1 - MOTOR HOUSING
BSD-3605108589.A4
3605108589
|
-
|
|
|
|
2 - FIELD 100-110V
BSD-3604220535.A0
3604220535
|
-
|
|
|
|
3/70 - FAN
BSD-3606610517.A4
3606610517
|
-
|
|
|
|
4 - FAN HOUSING
BSD-3605702592.A20
3605702592
|
£81.81
|
£98.17
|
|
|
5 - HOUSING COVER
BSD-3605500575.A6
3605500575
|
£7.78
|
£9.33
|
|
|
6 - SEALING CAP
BSD-3605500596.A17
3605500596
|
£2.52
|
£3.02
|
|
|
7 - BASE PLATE
BSD-3605702595.A2
3605702595
|
£120.11
|
£144.13
|
|
|
8 - INTERMEDIATE PLATE
BSD-3600190515.A2
3600190515
|
-
|
|
|
|
9 - HANDLE
BSD-3605133519.A2
3605133519
|
-
|
|
|
|
10 - HANDLE
BSD-3605133520.A20
3605133520
|
-
|
|
|
|
12 - TOOTHED LOCK WASHER
BSD-3600190516.A20
3600190516
|
£2.61
|
£3.13
|
|
|
13 - ON-OFF SWITCH
BSD-3607200510.A17
3607200510
|
-
|
|
|
|
14 - SUPPRESSION FILTER
BSD-1607328034.A306
1607328034
|
£4.26
|
£5.11
|
|
|
15 - FASTENING CLAMP
BSD-3601032500.A2
3601032500
|
£7.36
|
£8.83
|
|
|
16 - TAPPING SCREW DIN 7981-ST3.5x13-C-H
BSD-2910611011.A3
2910611011
|
-
|
|
|
|
17 - POWER SUPPLY CORD
BSD-3604460609.A2
3604460609
|
-
|
|
|
|
18 - GROMMET dia 9.4 MM
BSD-3600707503.A74
3600707503
|
£3.72
|
£4.47
|
|
|
19 - SHOULDER SCREW M4
BSD-3603415556.A57
3603415556
|
£2.33
|
£2.80
|
|
|
21 - BRUSH HOLDER
BSD-1604336008.A37
1604336008
|
£21.52
|
£25.83
|
|
|
22 - THREADED SPINDLE
BSD-3603500500.A8
3603500500
|
-
|
|
|
|
23 - TAPPING SCREW DIN 7981-ST3.9x13-C-H
BSD-2910611018.A232
2910611018
|
-
|
|
|
|
24 - TAPPING SCREW DIN 7981-ST3.9x16-C-H
BSD-2910611019.A5
2910611019
|
£2.80
|
£3.36
|
|
|
25 - HEX SOCKET HEAD CAP SCREW DIN 912-M6x16-8.8
BSD-2910141197.A156
2910141197
|
£1.75
|
£2.10
|
|
|
26 - SPIRAL SPRING
BSD-1614652001.A48
1614652001
|
£3.72
|
£4.47
|
|
|
28 - TAB WASHER
BSD-1611331007.A37
1611331007
|
£1.32
|
£1.58
|
|
|
29 - TAPPING SCREW B 4.8x68 MM
BSD-1613412001.A170
1613412001
|
£1.75
|
£2.10
|
|
|
30 - GROOVE BALL BEARING 6200-2 RS/C 3
BSD-1900905276.A5
1900905276
|
-
|
|
|
|
31 - SPRING RETAINING RING
BSD-3600119507.A10
3600119507
|
-
|
|
|
|
32 - GROOVE BALL BEARING
BSD-3600900526.A7
3600900526
|
£31.64
|
£37.97
|
|
|
33 - FIXING PLATE
BSD-3600034503.A5
3600034503
|
-
|
|
|
|
34 - REC CT-SUNK TAPPING SCREW
BSD-3603415559.A15
3603415559
|
£1.95
|
£2.34
|
