Bosch GWS 22-230 H / 3601H82103 / --- 230 Volt Spare Parts

An exploded drawing and listing for the Bosch GWS 22-230 H / 3601H82103 / --- 230 Volt

	Ex VAT	Inc VAT
1 - MOTOR HOUSING BSD-1605108275.A47 1605108275	£16.41	£19.69
6 - GROMMET dia10.5-dia11.0x100 MM BSD-1600703036.A114 1600703036	£2.16	£2.59
7 - FASTENING CLAMP BSD-1601302018.A357 1601302018	£1.75	£2.10
9 - MANUFACTURER'S NAMEPLATE BSD-1618B00025.A2 1618B00025	-
21/29 - O-RING 8.0x1.0 MM BSD-1600210045.A445 1600210045	£1.75	£2.10
21/51 - PLAIN BEARING dia14 MM BSD-1600200031.A180 1600200031	£2.80	£3.36
24 - HANDLE BSD-1605132149.A80 1605132149	£10.82	£12.99
25 - GRINDING SPINDLE BSD-160312305U.A97 160312305U	£13.12	£15.75
26 - BEVEL GEAR SET BSD-1600A012VU.A46 1600A012VU	-
28 - O-RING 79.0x1.78 MM BSD-1600210033.A536 1600210033	£1.75	£2.10
30 - AIR DISTRIBUTOR BSD-1600591029.A145 1600591029	£2.61	£3.13
31 - AIR-DEFLECTOR RING BSD-1600591028.A216 1600591028	£2.33	£2.80
32 - RETAINING SNAP RING BSD-1600290019.A329 1600290019	£1.75	£2.10
33 - ROTARY SHAFT LIP SEAL 16 MM BSD-1600290064.A92 1600290064	£2.16	£2.59
34 - SHIM 0.15 MM BSD-1600190020.A644 1600190020	£1.75	£2.10
34 - SHIM 0.3 MM BSD-1600190021.A183 1600190021	£2.61	£3.13
34 - SHIM 0.1 MM BSD-1600190022.A644 1600190022	£1.75	£2.10
34 - SHIM 0.2 MM BSD-1600190037.A92 1600190037	£1.75	£2.10
34 - SHIM 0.25 MM BSD-1600190038.A295 1600190038	£1.75	£2.10
34 - SHIM 0.35 MM BSD-1600190039.A92 1600190039	£1.75	£2.10
34 - SHIM 0.4 MM BSD-1600190040.A295 1600190040	£1.75	£2.10
35 - FELT WASHER BSD-1600205034.A387 1600205034	£1.75	£2.10
38 - RUBBER RING 7 MM BSD-1600206020.A353 1600206020	£1.75	£2.10
39 - RUBBER RING BSD-1600206030.A600 1600206030	£1.75	£2.10
45 - HEX NUT M10. SW14 BSD-1603300019.A528 1603300019	£1.75	£2.10
53 - SOCKET HOUSING BSD-1618B00804.A85 1618B00804	£1.66	£1.99
60 - THREAD-FORMING TAP. SCREW TT M5x18 MM BSD-1603435023.A632 1603435023	£2.16	£2.59
61 - TAPPING SCREW DIN 7981-4.8x38-C-Z-ST BSD-2912401038.A342 2912401038	£1.75	£2.10
62 - TAPPING SCREW 4.8x55 BSD-1603435060.A101 1603435060	£1.75	£2.10
63 - PAN HEAD SCREW M4x10 MM BSD-1603410014.A355 1603410014	£1.75	£2.10
64 - PLASTIC-CUTTING SCREW St3.9x12 BSD-1603435042.A266 1603435042	£1.75	£2.10
65 - TAPPING SCREW DIN 7981-3.9x19-C-Z-ST BSD-2912401020.A1287 2912401020	£2.16	£2.59
651 - PROTECTIVE COVER BSD-1600A00XM0.A153 1600A00XM0	£21.68	£26.01
802 - FIELD 230V BSD-1604220435.A37 1604220435	£37.72	£45.27
803 - ARMATURE 230V BSD-1604011296.A51 1604011296	£61.98	£74.38
804 - ON-OFF SWITCH BSD-1607000C13.A18 1607000C13	£37.27	£44.72
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F BSD-1607000227.A181 1607000227	£23.86	£28.63
808 - NAMEPLATE BSD-160111A3H3.A287 160111A3H3	£2.61	£3.13
810 - CARBON-BRUSH SET BSD-1607014171.A361 1607014171	£14.91	£17.89
810 - CARBON-BRUSH SET 10 x 1 607 014 171 BSD-1607000480.A33 1607000480	£102.57	£123.08
813 - GROOVE BALL BEARING 8x22x7 BSD-1600905011.A381 1600905011	£5.58	£6.70
814 - GROOVE BALL BEARING BSD-1600905028.A152 1600905028	£12.04	£14.45
816 - BRUSH HOLDER BSD-1604336048.A117 1604336048	£7.36	£8.83
821 - GEAR HOUSING BSD-1607000C32.A43 1607000C32	£40.80	£48.96
822 - BEARING FLANGE dia230 MM BSD-1607000C22.A51 1607000C22	£30.28	£36.33
822/22/48 - RETAINING CLIP BSD-1600119010.A247 1600119010	£1.75	£2.10
822/22/50 - GROOVE BALL BEARING 17x40x12 BSD-1600905026.A208 1600905026	£8.67	£10.41
823 - SEALING CAP BSD-1618B00802.A211 1618B00802	£4.27	£5.12
835 - FAN BSD-1600A00J93.A278 1600A00J93	£2.80	£3.36
837 - SEAL RING BSD-1600290036.A316 1600290036	£2.16	£2.59
840 - PUSH-BUTTON BSD-1607000354.A120 1607000354	£6.52	£7.83
846 - RETAINING WASHER BSD-1607000342.A215 1607000342	£3.72	£4.47
851 - NEEDLE-ROLLER BEARING dia14 MM BSD-2600910001.A1137 2600910001	£4.26	£5.11
882 - STOPPER BSD-1619P06597.A5 1619P06597	£4.26	£5.11
890 - O-RING 20.35x1.78 MM BSD-1600210039.A324 1600210039	£2.16	£2.59
891 - AUXILIARY HANDLE M14 BSD-1602025022.A604 1602025022	£13.41	£16.09
891/1 - AUXILIARY HANDLE M14. dia37x115 MM BSD-1602025030.A755 1602025030	£18.96	£22.75
892 - PIN-TYPE FACE-WRENCH BSD-1607950061.A372 1607950061	£5.42	£6.50
893 - CLAMPING FLANGE dia22.3xdia42 MM BSD-2605703014.A1223 2605703014	£7.36	£8.83
894 - ROUND NUT M14 BSD-1603345043.A783 1603345043	£8.67	£10.41
896 - FAST LOCKING FLANGE M14. SDS-CLIC BSD-1603340027.A552 1603340027	£46.82	£56.18
