1 - MOTOR HOUSING
BSD-1619P07704.A1
1619P07704
|
£22.60
|
£27.12
|
|
|
2 - FIELD 220-240V
BSD-1619P05379.A2
1619P05379
|
£33.74
|
£40.49
|
|
|
4 - SWITCH
BSD-1619P07720.A2
1619P07720
|
£19.91
|
£23.89
|
|
|
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07 RN-F
BSD-1604460449.A9
1604460449
|
£28.59
|
£34.31
|
|
|
6 - GROMMET
BSD-1619P07722.A2
1619P07722
|
£2.16
|
£2.59
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A92
1601302018
|
£1.75
|
£2.10
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-160111C0ZT.A1
160111C0ZT
|
£2.61
|
£3.13
|
|
|
10 - STICKER
BSD-160111C0ZU.A1
160111C0ZU
|
£2.16
|
£2.59
|
|
|
21 - PROTECTIVE CAP
BSD-1619P07829.A2
1619P07829
|
£4.26
|
£5.11
|
|
|
22 - PROTECTION SLEEVE
BSD-1619P07724.A1
1619P07724
|
£21.52
|
£25.83
|
|
|
25 - STOPPING DEVICE
BSD-1619P07742.A2
1619P07742
|
£8.67
|
£10.41
|
|
|
27 - AIR-DEFLECTOR RING
BSD-1619P07739.A1
1619P07739
|
£2.61
|
£3.13
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A144
1614621000
|
£2.80
|
£3.36
|
|
|
29 - WASHER
BSD-1619P10522.A3
1619P10522
|
£2.16
|
£2.59
|
|
|
30 - SUPPORTING DISC
BSD-1619P07715.A1
1619P07715
|
£10.61
|
£12.73
|
|
|
31 - SUPPORTING DISC
BSD-1619P07743.A9
1619P07743
|
£7.36
|
£8.83
|
|
|
33 - TOOLHOLDER
BSD-1619P07748.A1
1619P07748
|
£39.13
|
£46.96
|
|
|
34 - FLANGE
BSD-1610516013.A37
1610516013
|
£1.75
|
£2.10
|
|
|
35 - HAMMER PIPE
BSD-1619P07734.A3
1619P07734
|
£72.18
|
£86.62
|
|
|
36 - INTERMEDIATE SLEEVE
BSD-1619P07702.A3
1619P07702
|
£7.36
|
£8.83
|
|
|
37 - CYLINDRICAL ROLLER
BSD-1619P07749.A3
1619P07749
|
£1.75
|
£2.10
|
|
|
38 - COVERING HOOD
BSD-1619P07710.A2
1619P07710
|
£13.12
|
£15.75
|
|
|
42 - BRUSH HOLDER
BSD-1619P07754.A2
1619P07754
|
£22.76
|
£27.31
|
|
|
43 - FAN COVER
BSD-1619P07711.A2
1619P07711
|
£12.64
|
£15.17
|
|
|
44 - COMPRESSION SPRING
BSD-1619P07755.A2
1619P07755
|
£2.52
|
£3.02
|
|
|
45 - CONTROL BUSHING
BSD-1619P07756.A2
1619P07756
|
£11.30
|
£13.56
|
|
|
48 - CLUTCH SLEEVE
BSD-1619P07780.A1
1619P07780
|
£6.52
|
£7.83
|
|
|
52 - STOP SLEEVE
BSD-1619P07738.A1
1619P07738
|
£6.52
|
£7.83
|
|
|
53 - SUPPORTING DISC
BSD-1619P07792.A2
1619P07792
|
£2.74
|
£3.29
|
|
|
54 - GUIDE BUSHING
BSD-1610231001.A1
1610231001
|
£12.04
|
£14.45
|
|
|
57 - STRIKER
BSD-1619P07762.A2
1619P07762
|
£21.68
|
£26.01
|
|
|
69 - RETAINING BRACKET
BSD-1610099004.A26
1610099004
|
£2.80
|
£3.36
|
|
|
72 - ECCENTRIC COG WHEEL Z=43
BSD-1619P07723.A2
1619P07723
|
£41.62
|
£49.95
|
|
|
74 - GUIDE PLATE
