1 - HOUSING SECTION
BSD-2605104760.A6
2605104760
|
£37.27
|
£44.72
|
|
|
2 - FIELD 100-120V
BSD-2604220660.A8
2604220660
|
£27.23
|
£32.68
|
|
|
3 - ARMATURE 110V
BSD-2604011290.A1
2604011290
|
£46.82
|
£56.18
|
|
|
3/60 - FAN
BSD-2606610029.A6
2606610029
|
£2.61
|
£3.13
|
|
|
4 - SWITCH
BSD-2607200555.A0
2607200555
|
-
|
|
|
|
5 - POWER SUPPLY CORD GB 110V 4.15m 2 x 1.0mm H05 RN-F
BSD-2604460204.A59
2604460204
|
£31.64
|
£37.97
|
|
|
6 - GROMMET dia6.2-dia6.9x90 MM
BSD-2600707066.A3
2600707066
|
£2.48
|
£2.97
|
|
|
9 - MANUFACTURER'S NAMEPLATE
BSD-2601116359.A2
2601116359
|
£3.34
|
£4.01
|
|
|
14 - NEEDLE BEARING
BSD-2600914019.A96
2600914019
|
£5.30
|
£6.36
|
|
|
16 - BRUSH PLATE
BSD-2604337061.A35
2604337061
|
£14.91
|
£17.89
|
|
|
20 - REFERENCE PLATE
BSD-2601116360.A6
2601116360
|
£4.75
|
£5.70
|
|
|
22 - CHANGE-OVER SWITCH
BSD-2602098008.A138
2602098008
|
£1.75
|
£2.10
|
|
|
24 - TAPPING SCREW DIN 7981-ST2.2x9.5-C-H
BSD-2910611002.A196
2910611002
|
£1.75
|
£2.10
|
|
|
25 - O-RING 5.0x1.5 MM
BSD-1900210000.A573
1900210000
|
£1.75
|
£2.10
|
|
|
27 - DAMPING ELEMENT
BSD-2603239024.A4
2603239024
|
£1.75
|
£2.10
|
|
|
28 - OVAL-HEAD SCREW
BSD-2603429006.A4
2603429006
|
£1.32
|
£1.58
|
|
|
29 - HANDLE COVER
BSD-2608040177.A11
2608040177
|
£5.87
|
£7.04
|
|
|
30 - DRILLING SPINDLE
BSD-2606135116.A9
2606135116
|
£18.96
|
£22.75
|
|
|
31 - LOCKING WASHER 0.6 MM
BSD-2600118001.A120
2600118001
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.8 MM
BSD-2600118002.A117
2600118002
|
£1.75
|
£2.10
|
|
|
31 - LOCKING WASHER 0.3 MM
BSD-2600118006.A120
2600118006
|
-
|
|
|
|
32 - COMPRESSION SPRING
BSD-2604616006.A159
2604616006
|
£1.75
|
£2.10
|
|
|
33 - GROOVE BALL BEARING 17x35x10
BSD-1900905163.A445
1900905163
|
£11.30
|
£13.56
|
|
|
34 - CYLINDRICAL GEAR
BSD-2606317082.A26
2606317082
|
£13.12
|
£15.75
|
|
|
35 - CYLINDRICAL GEAR
BSD-2606317083.A30
2606317083
|
£11.30
|
£13.56
|
|
|
36 - SHIM 0.5 MM
BSD-2600100695.A223
2600100695
|
£1.75
|
£2.10
|
|
|
37 - SHIM 0.3 MM
BSD-2600101047.A494
2600101047
|
£1.75
|
£2.10
|
|
|
38 - CONTACT STRAP
BSD-2601329072.A7
2601329072
|
-
|
|
|
|
39 - RETAINING WASHER
BSD-2600101084.A52
2600101084
|
£1.75
|
£2.10
|
|
|
40 - FLAT KEY
BSD-2602300034.A38
2602300034
|
-
|
|
|
|
41 - GUIDING PLATE
BSD-2601098031.A39
2601098031
|
£1.75
|
£2.10
|
|
|
42 - CATCH DISK
BSD-2600190070.A33
2600190070
|
£5.58
|
£6.70
|
|
|
44 - BALL DIN 5401-5.5MM-III-ST
BSD-1903230010.A583
1903230010
|
£1.75
|
£2.10
|
|
|
45 - INDEXING DISK
BSD-2601990041.A6
2601990041
|
£1.75
|
£2.10
|
|
|
46 - PRESSURE PLATE
