4 - SWITCH
BSD-1607200200.A12
1607200200
|
£12.64
|
£15.17
|
|
|
6 - GROMMET
BSD-1600703040.A28
1600703040
|
£2.27
|
£2.72
|
|
|
7 - FASTENING CLAMP
BSD-1601302017.A594
1601302017
|
£1.84
|
£2.21
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-1601118N92.A1
1601118N92
|
£2.33
|
£2.80
|
|
|
13 - BALL BEARING 7x19x6
BSD-2600905032.A648
2600905032
|
£5.57
|
£6.68
|
|
|
17 - SPIRAL SPRING
BSD-1604652013.A682
1604652013
|
£1.84
|
£2.21
|
|
|
24 - COVER
BSD-1605500227.A34
1605500227
|
£2.16
|
£2.59
|
|
|
25 - HOUSING COVER
BSD-1605500251.A47
1605500251
|
£7.72
|
£9.27
|
|
|
29 - AIR-DEFLECTOR RING
BSD-1600591025.A152
1600591025
|
£2.61
|
£3.13
|
|
|
32 - GRINDING SPINDLE
BSD-1607000D6A.A51
1607000D6A
|
£7.36
|
£8.83
|
|
|
33 - O-RING 46.0x1.1 MM
BSD-1600210035.A217
1600210035
|
£1.84
|
£2.21
|
|
|
35 - SHIM 0.1 MM
BSD-1600136013.A295
1600136013
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.15 MM
BSD-1600136020.A223
1600136020
|
£3.72
|
£4.47
|
|
|
35 - SHIM 0.2 MM
BSD-1600136014.A225
1600136014
|
£2.74
|
£3.29
|
|
|
35 - SHIM 0.3 MM
BSD-1600136015.A295
1600136015
|
£2.74
|
£3.29
|
|
|
45 - HEX NUT M7. SW10
BSD-1603300016.A199
1603300016
|
£1.84
|
£2.21
|
|
|
47 - TORX OVAL-HEAD SCREW 4x12
BSD-2603490021.A552
2603490021
|
£1.84
|
£2.21
|
|
|
49 - THREAD-FORMING TAP. SCREW M4x16
BSD-2914491410.A134
2914491410
|
£1.84
|
£2.21
|
|
|
50 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A1339
2603490023
|
£1.84
|
£2.21
|
|
|
53 - TORX OVAL-HEAD SCREW
BSD-1603435078.A166
1603435078
|
£1.84
|
£2.21
|
|
|
54 - TORX OVAL-HEAD SCREW 4x30
BSD-1603414026.A84
1603414026
|
£1.84
|
£2.21
|
|
|
80 - SEALING DISK
BSD-3600150021.A152
3600150021
|
£3.99
|
£4.79
|
|
|
104 - O-RING 4.5x1.0 MM
BSD-1600210044.A184
1600210044
|
£1.84
|
£2.21
|
|
|
105 - INSULATING PLATE
BSD-1601008005.A119
1601008005
|
£4.26
|
£5.11
|
|
|
107 - INSULATING PART
BSD-1600712030.A113
1600712030
|
£1.75
|
£2.10
|
|
|
301/1 - MOTOR HOUSING
BSD-1605108269.A1
1605108269
|
£12.64
|
£15.17
|
|
|
301/16 - BRUSH HOLDER
BSD-1601323025.A191
1601323025
|
£3.91
|
£4.69
|
|
|
301/18 - SWITCH HANDLE
BSD-1602026088.A37
1602026088
|
£1.75
|
£2.10
|
|
|
301/19 - COMPRESSION SPRING
BSD-1604611026.A371
1604611026
|
£1.84
|
£2.21
|
|
|
301/20 - ADJUSTING SLIDE
BSD-1602319011.A51
1602319011
|
£1.75
|
£2.10
|
|
|
301/48 - LENS HEAD SCREW 3x10 ST
BSD-1613435034.A136
1613435034
|
£1.84
|
£2.21
|
|
|
321/14 - GROOVE BALL BEARING 8x22x7
BSD-1600905032.A258
1600905032
|
£5.58
|
£6.70
|
|
|
321/27 - RUBBER RING
BSD-1600206025.A669