BSD-1619P07772.A2
1619P07772
|
£2.61
|
£3.13
|
|
|
75 - HANDLE
BSD-1619P07708.A2
1619P07708
|
£15.65
|
£18.78
|
|
|
76 - MAGNET
BSD-1619P07789.A2
1619P07789
|
£3.91
|
£4.69
|
|
|
79 - TORX OVAL-HEAD SCREW M5x12-TORX.T25
BSD-1613435015.A25
1613435015
|
£2.74
|
£3.29
|
|
|
81 - HANDLE COVER
BSD-1619P07709.A2
1619P07709
|
£13.12
|
£15.75
|
|
|
82 - SUPPORT BRACKET
BSD-1619P07786.A2
1619P07786
|
£1.75
|
£2.10
|
|
|
84 - AUXILIARY HANDLE
BSD-1615132109.A17
1615132109
|
£23.86
|
£28.63
|
|
|
86 - HEX SCREW DIN 931-M8x130-8.8
BSD-2911011270.A4
2911011270
|
£4.48
|
£5.37
|
|
|
87 - CLAMPING BAND
BSD-1619P07800.A2
1619P07800
|
£9.11
|
£10.93
|
|
|
88 - STAR KNOB M8
BSD-1619P16922.A51
1619P16922
|
£6.45
|
£7.74
|
|
|
89 - CLAMPING PIECE
BSD-1619P07803.A2
1619P07803
|
£2.27
|
£2.72
|
|
|
90 - CATCH DISK
BSD-1610190053.A36
1610190053
|
£2.49
|
£2.99
|
|
|
95 - O-RING 32.0x1.5 MM
BSD-1610210173.A2
1610210173
|
£2.16
|
£2.59
|
|
|
98 - SHIM RING 1.0 MM
BSD-1610101015.A30
1610101015
|
£1.84
|
£2.21
|
|
|
101 - RETAINING RING
BSD-1610224009.A6
1610224009
|
£1.75
|
£2.10
|
|
|
103 - BUSHING
BSD-1619P07781.A2
1619P07781
|
£11.87
|
£14.24
|
|
|
104 - O-RING
BSD-1619P07740.A2
1619P07740
|
£2.80
|
£3.36
|
|
|
105 - DRIVING PIN
BSD-1613120021.A1
1613120021
|
£1.75
|
£2.10
|
|
|
111 - BUSHING
BSD-1610290064.A45
1610290064
|
£1.84
|
£2.21
|
|
|
112 - HEX NUT DIN 936-M8x1-8
BSD-1613300008.A38
1613300008
|
£2.74
|
£3.29
|
|
|
113 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A357
1613435009
|
£1.75
|
£2.10
|
|
|
117 - NEEDLE-ROLLER ASSEMBLY
BSD-1619P07713.A2
1619P07713
|
£3.91
|
£4.69
|
|
|
126 - SCREW 4x16
BSD-2603490022.A440
2603490022
|
£1.84
|
£2.21
|
|
|
129 - HOLDING SLEEVE
BSD-1619P10665.A0
1619P10665
|
£12.04
|
£14.45
|
|
|
130 - COVER
BSD-1619P07796.A2
1619P07796
|
£6.85
|
£8.22
|
|
|
138 - SEALING FRAME
BSD-1619P07797.A2
1619P07797
|
£2.80
|
£3.36
|
|
|
141 - ROTARY SHAFT LIP SEAL
BSD-1610290066.A45
1610290066
|
£10.61
|
£12.73
|
|
|
143 - RETAINING RING DIN 7993-28x2
BSD-1614601021.A71
1614601021
|
£7.72
|
£9.27
|
|
|
145 - SPRING RETAINING RING
BSD-1610119012.A55
1610119012
|
£2.74
|
£3.29
|
|
|
154 - CLIP
BSD-1619P07801.A2
1619P07801
|
£5.30
|
£6.36
|
|
|
158 - RETAINING RING
BSD-1619P07751.A2
1619P07751
|
£1.75
|
£2.10
|
|
|
160 - DAMPING RING
BSD-1619P07806.A2
1619P07806
|
£7.72
|
£9.27
|
|
|
161 - DAMPING RUBBER
BSD-1610290093.A4
1610290093
|
£1.75
|
£2.10
|
|
|
162 - O-RING 24.0x4.0 MM
BSD-1610210091.A52
