Bosch GSR 14.4 VPE-2 / 0601946420 / EU 14.4 Volt Spare Parts

An exploded drawing and listing for the Bosch GSR 14.4 VPE-2 / 0601946420 / EU 14.4 Volt

	Ex VAT	Inc VAT
1 - HOUSING SECTION BSD-2605104628.A7 2605104628	-
2/10 - PINION BSD-2606316182.A31 2606316182	£1.75	£2.10
5 - ADJUSTING SLIDE BSD-2601099082.A33 2601099082	£1.75	£2.10
9 - MANUFACTURER'S NAMEPLATE BSD-2601119600.A4 2601119600	-
20 - REFERENCE PLATE BSD-2601119601.A1 2601119601	-
25 - KEYLESS CHUCK BSD-2608572160.A1 2608572160	-
32 - ADJUSTING SLIDE BSD-2601099078.A2 2601099078	£1.32	£1.58
50 - INTERMEDIATE FLANGE BSD-2605719027.A43 2605719027	£2.61	£3.13
91 - ACCUMULATOR BATTERY 14.4V.2.0Ah.NiCd BSD-2607335209.A2 2607335209	-
93 - SCREWDRIVER BLADE BSD-2608521018.A18 2608521018	£5.01	£6.01
96 - SUPPORT BSD-2608040131.A94 2608040131	£1.95	£2.34
101 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A460 2603490018	£1.75	£2.10
102 - RETAINING BRACKET BSD-2601329041.A140 2601329041	£2.33	£2.80
107 - COUNTERSUNK-HEAD SCREW BSD-2603421008.A23 2603421008	£1.75	£2.10
653 - FAST CHARGER EU 230/7.2-14.4V. 30 MIN. BSD-2607224701.A377 2607224701	£88.07	£105.68
798 - CARRYING LOOP BSD-2601398009.A18 2601398009	-
802 - DC MOTOR 14.4V BSD-2607022963.A0 2607022963	£37.72	£45.27
804 - ON-OFF SWITCH BSD-2607200353.A46 2607200353	-
845 - PLANETARY GEAR TRAIN BSD-2606200908.A27 2606200908	-
899 - CORDLESS DRILL DRIVER BSD-0601946420.A1 0601946420	-

Attribute Name	Value
Brand	Bosch