|
|
35 - HEX NUT
BSD-3603301522.A0
3603301522
|
-
|
|
|
|
37 - RETAINING BRACKET
BSD-3601961500.A9
3601961500
|
-
|
|
|
|
38 - COMPRESSION SPRING
BSD-3604613502.A15
3604613502
|
-
|
|
|
|
39 - SCREW DIN 7982-ST4.8x19
BSD-2910611034.A31
2910611034
|
-
|
|
|
|
40 - SCREW 4x13 MM
BSD-3603415540.A5
3603415540
|
£2.61
|
£3.13
|
|
|
41 - DEPTH-GAUGE
BSD-3600232503.A5
3600232503
|
£10.82
|
£12.99
|
|
|
42 - SPRING RETAINING RING DIN 471 25x1.2
BSD-2916650014.A152
2916650014
|
£1.75
|
£2.10
|
|
|
43 - LEAF SPRING
BSD-3601254501.A18
3601254501
|
£8.49
|
£10.19
|
|
|
44 - LOCKING LEVER
BSD-3602033500.A18
3602033500
|
£1.75
|
£2.10
|
|
|
45 - AXLE
BSD-3603053503.A17
3603053503
|
-
|
|
|
|
46 - COMPRESSION SPRING
BSD-3604613503.A7
3604613503
|
£2.61
|
£3.13
|
|
|
47 - OVAL-HEAD SCREW DIN 7985-M4x8-8.8-H
BSD-2910951118.A57
2910951118
|
£1.75
|
£2.10
|
|
|
48 - HEX NUT DIN 985-M10-10
BSD-2915065007.A15
2915065007
|
-
|
|
|
|
49 - ADJUSTING NUT
BSD-2603345015.A40
2603345015
|
-
|
|
|
|
50 - GUIDE PIECE
BSD-3603120501.A22
3603120501
|
-
|
|
|
|
51 - ADJUSTING LEVER
BSD-3602000509.A3
3602000509
|
-
|
|
|
|
52 - CLAMPING SPRING
BSD-3604651501.A19
3604651501
|
-
|
|
|
|
53 - ADJUSTING ECCENTRIC
BSD-3602202500.A3
3602202500
|
-
|
|
|
|
54 - PLAIN WASHER DIN 125-A4.3-ST
BSD-2916011010.A51
2916011010
|
£1.75
|
£2.10
|
|
|
55 - HEX NUT DIN 985-M4-8
BSD-2915061002.A5
2915061002
|
£1.75
|
£2.10
|
|
|
56 - SCREW B 4.8x45 MM
BSD-3603415560.A11
3603415560
|
£1.75
|
£2.10
|
|
|
57 - COMPRESSION SPRING
BSD-3604619502.A18
3604619502
|
£2.61
|
£3.13
|
|
|
58 - HEX NUT DIN 439-BM10-04
BSD-2915055108.A18
2915055108
|
-
|
|
|
|
59 - SPRING WASHER
BSD-3916060500.A68
3916060500
|
£1.75
|
£2.10
|
|
|
61 - MANUFACTURER'S NAMEPLATE
BSD-3601119653.A0
3601119653
|
-
|
|
|
|
62 - UNION NUT SW27
BSD-3603313507.A7
3603313507
|
-
|
|
|
|
63 - PROTECTIVE SHIELD
BSD-3605510526.A20
3605510526
|
-
|
|
|
|
65 - REC CT-SUNK TAPPING SCREW DIN 7982-ST4.8x18-F-H
BSD-2910601433.A4
2910601433
|
-
|
|
|
|
67 - INSULATING TUBE
BSD-3601007502.A4
3601007502
|
-
|
|
|
|
74 - AIR-DEFLECTOR RING
BSD-3600590504.A12
3600590504
|
-
|
|
|
|
75 - TAB WASHER
BSD-1601030022.A67
1601030022
|
£1.75
|
£2.10
|
|
|
