1 - HOUSING SECTION
BSD-2605105964.A11
2605105964
|
£37.27
|
£44.72
|
|
|
2 - FIELD 110V
BSD-2604220751.A2
2604220751
|
£33.74
|
£40.49
|
|
|
4 - SWITCH
BSD-2607200688.A20
2607200688
|
£16.41
|
£19.69
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.0mm H05 RN-F
BSD-2604460204.A4
2604460204
|
£33.22
|
£39.87
|
|
|
6 - GROMMET dia6.4-dia7.2x76 MM
BSD-2600703017.A188
2600703017
|
£2.74
|
£3.29
|
|
|
9 - MANUFACTURER'S NAMEPLATE GSS 230 AVE
BSD-2601112337.A2
2601112337
|
£2.61
|
£3.13
|
|
|
14 - GROOVE BALL BEARING
BSD-1619P00290.A1
1619P00290
|
£6.85
|
£8.22
|
|
|
16 - BRUSH HOLDER
BSD-2604337003.A121
2604337003
|
£2.16
|
£2.59
|
|
|
19 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A30
2603490017
|
£2.27
|
£2.72
|
|
|
20 - REFERENCE PLATE
BSD-2601111477.A13
2601111477
|
£2.74
|
£3.29
|
|
|
22 - SUCTION PIECE
BSD-2601328094.A0
2601328094
|
£3.72
|
£4.47
|
|
|
23 - SPRING RETAINING RING DIN 471 9x1MM
BSD-2916640006.A85
2916640006
|
£1.84
|
£2.21
|
|
|
24 - SEALING DISK
BSD-2600590013.A17
2600590013
|
£2.16
|
£2.59
|
|
|
25 - V-RING
BSD-2600290030.A42
2600290030
|
£2.94
|
£3.53
|
|
|
26 - NEEDLE BEARING
BSD-2600910012.A1
2600910012
|
£5.30
|
£6.36
|
|
|
27 - INNER RING
BSD-2600400035.A6
2600400035
|
£10.10
|
£12.12
|
|
|
28 - ECCENTRIC
BSD-2602210045.A6
2602210045
|
£22.60
|
£27.12
|
|
|
29 - FAN
BSD-2606610085.A22
2606610085
|
£9.11
|
£10.93
|
|
|
30 - THREAD-FORMING TAP. SCREW M4x8
BSD-2603410048.A199
2603410048
|
£1.84
|
£2.21
|
|
|
31 - SHAFT SEAL
BSD-2600290031.A5
2600290031
|
£2.80
|
£3.36
|
|
|
32 - SEALING COVER
BSD-2600500019.A1
2600500019
|
£1.75
|
£2.10
|
|
|
34 - SANDER PLATE
BSD-2600009019.A3
2600009019
|
£35.42
|
£42.51
|
|
|
35 - HEX NUT DIN 439-BM8-04
BSD-2915051107.A44
2915051107
|
£1.84
|
£2.21
|
|
|
37 - TAPPING SCREW
BSD-2603435086.A102
2603435086
|
£1.84
|
£2.21
|
|
|
40 - THREAD-FORMING TAP. SCREW
BSD-2603435042.A76
2603435042
|
£1.75
|
£2.10
|
|
|
41 - TORX OVAL-HEAD SCREW 3x10
BSD-2603490017.A29
2603490017
|
£2.27
|
£2.72
|
|
|
42 - SUPPRESSOR BOX
BSD-2604465115.A6
2604465115
|
£7.72
|
£9.27
|
|
|
43 - DAMPING ELEMENT
BSD-2603203041.A10
2603203041
|
£1.75
|
£2.10
|
|
|
44 - SPEED GOVERNOR 110-127V
BSD-1607233557.A2
1607233557
|
£42.84
|
£51.41
|
|
|
45 - SQUARE NUT DIN 562-M6-04
BSD-2915121006.A65
2915121006
|
£2.74
|
£3.29
|
|
|
46 - TORX OVAL-HEAD SCREW 4x20
BSD-2603490023.A28
2603490023
|
£1.84
|
£2.21
|
|
|
47 - HOUSING COVER
BSD-2605500208.A10
2605500208
|
£12.64
|
£15.17
|
|
|
48 - SCREW 4x16
BSD-2603490022.A3190
2603490022
|
£1.84
|
£2.21
|
|
|
49 - PUSHER
BSD-2601035002.A23
2601035002
|
£2.27
|
£2.72
|
|
|
50 - SUCTION SOCKET
BSD-2601328054.A18
2601328054
|
£3.72
|
£4.47
|
|
|
51 - FELT STRIP
BSD-2601005017.A15
2601005017
|
£1.75
|
£2.10
|
|
|
54 - TENSIONING BRACKET
BSD-2609200378.A4
2609200378
|
£17.22
|
£20.67
|
|
|
56 - LEVER
BSD-2601901020.A4
2601901020
|
£5.87
|
£7.04
|
|
|
57 - THREAD-FORMING TAP. SCREW
BSD-2603410051.A29
2603410051
|
£1.84
|
£2.21
|
|
|
58 - SPRING WASHER
BSD-2600100713.A2
2600100713
|
£1.84
|
£2.21
|
|
|
59 - GUIDE BUSHING
BSD-2600499078.A12
2600499078
|
£2.16
|
£2.59
|
|
|
61 - PRESSURE BAR
BSD-2601014020.A2
2601014020
|
£4.26
|
£5.11
|
|
|
62 - COILED SPRING
BSD-2604651029.A14
2604651029
|
£2.94
|
£3.53
|
|
|
655 - DUST CHAMBER
BSD-2605411228.A6
2605411228
|
£47.95
|
£57.54
|
|
|
656 - AUXILIARY HANDLE
BSD-2602026175.A5
2602026175
|
£17.22
|
£20.67
|
|
|
680 - OFFSET SCREWDRIVER DIN 911-SW5
BSD-1907950006.A895
1907950006
|
£4.48
|
£5.37
|
|
|
803 - ARMATURE 110V
BSD-2604011953.A3
2604011953
|
£72.18
|
£86.62
|
|
|
803/3/6 - FAN
BSD-2606610076.A30
2606610076
|
£3.91
|
£4.69
|
|
|
803/13 - GROOVE BALL BEARING 7x19x6
BSD-1610905025.A438
1610905025
|
£6.85
|
£8.22
|
|
|
805 - POWER SUPPLY CORD EU 230V 4.15m 2 x 1.0mm H05 RN-F
BSD-1607000386.A634
1607000386
|
£22.60
|
£27.12
|
|
|
808 - NAMEPLATE
BSD-160111A218.A0
160111A218
|
-
|
|
|
|
810 - CARBON BRUSH
BSD-1607014117.A208
1607014117
|
£10.61
|
£12.73
|
|
|
821 - SUCTION HOOD
BSD-2605510903.A2
2605510903
|
£68.42
|
£82.10
|
|
|
833 - SPRING
BSD-2608005902.A39
2608005902
|
£16.41
|
£19.69
|
|
|
836 - MOTOR HOUSING
BSD-2605105966.A14
2605105966
|
£25.05
|
£30.06
|
|
|
852 - SWING-PLATE
BSD-2601099901.A3
2601099901
|
£72.18
|
£86.62
|
|
