Bosch GSR 12 VE-2 / 0601951520 / EU 12 Volt Spare Parts

An exploded drawing and listing for the Bosch GSR 12 VE-2 / 0601951520 / EU 12 Volt

	Ex VAT	Inc VAT
1 - HOUSING SECTION BSD-2605105027.A8 2605105027	£20.42	£24.51
2/1 - PINION BSD-2606316188.A18 2606316188	£2.16	£2.59
5 - ADJUSTING SLIDE BSD-2601099085.A30 2601099085	-
25 - KEYLESS CHUCK BSD-2608572160.A30 2608572160	-
32 - ADJUSTING SLIDE BSD-2601099086.A43 2601099086	£2.27	£2.72
50 - INTERMEDIATE FLANGE BSD-2605719901.A18 2605719901	-
93 - SCREWDRIVER BLADE BSD-2608521018.A62 2608521018	£5.01	£6.01
96 - SUPPORT BSD-2608040131.A43 2608040131	£1.95	£2.34
101 - TORX OVAL-HEAD SCREW 3x18 BSD-2603490018.A584 2603490018	£1.75	£2.10
107 - COUNTERSUNK-HEAD SCREW BSD-2603421008.A62 2603421008	£1.84	£2.21
802 - DC MOTOR 12V BSD-2607022876.A0 2607022876	£88.07	£105.68
804 - ON-OFF SWITCH BSD-2607200421.A11 2607200421	£50.80	£60.96
809 - MANUFACTURER'S NAMEPLATE BSD-2601116136.A0 2601116136	£4.48	£5.37
809 - MANUFACTURER'S NAMEPLATE GSR 12 PROFI BSD-2601116544.A0 2601116544	£4.26	£5.11
820 - NAMEPLATE BSD-2601116137.A10 2601116137	£4.48	£5.37
845 - PLANETARY GEAR TRAIN BSD-2606200917.A1 2606200917	£85.90	£103.08
899 - BATT-OPER SCREWDRIVER BSD-0601951520.A1 0601951520	-