1610210091
|
£3.91
|
£4.69
|
|
|
163 - SEAL RING
BSD-1610290065.A16
1610290065
|
£8.54
|
£10.25
|
|
|
165 - O-RING 25.0x4.0 MM
BSD-1610210153.A25
1610210153
|
£7.36
|
£8.83
|
|
|
168 - O-RING 22.0x3.0 MM
BSD-1610210144.A55
1610210144
|
£5.30
|
£6.36
|
|
|
171 - TORX OVAL-HEAD SCREW M5x16-TORX. T25
BSD-1619P07816.A9
1619P07816
|
£1.84
|
£2.21
|
|
|
172 - TORX OVAL-HEAD SCREW M6x30-TORX.T30
BSD-1613435013.A22
1613435013
|
£2.16
|
£2.59
|
|
|
174 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A72
1613435012
|
£2.27
|
£2.72
|
|
|
175 - TAPPING SCREW DIN7981-ST3.9x13-C-Z
BSD-2912401018.A467
2912401018
|
£1.75
|
£2.10
|
|
|
176 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A73
1613435012
|
£2.27
|
£2.72
|
|
|
177 - SCREW ST3.9x32
BSD-1619P07821.A1
1619P07821
|
£1.75
|
£2.10
|
|
|
178 - CONNECTION CABLE
BSD-1619P07822.A3
1619P07822
|
£6.61
|
£7.93
|
|
|
179 - SCREW
BSD-1619P07815.A1
1619P07815
|
£1.75
|
£2.10
|
|
|
182 - FELT SEAL
BSD-1619P09862.A1
1619P09862
|
£2.27
|
£2.72
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A215
1615430010
|
£6.85
|
£8.22
|
|
|
691 - CARRYING CASE
BSD-16054381D1.A10
16054381D1
|
£45.67
|
£54.80
|
|
|
803 - ARMATURE 220-240V
BSD-1619P07761.A2
1619P07761
|
£120.11
|
£144.13
|
|
|
803/13 - GROOVE BALL BEARING 8x24x8
BSD-1610900026.A94
1610900026
|
£12.64
|
£15.17
|
|
|
803/1/14 - GROOVE BALL BEARING 12x32x10
BSD-1610905028.A40
1610905028
|
£16.41
|
£19.69
|
|
|
808 - NAMEPLATE
BSD-160111A4XL.A0
160111A4XL
|
-
|
|
|
|
811 - CARBON-BRUSH SET
BSD-1617014138.A25
1617014138
|
£22.60
|
£27.12
|
|
|
817 - SPIRAL SPRING
BSD-1614652004.A66
1614652004
|
£7.72
|
£9.27
|
|
|
818 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x6-5.8
BSD-2910011082.A83
2910011082
|
£1.75
|
£2.10
|
|
|
821 - BUSHING
BSD-1619P07768.A2
1619P07768
|
£21.52
|
£25.83
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1619P10667.A3
1619P10667
|
£98.57
|
£118.28
|
|
|
841 - STRIKER
BSD-1619P07839.A3
1619P07839
|
£28.59
|
£34.31
|
|
|
849 - CONTROL FORK
BSD-1619P07798.A1
1619P07798
|
£3.72
|
£4.47
|
|
|
854 - GUIDE BUSHING
BSD-1619P07773.A2
1619P07773
|
£21.68
|
£26.01
|
|
|
856 - HAMMER PISTON
BSD-1619P07775.A2
1619P07775
|
£22.76
|
£27.31
|
|
|
873 - HOUSING COVER
BSD-1619P07799.A3
1619P07799
|
£25.05
|
£30.06
|
|
|
884 - AUXILIARY HANDLE
BSD-1619P10294.A3
1619P10294
|
£40.80
|
£48.96
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1619P07788.A3
1619P07788
|
£37.27
|
£44.72
|
|
