2 - FIELD 230V
BSD-1614220122.A10
1614220122
|
£33.74
|
£40.49
|
|
|
4 - SWITCH
BSD-1617200110.A0
1617200110
|
£27.23
|
£32.68
|
|
|
5 - POWER SUPPLY CORD CH 4.15m 2 x 1.0mm H07 RN-F
BSD-1604460449.A17
1604460449
|
£28.59
|
£34.31
|
|
|
6 - GROMMET dia9.7-dia12x89 MM
BSD-1610703053.A199
1610703053
|
£2.74
|
£3.29
|
|
|
7 - FASTENING CLAMP
BSD-1601302018.A798
1601302018
|
£1.75
|
£2.10
|
|
|
9 - STICKER
BSD-1611110C06.A3
1611110C06
|
£3.72
|
£4.47
|
|
|
12 - SUPPRESSION FILTER
BSD-1607328052.A10
1607328052
|
£4.48
|
£5.37
|
|
|
13 - GROOVE BALL BEARING 8x24x8
BSD-1610900026.A13
1610900026
|
£12.64
|
£15.17
|
|
|
14 - GROOVE BALL BEARING 12x32x10
BSD-1610905028.A13
1610905028
|
£16.41
|
£19.69
|
|
|
15 - FAN
BSD-1616610085.A3
1616610085
|
£2.94
|
£3.53
|
|
|
16 - RATCHET SLEEVE
BSD-1610499055.A18
1610499055
|
£7.36
|
£8.83
|
|
|
17 - CATCH DISK
BSD-1610241000.A12
1610241000
|
£3.91
|
£4.69
|
|
|
18 - RETAINING RING
BSD-1614601030.A10
1614601030
|
£2.61
|
£3.13
|
|
|
21 - PROTECTIVE CAP
BSD-1610508038.A29
1610508038
|
£8.54
|
£10.25
|
|
|
22 - PROTECTION SLEEVE
BSD-1610591024.A4
1610591024
|
£18.96
|
£22.75
|
|
|
25 - STOPPING DEVICE
BSD-1612300034.A10
1612300034
|
£3.72
|
£4.47
|
|
|
27 - AIR-DEFLECTOR RING
BSD-1600591032.A1
1600591032
|
£2.94
|
£3.53
|
|
|
28 - COMPRESSION SPRING
BSD-1614621000.A79
1614621000
|
£2.94
|
£3.53
|
|
|
31 - SUPPORTING DISC
BSD-1610251006.A1
1610251006
|
£5.58
|
£6.70
|
|
|
34 - FLANGE
BSD-1610516013.A18
1610516013
|
£1.84
|
£2.21
|
|
|
38 - COVERING HOOD
BSD-1615190088.A5
1615190088
|
£14.91
|
£17.89
|
|
|
42 - BRUSH HOLDER
BSD-1614336041.A2
1614336041
|
£28.59
|
£34.31
|
|
|
43 - FAN COVER
BSD-1615500303.A14
1615500303
|
£10.10
|
£12.12
|
|
|
53 - SUPPORT DISC
BSD-1610102054.A14
1610102054
|
£3.91
|
£4.69
|
|
|
57 - STRIKER
BSD-1618710073.A13
1618710073
|
£27.23
|
£32.68
|
|
|
69 - RETAINING BRACKET
BSD-1610099004.A0
1610099004
|
£2.80
|
£3.36
|
|
|
72 - ECCENTRIC COG WHEEL
BSD-1616317062.A15
1616317062
|
£51.22
|
£61.47
|
|
|
73 - HOUSING COVER
BSD-1615500358.A1
1615500358
|
-
|
|
|
|
75 - HANDLE
BSD-1615132078.A3
1615132078
|
-
|
|
|
|
81 - HANDLE COVER
BSD-1615132079.A11
1615132079
|
£11.30
|
£13.56
|
|
|
84 - AUXILIARY HANDLE
BSD-160202507H.A35
160202507H
|
£11.87
|
£14.24
|
|
|
85 - SUPPORT CLAMP
BSD-1618040074.A21
1618040074
|
£5.30
|
£6.36
|
|
|
86 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A634
1613490002
|
£4.48
|
£5.37
|
|
|
87 - CLAMPING BAND dia62 MM
BSD-1611316019.A3
1611316019
|
£4.26
|
£5.11
|
|
|
95 - O-RING 32.0x1.5 MM
BSD-1610210173.A39
1610210173
|
£2.16
|
£2.59
|
|
|
104 - O-RING 55.0x2.0 MM
BSD-1610210095.A48
1610210095
|
£2.74
|
£3.29
|
|
|
111 - BUSHING
BSD-1610290064.A4
1610290064
|
£1.84
|
£2.21
|
|
|
112 - HEX NUT DIN 936-M8x1-8
BSD-1613300008.A11
1613300008
|
£2.74
|
£3.29
|
|
|
113 - TAPPING SCREW ST-4.8x57.5-TORX.T20
BSD-1613435009.A165
1613435009
|
£1.75
|
£2.10
|
|
|
116 - INNER RING
BSD-1610311017.A29
1610311017
|
£6.85
|
£8.22
|
|
|
121 - BUSHING
BSD-1610328018.A13
1610328018
|
£15.65
|
£18.78
|
|
|
126 - SCREW 4x16
BSD-2603490022.A2962
2603490022
|
£1.84
|
£2.21
|
|
|
131 - STICKER
BSD-160111C021.A1
160111C021
|
-
|
|
|
|
138 - SEALING FRAME
BSD-1611015050.A5
1611015050
|
£9.47
|
£11.36
|
|
|
141 - ROTARY SHAFT LIP SEAL