BSD-2601074003.A59
2601074003
|
£1.75
|
£2.10
|
|
|
52 - SHIM 0.3 MM
BSD-2600100607.A964
2600100607
|
£1.75
|
£2.10
|
|
|
54 - BEARING SLEEVE
BSD-2600400027.A105
2600400027
|
£4.26
|
£5.11
|
|
|
56 - FORK LEVER
BSD-2601990009.A34
2601990009
|
£2.29
|
£2.75
|
|
|
57 - ROTARY KNOB
BSD-2602026119.A6
2602026119
|
-
|
|
|
|
58 - RATCHET CAP
BSD-2600590006.A1175
2600590006
|
£1.75
|
£2.10
|
|
|
62 - DRIVER PIN
BSD-2601335001.A7
2601335001
|
£2.16
|
£2.59
|
|
|
63 - LOCKING WASHER 4 DIN 6799
BSD-2916080907.A4
2916080907
|
£2.16
|
£2.59
|
|
|
64 - SHIM WASHER
BSD-2600100618.A238
2600100618
|
£1.75
|
£2.10
|
|
|
66 - BEARING BRACKET
BSD-2605807085.A12
2605807085
|
£19.45
|
£23.34
|
|
|
67 - CATCH DISK
BSD-2600190071.A34
2600190071
|
£6.52
|
£7.83
|
|
|
68 - NEEDLE-ROLLER BEARING dia6 MM
BSD-2600914010.A531
2600914010
|
£2.80
|
£3.36
|
|
|
76 - FELT STRIP
BSD-2601005011.A39
2601005011
|
-
|
|
|
|
77 - FELT STRIP
BSD-2601005021.A18
2601005021
|
£1.32
|
£1.58
|
|
|
80 - KEY CHUCK
BSD-2608571065.A20
2608571065
|
£37.27
|
£44.72
|
|
|
80/700 - CHUCK WRENCH SG2
BSD-2607950007.A1036
2607950007
|
£6.52
|
£7.83
|
|
|
90 - PVC-INSULATED CABLE L=120 MM
BSD-2604448228.A126
2604448228
|
£2.16
|
£2.59
|
|
|
91 - PVC-INSULATED CABLE L=95 MM
BSD-1614431025.A51
1614431025
|
£2.61
|
£3.13
|
|
|
96 - PLAIN WASHER
BSD-2600100066.A59
2600100066
|
£1.75
|
£2.10
|
|
|
653 - AUXILIARY HANDLE dia43 MM
BSD-2602025118.A126
2602025118
|
£14.91
|
£17.89
|
|
|
653/120 - AUXILIARY HANDLE M8
BSD-1612025019.A47
1612025019
|
£6.52
|
£7.83
|
|
|
653/124 - CLAMPING BAND dia43 MM
BSD-1611316006.A394
1611316006
|
£2.61
|
£3.13
|
|
|
653/125 - T-HEAD BOLT M8x40 MM
BSD-1613490002.A188
1613490002
|
£4.26
|
£5.11
|
|
|
653/802 - SUPPORT CLAMP dia43 MM
BSD-2608040176.A123
2608040176
|
£6.52
|
£7.83
|
|
|
655 - DEPTH-GAUGE SW 6x210 MM
BSD-1613001009.A681
1613001009
|
£3.72
|
£4.47
|
|
|
808 - MARKING PLATE
BSD-2601116377.A0
2601116377
|
£2.33
|
£2.80
|
|
|
816/04 - BRUSH HOLDER
BSD-1607000CJ1.A45
1607000CJ1
|
-
|
|
|
|
819 - TAPPING SCREW DIN 7981-ST2.9x13-C-H
BSD-2910611006.A177
2910611006
|
£1.75
|
£2.10
|
|
|
823 - TAPPING SCREW DIN 7981-ST3.9x19-C-H
BSD-2910611020.A474
2910611020
|
£1.75
|
£2.10
|
|
|
849 - TOOTHED SHAFT
BSD-2606309935.A3
2606309935
|
£21.52
|
£25.83
|
|
|
849/50 - HELICAL GEAR Z=29
BSD-2606319080.A7
2606319080
|
£6.52
|
£7.83
|
|
|
866 - BEARING BRACKET
BSD-2605807934.A15
2605807934
|
-
|
|
|
|
890 - FASTENING PARTS KIT
BSD-2607001305.A130
2607001305
|
£4.26
|
£5.11
|
|
|
891 - CROSS RECESSED-HEAD SCREW M3x5
BSD-2603410046.A186
2603410046
|
£2.16
|
£2.59
|
|