1600206025
|
£2.16
|
£2.59
|
|
|
321/30 - AIR-DEFLECTOR RING
BSD-1600591014.A329
1600591014
|
£2.74
|
£3.29
|
|
|
321/37 - ROTARY SHAFT LIP SEAL
BSD-1600290016.A340
1600290016
|
£2.74
|
£3.29
|
|
|
321/40 - RETAINING CLIP
BSD-1600119011.A420
1600119011
|
£2.27
|
£2.72
|
|
|
321/41 - PLAIN BEARING
BSD-1600200029.A209
1600200029
|
£4.48
|
£5.37
|
|
|
343 - CATCH LEVER
BSD-1607000742.A120
1607000742
|
£7.72
|
£9.27
|
|
|
343/44 - COMPRESSION SPRING
BSD-1604611042.A131
1604611042
|
£1.84
|
£2.21
|
|
|
651 - PROTECTIVE COVER
BSD-1600A00XK9.A17
1600A00XK9
|
£14.72
|
£17.67
|
|
|
802 - FIELD 220-240V
BSD-1607000397.A17
1607000397
|
£36.63
|
£43.96
|
|
|
803 - ARMATURE WITH FAN 230V
BSD-1604010A23.A1
1604010A23
|
£63.50
|
£76.20
|
|
|
805 - POWER SUPPLY CORD EU 4.15m 2 x 1.0mm H07 RN-F
BSD-1607000392.A83
1607000392
|
£21.52
|
£25.83
|
|
|
808 - NAMEPLATE
BSD-160111A3H3.A66
160111A3H3
|
£2.74
|
£3.29
|
|
|
810 - CARBON-BRUSH SET
BSD-1607014176.A218
1607014176
|
£13.78
|
£16.54
|
|
|
810 - CARBON-BRUSH SET 10 x 1 607 014 176
BSD-1607000482.A22
1607000482
|
£93.88
|
£112.65
|
|
|
813 - PARTS SET
BSD-1607000378.A42
1607000378
|
£6.52
|
£7.83
|
|
|
818 - PAN HEAD SCREW DIN 85-AM3x6-CUZN
BSD-2910110048.A360
2910110048
|
£1.84
|
£2.21
|
|
|
821 - GEAR HOUSING
BSD-1605806533.A0
1605806533
|
£33.74
|
£40.49
|
|
|
828 - BEARING FLANGE
BSD-1607000D6D.A8
1607000D6D
|
£14.91
|
£17.89
|
|
|
828/04 - O-RING 47.0x1.5 MM
BSD-3600210109.A194
3600210109
|
£2.27
|
£2.72
|
|
|
831 - SPRING ELEMENT
BSD-1601290013.A65
1601290013
|
£1.84
|
£2.21
|
|
|
835 - FAN
BSD-1606610132.A188
1606610132
|
£2.27
|
£2.72
|
|
|
838 - GEAR UNIT
BSD-1607000D50.A2
1607000D50
|
£71.84
|
£86.21
|
|
|
840 - PUSH-BUTTON
BSD-1607000A71.A54
1607000A71
|
£3.91
|
£4.69
|
|
|
851 - SPEED GOVERNOR 220-240V
BSD-1607233278.A2
1607233278
|
£50.80
|
£60.96
|
|
|
860 - CONNECTING CABLE
BSD-1604448023.A40
1604448023
|
£1.75
|
£2.10
|
|
|
890 - O-RING 20.35x1.78 MM
BSD-1600210039.A178
1600210039
|
£2.27
|
£2.72
|
|
|
891 - AUXILIARY HANDLE M10. dia32.5x105 MM
BSD-160202509T.A1004
160202509T
|
£3.91
|
£4.69
|
|
|
891 - AUXILIARY HANDLE M10 ANTI-VIBRATION
BSD-16020250A0.A30
16020250A0
|
£21.42
|
£25.71
|
|
|
892 - ROUND NUT M14
BSD-1603345043.A632
1603345043
|
£9.11
|
£10.93
|
|
|
893 - PIN-TYPE FACE-WRENCH
BSD-1607950052.A229
1607950052
|
£3.91
|
£4.69
|
|
|
895 - CLAMPING FLANGE dia22.3xdia42 MM
BSD-2605703014.A1013
2605703014
|
£7.72
|
£9.27
|
|
|
896 - FAST LOCKING FLANGE M14. SDS-CLIC
BSD-1603340027.A523
1603340027
|
£49.16
|
£58.99
|
|