BSD-1610290066.A5
1610290066
|
£10.61
|
£12.73
|
|
|
142 - ROTARY SHAFT LIP SEAL
BSD-1610290061.A5
1610290061
|
£5.58
|
£6.70
|
|
|
143 - RETAINING RING DIN 7993-28x2
BSD-1614601021.A58
1614601021
|
£7.72
|
£9.27
|
|
|
145 - SPRING RETAINING RING
BSD-1610119012.A29
1610119012
|
£2.74
|
£3.29
|
|
|
150 - RETAINING RING
BSD-1614601041.A5
1614601041
|
£1.75
|
£2.10
|
|
|
154 - SPRING RETAINING RING 55x2MM. DIN 472
BSD-2916660024.A13
2916660024
|
£5.57
|
£6.68
|
|
|
160 - DAMPING RING
BSD-1610210172.A4
1610210172
|
£6.85
|
£8.22
|
|
|
162 - O-RING 24.0x4.0 MM
BSD-1610210091.A44
1610210091
|
£3.91
|
£4.69
|
|
|
163 - SEAL RING
BSD-1610290065.A56
1610290065
|
£8.54
|
£10.25
|
|
|
164 - O-RING 22.0x3.0 MM
BSD-1610210144.A33
1610210144
|
£5.30
|
£6.36
|
|
|
165 - O-RING 25.0x4.0 MM
BSD-1610210153.A11
1610210153
|
£7.36
|
£8.83
|
|
|
167 - ROTARY SHAFT LIP SEAL
BSD-1610290062.A17
1610290062
|
£3.91
|
£4.69
|
|
|
171 - TORX OVAL-HEAD SCREW M5x16-TORX.T25
BSD-1613435014.A10
1613435014
|
£2.27
|
£2.72
|
|
|
172 - TORX OVAL-HEAD SCREW M6x30-TORX.T30
BSD-1613435013.A51
1613435013
|
£2.16
|
£2.59
|
|
|
174 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A19
1613435012
|
£2.27
|
£2.72
|
|
|
175 - TAPPING SCREW DIN7981-ST3.9x13-C-Z
BSD-2912401018.A171
2912401018
|
£1.75
|
£2.10
|
|
|
176 - TORX OVAL-HEAD SCREW M4.8x25-TORX.T25
BSD-1613435012.A20
1613435012
|
£2.27
|
£2.72
|
|
|
177 - TAPPING SCREW ST3.9x32
BSD-1603435051.A86
1603435051
|
£2.05
|
£2.46
|
|
|
178 - CONNECTING CABLE
BSD-1604412069.A11
1604412069
|
£7.72
|
£9.27
|
|
|
661 - GREASE TUBE 30 ML
BSD-1615430010.A150
1615430010
|
£6.85
|
£8.22
|
|
|
801 - MOTOR HOUSING
BSD-1615102154.A11
1615102154
|
£22.50
|
£27.00
|
|
|
803 - ARMATURE 230V
BSD-1614011083.A7
1614011083
|
£120.11
|
£144.13
|
|
|
808 - NAMEPLATE
BSD-160111A3H5.A233
160111A3H5
|
£2.74
|
£3.29
|
|
|
811 - CARBON-BRUSH SET
BSD-1617014138.A11
1617014138
|
£22.60
|
£27.12
|
|
|
811 - CARBON-BRUSH SET 10 x 1 617 014 138
BSD-1607000493.A4
1607000493
|
£126.12
|
£151.34
|
|
|
817 - SPIRAL SPRING
BSD-1614652004.A4
1614652004
|
£7.72
|
£9.27
|
|
|
818 - SOCKET HEAD CAP SCREW DIN 84-AM3.5x12-5.8
BSD-2910011088.A97
2910011088
|
£1.84
|
£2.21
|
|
|
821 - BUSHING
BSD-1617000835.A12
1617000835
|
£22.76
|
£27.31
|
|
|
835 - HAMMER PIPE
BSD-1617000838.A1
1617000838
|
£135.25
|
£162.30
|
|
|
840 - IMPACT MECHANISM HOUSING
BSD-1617000837.A11
1617000837
|
£59.87
|
£71.84
|
|
|
841 - STRIKER PIN
BSD-1617000452.A12
1617000452
|
£42.84
|
£51.41
|
|
|
854 - STOP DISC
BSD-1617000442.A3
1617000442
|
£39.13
|
£46.96
|
|
|
856 - HAMMER PISTON
BSD-1617000836.A3
1617000836
|
£28.59
|
£34.31
|
|
|
874 - HOLDING-DOWN-APPLIANCE
BSD-1617000422.A11
1617000422
|
£13.78
|
£16.54
|
|
|
884 - AUXILIARY HANDLE dia62 MM
BSD-1612025055.A17
1612025055
|
£42.84
|
£51.41
|
|
|
886 - AUXILIARY HANDLE M8
BSD-1617000459.A18
1617000459
|
£13.78
|
£16.54
|
|
|
890 - MOUNTING SLEEVE
BSD-1609244B42.A11
1609244B42
|
-
|
|
|
|
892 - BOW
BSD-1609244B43.A11
1609244B43
|
-
|
|
|
|
895 - OIL RESERVOIR 1000 ML
BSD-1615430019.A59
1615430019
|
£59.53
|
£71.44
|
|
|
897 - WEAR AND TEAR PART SET
BSD-1617000A15.A1
1617000A15
|
£45.67
|
£54.80
|
|
|
898 - OIL RESERVOIR 50 ML
BSD-1615437512.A3
1615437512
|
£13.78
|
£16.54
|
|
