3 - SEAL RING
BSD-1600209006.A22
1600209006
|
£2.94
|
£3.53
|
|
|
4 - AIR-DEFLECTOR RING
BSD-1600209003.A49
1600209003
|
£8.13
|
£9.76
|
|
|
6 - O-RING 66.0x3.0 MM
BSD-1600210005.A148
1600210005
|
£2.80
|
£3.36
|
|
|
11 - SWITCH
BSD-1607200038.A100
1607200038
|
£57.14
|
£68.57
|
|
|
12 - GROMMET dia11.5-dia15.0x150 MM
BSD-1600703009.A314
1600703009
|
£5.87
|
£7.04
|
|
|
14 - FASTENING CLAMP
BSD-1601303003.A188
1601303003
|
£2.27
|
£2.72
|
|
|
16 - INSULATING STRIP 33x10x6 MM
BSD-1602381001.A491
1602381001
|
-
|
|
|
|
18 - NAMEPLATE
BSD-3601106053.A361
3601106053
|
£5.57
|
£6.68
|
|
|
21 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x55-8.8
BSD-2910141176.A9
2910141176
|
£1.84
|
£2.21
|
|
|
22 - HEX SOCKET HEAD CAP SCREW DIN 912-M5x45-8.8
BSD-2910141172.A49
2910141172
|
£1.84
|
£2.21
|
|
|
24 - HEX SOCKET HEAD CAP SCREW DIN 912-M5X16-8.8
BSD-2910141158.A81
2910141158
|
£1.84
|
£2.21
|
|
|
25 - SOCKET HEAD CAP SCREW DIN 84-AM4x6-8.8
BSD-2910021116.A135
2910021116
|
£2.27
|
£2.72
|
|
|
27 - PAN HEAD SCREW DIN 85-MS-M 4x12
BSD-2910110122.A84
2910110122
|
£1.84
|
£2.21
|
|
|
28 - TAPPING SCREW DIN 7971-BZ3.9x19
BSD-2910211020.A110
2910211020
|
£2.16
|
£2.59
|
|
|
31 - SPRING WASHER dia4.2 MM
BSD-3600150006.A427
3600150006
|
£2.74
|
£3.29
|
|
|
32 - CLAMPING SADDLE
BSD-3601321001.A551
3601321001
|
£3.72
|
£4.47
|
|
|
33 - GROOVED NAIL DIN 1476-2x5 MM
BSD-3603133001.A750
3603133001
|
£2.61
|
£3.13
|
|
|
35 - SPINDLE BEARING
BSD-3605806116.A5
3605806116
|
-
|
|
|
|
36 - DRILLING SPINDLE
BSD-1603124039.A62
1603124039
|
-
|
|
|
|
37 - GROOVE BALL BEARING 15x32x8
BSD-1900900201.A27
1900900201
|
-
|
|
|
|
38 - RETAINING SNAP RING
BSD-3607030355.A12
3607030355
|
£19.91
|
£23.89
|
|
|
39 - SEALING DISK
BSD-1600108000.A71
1600108000
|
-
|
|
|
|
40 - SHIM 0.5 MM
BSD-1600102003.A60
1600102003
|
£1.75
|
£2.10
|
|
|
41 - SPACER BUSHING
BSD-1600300026.A10
1600300026
|
-
|
|
|
|
42 - GROOVE BALL BEARING 15x35x11
BSD-1900900303.A81
1900900303
|
-
|
|
|
|
43 - SPRING RETAINING RING DIN 472 35x1.5 MM
BSD-2916660014.A560
2916660014
|
£1.75
|
£2.10
|
|
|
44 - SPACER BUSHING
BSD-1600300027.A90
1600300027
|
-
|
|
|
|
45 - CYLINDRICAL GEAR Z=44
BSD-1606317047.A11
1606317047
|
-
|
|
|
|
46 - SPINDLE WITH GEAR Z=9/29
BSD-1606328051.A5
1606328051
|
-
|
|
|
|
47 - SHIM 0.5 MM
BSD-1600100631.A200
1600100631
|
£1.75
|
£2.10
|
|
|
48 - ROTOR WITHOUT WINDING
BSD-3604080057.A35
3604080057
|
£283.50
|
£340.20
|
|
|
48/3 - FAN
BSD-3606610010.A109
3606610010
|
£4.48
|
£5.37
|
|
|
49 - CONICAL SPRING WASHER
BSD-1600501025.A50
1600501025
|
£35.42
|
£42.51
|
|
|
50 - SEALING DISK
BSD-1600108030.A44
1600108030
|
£3.72
|
£4.47
|
|
|
51 - BEARING FLANGE
BSD-3605820056.A13
3605820056
|
-
|
|
|
|
52 - SOCKET HEAD CAP SCREW DIN 84-AM4x15-8.8
BSD-2910021125.A213
2910021125
|
£1.75
|
£2.10
|
|
|
53 - GROOVE BALL BEARING 12x28x8
BSD-1900905121.A258
1900905121
|
£18.96
|
£22.75
|
|
|
54 - GROOVE BALL BEARING 7x22x7
BSD-1610900025.A61
1610900025
|
£16.41
|
£19.69
|
|
|
56 - END SPLICE
BSD-3604477008.A218
3604477008
|
£1.75
|
£2.10
|
|
|
57 - SET SCREW
BSD-1603402002.A17
1603402002
|
£1.75
|
£2.10
|
|
|
69 - O-RING 22.0x1.5 MM
BSD-3600210016.A25
3600210016
|
£1.84
|
£2.21
|
|
|
650 - AUXILIARY HANDLE M14
BSD-1602025022.A761
1602025022
|
£13.41
|
£16.09
|
|
|
650 - AUXILIARY HANDLE M14. dia37x115 MM
BSD-1602025030.A210
1602025030
|
£19.91
|
£23.89
|
|
|
651 - KEY CHUCK dia1.5-13 MM. B16
BSD-1608571027.A69
1608571027
|
-
|
|
|
|
651/7 - CHUCK WRENCH
BSD-1607950027.A36
1607950027
|
-
|
|
|
|
800 - HANDLE
BSD-3605133011.A24
3605133011
|
-
|
|
|
|
802 - MOTOR HOUSING
BSD-3605102040.A48
3605102040
|
£229.32
|
£275.19
|
|
|
810 - STATOR 200V/300HZ
BSD-1604229089.A16
1604229089
|
£431.32
|
£517.59
|
|
