1610210068.A121
1610210068
|
£1.75
|
£2.10
|
|
|
55 - SEAL RING
BSD-1610206023.A101
1610206023
|
£2.94
|
£3.53
|
|
|
56 - O-RING 14.0x3.0 MM
BSD-1610210070.A103
1610210070
|
£2.61
|
£3.13
|
|
|
58 - O-RING 18.0x3.0 MM
BSD-1610210058.A7
1610210058
|
£2.61
|
£3.13
|
|
|
59 - O-RING 6.0x2.5 MM
BSD-1610210069.A66
1610210069
|
£1.84
|
£2.21
|
|
|
60 - O-RING 10.0x3.5 MM
BSD-1610210073.A34
1610210073
|
£2.16
|
£2.59
|
|
|
61 - ROTARY SHAFT LIP SEAL
BSD-1610283017.A66
1610283017
|
£7.36
|
£8.83
|
|
|
62 - PLAIN BEARING
BSD-1610202026.A153
1610202026
|
£5.57
|
£6.68
|
|
|
63 - GROOVE BALL BEARING 9x24x7
BSD-1610905048.A381
1610905048
|
£8.67
|
£10.41
|
|
|
64 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A230
1610905025
|
£6.52
|
£7.83
|
|
|
65 - GROOVE BALL BEARING 8x22x7
BSD-1900900228.A146
1900900228
|
£6.61
|
£7.93
|
|
|
66 - BUSHING dia30xdia37x15.7 MM
BSD-1610301000.A52
1610301000
|
£3.34
|
£4.01
|
|
|
66 - NEEDLE BEARING dia30xdia37x12 MM
BSD-1610910063.A45
1610910063
|
£5.87
|
£7.04
|
|
|
67 - NEEDLE BEARING
BSD-1610910064.A298
1610910064
|
£2.64
|
£3.17
|
|
|
70 - BALL DIN 5401-dia7MM-III-ST
BSD-1903230013.A391
1903230013
|
£2.16
|
£2.59
|
|
|
71 - SHIM WASHER 1.2 MM
BSD-1610101011.A23
1610101011
|
£1.75
|
£2.10
|
|
|
72 - RETAINING RING DIN 7993-A32
BSD-2916540018.A7
2916540018
|
£3.72
|
£4.47
|
|
|
73 - RETAINING RING DIN 9045-24
BSD-1614601009.A148
1614601009
|
£2.05
|
£2.46
|
|
|
76 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A138
1613435009
|
£1.75
|
£2.10
|
|
|
77 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A299
2910211021
|
£1.75
|
£2.10
|
|
|
78 - TAPPING SCREW ST3.9x19-TORX.T20
BSD-1603435050.A100
1603435050
|
£2.33
|
£2.80
|
|
|
79 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A395
2910211005
|
£1.75
|
£2.10
|
|
|
79 - TAPPING SCREW DIN 7971-B 2.9x13
BSD-2910211206.A13
2910211206
|
£1.38
|
£1.66
|
|
|
80 - RECESSED-HEAD SCREW DIN 7981-ST3.5x9.5-F
BSD-2603435015.A308
2603435015
|
£2.27
|
£2.72
|
|
|
81 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A2652
2603410001
|
£1.84
|
£2.21
|
|
|
83 - BALL 5 MM V DIN 5401
BSD-1903230309.A36
1903230309
|
£1.84
|
£2.21
|
|
|
87 - RETAINING RING DIN 7993-A22
BSD-2916540012.A448
2916540012
|
-
|
|
|
|
94 - DETENT PIN
BSD-1613120017.A64
1613120017
|
£1.84
|
£2.21
|
|
|
120 - AUXILIARY HANDLE M8
BSD-1612025019.A459
1612025019
|
£6.85
|
£8.22
|
|
|
121 - SUPPORT CLAMP dia43 MM
BSD-1618040048.A83
1618040048
|
£8.67
|
£10.41
|
|
|
122 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A567
1613490002
|
£4.48
|
£5.37
|
|
|
123 - CLAMPING BAND dia43 MM
BSD-1611316006.A313
1611316006
|
£2.61
|
£3.13
|
|
|
691 - CARRYING CASE
BSD-1615438184.A1
1615438184
|
-
|
|
|
|
700 - DRILL CHUCK SHANK
BSD-1617000132.A106
1617000132
|
£17.68
|
£21.22
|
|
|
700/20 - COUNTERSUNK-HEAD SCREW M6x27
BSD-2603421226.A163
2603421226
|
£1.84
|
£2.21
|
|
|
701 - KEY CHUCK dia1.5-13 MM. 1/2
BSD-1608571022.A28
1608571022
|
-
|
|
|
|
701/7 - CHUCK WRENCH SG2
BSD-2607950007.A456
2607950007
|
£6.85
|
£8.22
|
|
|
711 - PARTS SET
BSD-1617000133.A93
1617000133
|
-
|
|
|
|
711/10/2 - RETAINING RING
BSD-2604601004.A95
2604601004
|
£1.75
|
£2.10
|
|
|
711/20 - SCREWDRIVER BLADE NR.2.1/4
BSD-1608521004.A104
1608521004
|
-
|
|
|
|
711/30 - SCREWDRIVER BIT
BSD-2607000248.A38
2607000248
|
-
|
|
|
|
711/40 - SCREWDRIVER BLADE GR.1.0x6. 1/4
BSD-1608511020.A25
1608511020
|
-
|
|
|
|
720 - AUXILIARY HANDLE dia43 MM
BSD-2602025070.A57
2602025070
|
£14.91
|
£17.89
|
|
|
720/8 - PARTS SET
BSD-1617000925.A34
1617000925
|
£16.41
|
£19.69
|
|
|
751 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A261
1613001009
|
£3.91
|
£4.69
|
|
|
801 - PARTS SET
BSD-1615108054.A4
1615108054
|
-
|
|
|
|
803 - ARMATURE WITH FAN 220-240V
BSD-1614010052.A9
1614010052
|
-
|
|
|
|
808 - NAMEPLATE
BSD-160111A3HD.A48
160111A3HD
|
£2.74
|
£3.29
|
|
|
811 - CARBON BRUSH
BSD-1607014117.A126
1607014117
|
£10.61
|
£12.73
|
|
|
814 - BRUSH HOLDER
BSD-1617000130.A12
1617000130
|
£3.80
|
£4.56
|
|
|
816 - GEAR HOUSING
BSD-1615806143.A26
1615806143
|
-
|
|
|
|
821 - RATCHET SLEEVE
BSD-1617000931.A63
1617000931
|
£283.50
|
£340.20
|
|
|
827 - STRIKER
BSD-1617000338.A125
1617000338
|
£28.59
|
£34.31
|
|
|
833 - PROTECTION SLEEVE
BSD-1617000163.A30
1617000163
|
£7.72
|
£9.27
|
|