80 - THREAD-FORMING TAP. SCREW DIN 7500-CM 4x8-ST
BSD-2914411045.A15
2914411045
|
-
|
|
|
|
650/10 - GUIDE PLATE
BSD-3602386501.A7
3602386501
|
-
|
|
|
|
650/20 - RIM
BSD-2610996063.A2
2610996063
|
-
|
|
|
|
650/30 - PLAIN WASHER DIN 433-5.3-ST
BSD-2916011011.A180
2916011011
|
£1.75
|
£2.10
|
|
|
650/40 - SOCKET HEAD CAP SCREW DIN 84-AM5x12-8.8
BSD-2910021154.A120
2910021154
|
£1.75
|
£2.10
|
|
|
650/50 - HEX NUT DIN 934-M 5-m-8
BSD-2915011006.A51
2915011006
|
-
|
|
|
|
650/60 - GUIDE ROD 10 MM
BSD-3603001518.A19
3603001518
|
-
|
|
|
|
650/70 - WING SCREW M 6x16 MM
BSD-2603480003.A168
2603480003
|
£2.61
|
£3.13
|
|
|
650/80 - MANUFACTURER'S NAMEPLATE
BSD-3601119612.A7
3601119612
|
£2.52
|
£3.02
|
|
|
654 - TOOL GUIDE dia 30 MM
BSD-3605703528.A2
3605703528
|
-
|
|
|
|
655 - THREADED SPINDLE M 12x1 MM
BSD-3603523501.A2
3603523501
|
-
|
|
|
|
656 - COLLET dia 1/2
BSD-3600499520.A7
3600499520
|
-
|
|
|
|
657 - SINGLE-HEAD ENG. WRENCH
BSD-2607950504.A5
2607950504
|
£2.52
|
£3.02
|
|
|
658 - SINGLE-HEAD ENG. WRENCH DIN 894 SW27
BSD-1907950514.A6
1907950514
|
-
|
|
|
|
700 - TOOL GUIDE dia 27 MM
BSD-3605703527.A8
3605703527
|
-
|
|
|
|
700 - TOOL GUIDE dia 40 MM
BSD-3605703529.A8
3605703529
|
-
|
|
|
|
701/5 - COLLET dia 6 MM
BSD-3608570500.A6
3608570500
|
-
|
|
|
|
701/5 - COLLET 1/4
BSD-3600499503.A2
3600499503
|
-
|
|
|
|
701/5 - COLLET dia 8 MM
BSD-3608570502.A4
3608570502
|
-
|
|
|
|
701/5 - COLLET 3/8
BSD-3600499502.A8
3600499502
|
-
|
|
|
|
701/5 - COLLET dia 10 MM
BSD-3608570504.A6
3608570504
|
-
|
|
|
|
800 - CARBON-BRUSH SET
BSD-1607014103.A240
1607014103
|
£14.91
|
£17.89
|
|
|
809 - SOCKET HEAD CAP SCREW M3x6.5-4.8
BSD-2603410001.A725
2603410001
|
£1.75
|
£2.10
|
|
|
810 - NAMEPLATE
BSD-3601119779.A13
3601119779
|
-
|
|
|
|
816 - DEPTH-GAUGE
BSD-3603029500.A16
3603029500
|
-
|
|
|
|
824 - VACUUM ADAPTER
BSD-3608939626.A1
3608939626
|
-
|
|
|
|
825 - VACUUM ADAPTER
BSD-3608939611.A9
3608939611
|
-
|
|
|
|
826 - BRUSH-COVER
BSD-3607929500.A3
3607929500
|
-
|
|
|
|
827 - COUNTERSUNK-HEAD SCREW DIN 963-M5x25-4.8
BSD-2910761164.A8
2910761164
|
-
|
|
|
|
830 - ARMATURE 110V
BSD-3604011598.A0
3604011598
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1639
160111A3H3
|
£2.61
|
£3.13
|
|
