1 - MOTOR HOUSING
BSD-16051082CC.A0
16051082CC
|
£13.12
|
£15.75
|
|
|
2 - FIELD 110-120V
BSD-1604220226.A1
1604220226
|
£27.31
|
£32.77
|
|
|
4 - ON-OFF SWITCH
BSD-1607200086.A360
1607200086
|
£11.30
|
£13.56
|
|
|
5 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000227.A43
1607000227
|
£23.86
|
£28.63
|
|
|
6 - GROMMET dia6.5-dia6.9x95 MM
BSD-2600703012.A1187
2600703012
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A249
2600703011
|
£2.80
|
£3.36
|
|
|
6 - GROMMET dia7.6-dia8.2x95 MM
BSD-2600703013.A200
2600703013
|
£2.61
|
£3.13
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A543
1601302017
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601110672.A1
1601110672
|
-
|
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328029.A30
1607328029
|
-
|
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A303
2600905032
|
£5.30
|
£6.36
|
|
|
14 - GROOVE BALL BEARING 8x22x7
BSD-1600905011.A179
1600905011
|
£5.58
|
£6.70
|
|
|
15 - FAN
BSD-1606610121.A252
1606610121
|
£1.75
|
£2.10
|
|
|
17 - MANUFACTURER'S NAMEPLATE
BSD-1601110613.A8
1601110613
|
-
|
|
|
|
18 - COMPRESSION SPRING
BSD-1604611026.A420
1604611026
|
£1.75
|
£2.10
|
|
|
21 - GEAR HOUSING
BSD-1605806411.A3
1605806411
|
£21.68
|
£26.01
|
|
|
22 - ADJUSTING SLIDE
BSD-1602319002.A174
1602319002
|
£2.61
|
£3.13
|
|
|
23 - SWITCH HANDLE
BSD-1602026057.A222
1602026057
|
£1.97
|
£2.36
|
|
|
25 - HOUSING COVER
BSD-1600508010.A40
1600508010
|
£7.36
|
£8.83
|
|
|
26 - RUBBER BUSHING
BSD-1600502020.A270
1600502020
|
£2.61
|
£3.13
|
|
|
27 - RUBBER RING
BSD-1600206025.A500
1600206025
|
£2.16
|
£2.59
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1601328005.A232
1601328005
|
£2.61
|
£3.13
|
|
|
31 - RETAINING CLIP DIN 472-32x1.2 MM
BSD-2916660013.A396
2916660013
|
£2.16
|
£2.59
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-3600210124.A273
3600210124
|
£2.80
|
£3.36
|
|
|
35 - SHIM 0.2 MM
BSD-1600136010.A55
1600136010
|
£2.61
|
£3.13
|
|
|
35 - SHIM 0.3 MM
BSD-1600136011.A268
1600136011
|
£2.16
|
£2.59
|
|
|
35 - SHIM 0.1 MM
BSD-1600136012.A55
1600136012
|
£1.75
|
£2.10
|
|
|
36 - SPRING WASHER
BSD-1600150011.A104
1600150011
|
£1.75
|
£2.10
|
|
|
37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A395
1600290016
|
£2.61
|
£3.13
|
|
|
38 - CROWN GEAR Z=36
BSD-1606333601.A84
1606333601
|
£8.49
|
£10.19
|
|
|
39 - SPIRAL SPRING
BSD-1604652013.A465
1604652013
|
£1.75
|
£2.10
|
|
|
40 - SPRING RETAINING RING DIN 472-25x1.2MM
BSD-2916660009.A142
2916660009
|
£2.16
|
£2.59
|
|
|
41 - NEEDLE BEARING dia8xdia12x8 MM
BSD-1600910018.A666
1600910018
|
£5.30
|
£6.36
|
|
|
42 - GROOVE BALL BEARING 12x32x10
BSD-1600905006.A119
1600905006
|
£12.04
|
£14.45
|
|
|
43 - BEVEL GEAR Z=11
BSD-1606333242.A74
1606333242
|
£48.38
|
£58.06
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A0
1603300016
|
£1.75
|
£2.10
|
|
|
47 - TAPPING SCREW DIN 7971-ST3.9x13-F
BSD-2910211018.A277
2910211018
|
£1.75
|
£2.10
|
|
|
48 - TAPPING SCREW DIN 7971-ST2.9x9.5-F
BSD-2910211005.A32
2910211005
|
£1.75
|
£2.10
|
|
|
49 - TAPPING SCREW DIN7981-ST3.9x19-F-Z
BSD-2912401420.A1
2912401420
|
£1.75
|
£2.10
|
|
|
50 - TAPPING SCREW DIN 7971-ST3.9x22-F
BSD-2910211021.A613
2910211021
|
£1.75
|
£2.10
|
|
|
53 - CONNECTING CABLE L=95 MM
BSD-1604448005.A26
1604448005
|
£2.80
|
£3.36
|
|
|
55 - TAPPING SCREW DIN7981-ST3.9x22-C-Z
BSD-2912401021.A23
2912401021
|
£1.75
|
£2.10
|
|
|
150 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A322
1900452012
|
£1.75
|
£2.10
|
|
|
650/10 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A689
160202509T
|
£3.72
|
£4.47
|
|
|
650/30 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A0
1607950052
|
£3.72
|
£4.47
|
|
|
650/40 - FASTENING FLANGE
BSD-2605703023.A4
2605703023
|
-
|
|
|
|
650/50 - SINGLE-HEAD ENG. WRENCH SW17
BSD-2607950511.A789
2607950511
|
£4.26
|
£5.11
|
|
|
652/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A321
2910022197
|
-
|
|
|
|
700 - SUCTION HOOD dia 125 MM
BSD-2605510066.A4
2605510066
|
-
|
|
|
|
700/10 - PROTECTIVE COVER dia 115 MM
BSD-1605510201.A13
1605510201
|
-
|
|
|
|
700/10/20 - SOCKET HEAD CAP SCREW DIN 84-M 6x16-8.8
BSD-2910022197.A322
2910022197
|
-
|
|
|
|
700/20 - GUIDE BLOCK
BSD-1608135004.A9
1608135004
|
-
|
|
|
|
700/20/30 - ROUND-HEAD BOLT DIN 603-M 5x16
BSD-2910281158.A60
2910281158
|
-
|
|
|
|
700/20/40 - WING NUT M 5 DIN 315-G-5
BSD-2915191105.A11
2915191105
|
-
|
|
|
|
700/20/50 - COMPRESSION SPRING
BSD-1604643004.A0
1604643004
|
-
|
|
|
|
750/20 - ROUND NUT M14
BSD-1603340015.A42
1603340015
|
£3.87
|
£4.64
|
|
|
752 - PROTECTIVE COVER dia 115 MM(4 1/2)
BSD-2605510125.A69
2605510125
|
£27.23
|
£32.68
|
|
|
810 - CARBON BRUSH
BSD-1607014128.A8
1607014128
|
-
|
|
|
|
816 - BRUSH HOLDER
BSD-1600A003G4.A243
1600A003G4
|
£3.72
|
£4.47
|
|
|
828 - BEARING FLANGE
BSD-1607000936.A94
1607000936
|
£27.23
|
£32.68
|
|
|
830 - ARMATURE WITH FAN 115-120V
BSD-1604010261.A6
1604010261
|
£46.82
|
£56.18
|
|
|
832 - GRINDING SPINDLE
BSD-1607000D6A.A326
1607000D6A
|
£7.36
|
£8.83
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A846
160111A3H3
|
£2.61
|
£3.13
|
|
