25 - GEAR HOUSING
BSD-2605806306.A3
2605806306
|
-
|
|
|
|
26 - GROOVE BALL BEARING 20x42x12
BSD-1900900274.A28
1900900274
|
£27.23
|
£32.68
|
|
|
27 - NEEDLE BEARING
BSD-2600914011.A13
2600914011
|
£22.60
|
£27.12
|
|
|
28 - GEAR COVER
BSD-2605500042.A10
2605500042
|
£50.80
|
£60.96
|
|
|
30 - RETAINING RING
BSD-2600224009.A8
2600224009
|
£1.84
|
£2.21
|
|
|
31 - SPRING RETAINING RING DIN 471 20x1.2
BSD-2916650011.A18
2916650011
|
£2.16
|
£2.59
|
|
|
32 - DISC SPRING
BSD-2600550017.A10
2600550017
|
£5.58
|
£6.70
|
|
|
33 - RING GEAR Z=66
BSD-2606334040.A18
2606334040
|
£27.23
|
£32.68
|
|
|
34 - CYLINDRICAL GEAR Z=29
BSD-2606316033.A3
2606316033
|
-
|
|
|
|
35 - NEEDLE ROLLER
BSD-1903201520.A26
1903201520
|
£1.75
|
£2.10
|
|
|
37 - NEEDLE-ROLLER CAGE
BSD-2600913035.A17
2600913035
|
£11.30
|
£13.56
|
|
|
38 - CONNECTING ROD
BSD-2602001001.A21
2602001001
|
£54.42
|
£65.30
|
|
|
39 - BEARING BOLT
BSD-2603100003.A51
2603100003
|
£2.61
|
£3.13
|
|
|
40 - BUSHING
BSD-2600422005.A14
2600422005
|
£19.91
|
£23.89
|
|
|
41 - POWER PISTON
BSD-2603104001.A19
2603104001
|
£57.14
|
£68.57
|
|
|
42 - UNION NUT
BSD-3603340017.A14
3603340017
|
£33.74
|
£40.49
|
|
|
43 - HOLLOW BOLT
BSD-2603455006.A16
2603455006
|
£2.80
|
£3.36
|
|
|
44 - LOWER DIE RING
BSD-2608639015.A5
2608639015
|
-
|
|
|
|
45 - NIBBLING PUNCH
BSD-2608639013.A25
2608639013
|
£25.72
|
£30.86
|
|
|
46 - LOWER DIE
BSD-2608639014.A3
2608639014
|
-
|
|
|
|
47 - HEX SOCKET HEAD CAP SCREW
BSD-2603414003.A8
2603414003
|
£6.52
|
£7.83
|
|
|
49 - SHIM 1.2 MM
BSD-1600100611.A20
1600100611
|
£1.84
|
£2.21
|
|
|
50 - SPRING LOCK WASHER DIN 128-A4-FST
BSD-2916690003.A49
2916690003
|
£1.75
|
£2.10
|
|
|
51 - SOCKET HEAD CAP SCREW DIN 84-BM4x40-8.8
BSD-2910021138.A34
2910021138
|
£2.74
|
£3.29
|
|
|
52 - SEAL BUSHING
BSD-2600300047.A28
2600300047
|
£2.74
|
£3.29
|
|
|
53 - BEARING FLANGE
BSD-2605700182.A10
2605700182
|
-
|
|
|
|
54 - GROOVE BALL BEARING 9x24x7
BSD-2600905021.A447
2600905021
|
£8.67
|
£10.41
|
|
|
54 - GROOVE BALL BEARING 9x24x7
BSD-2600905039.A26
2600905039
|
£12.64
|
£15.17
|
|
|
55 - TAPPING SCREW DIN 7971-B3.9x45
BSD-2910211283.A11
2910211283
|
£2.74
|
£3.29
|
|
|
101 - MOTOR HOUSING
BSD-2605108060.A21
2605108060
|
£15.65
|
£18.78
|
|
|
102 - FIELD 240V
BSD-2604220503.A5
2604220503
|
£33.74
|
£40.49
|
|
|
103 - ARMATURE 240V
BSD-2604011075.A0
2604011075
|
£59.53
|
£71.44
|
|
|
103/60 - FAN
BSD-2606610081.A10
2606610081
|
£6.85
|
£8.22
|
|
|
104 - SWITCH
BSD-2607200286.A23
2607200286
|
£15.65
|
£18.78
|
|
|
105 - POWER SUPPLY CORD GB 2.65m 2 x 1.0mm H05 VV-F
BSD-2604420031.A2
2604420031
|
-
|
|
|
|
106 - GROMMET dia8.3-dia9.4x95 MM
BSD-2600703011.A202
2600703011
|
£2.94
|
£3.53
|
|
|
107 - FASTENING CLAMP
BSD-1601302017.A473
1601302017
|
£1.84
|
£2.21
|
|
|
109 - STICKER
BSD-3601110349.A3
3601110349
|
-
|
|
|
|
112 - SWITCH
BSD-2607200286.A24
2607200286
|
£15.65
|
£18.78
|
|
|
113 - BALL BEARING 7x19x6
BSD-2600905032.A330
2600905032
|
£5.57
|
£6.68
|
|
|
119 - TAPPING SCREW DIN 7971-BZ3.5x13
BSD-2910211011.A240
2910211011
|
£1.84
|
£2.21
|
|
|
120 - STICKER
BSD-3601110351.A8
3601110351
|
£2.94
|
£3.53
|
|
|
125 - COVER DISC
BSD-2601328002.A4
2601328002
|
£2.80
|
£3.36
|
|
|
126 - SWITCH ROCKER
BSD-2608001005.A7
2608001005
|
£2.94
|
£3.53
|
|
|
127 - SWITCH SLIDE
BSD-2608001008.A3
2608001008
|
£2.16
|
£2.59
|
|
|
128 - COMPRESSION SPRING
BSD-2604611033.A12
2604611033
|
£2.16
|
£2.59
|
|
|
129 - SWITCH HANDLE
BSD-2608001010.A26
2608001010
|
£2.80
|
£3.36
|
|
|
130 - SHIM
BSD-2600150003.A203
2600150003
|
£2.16
|
£2.59
|
|
|
131 - SHIM 0.3 MM
BSD-2600101617.A12
2600101617
|
£1.84
|
£2.21
|
|
|
132 - BRUSH HOLDER
BSD-3604336010.A11
3604336010
|
£54.42
|
£65.30
|
|
|
133 - HOUSING COVER
BSD-2605104339.A6
2605104339
|
£14.91
|
£17.89
|
|
|
134 - TAPPING SCREW DIN 7971-B3.9x45
BSD-2910211283.A10
2910211283
|
£2.74
|
£3.29
|
|
|
135 - TAPPING SCREW DIN 7971-BZ2.9x16
BSD-2910211007.A35
2910211007
|
£1.75
|
£2.10
|
|
|
136 - STICKER
BSD-3601110206.A12
3601110206
|
£2.80
|
£3.36
|
|
|
138 - CONTACT SPRING
BSD-2601329037.A35
2601329037
|
£1.75
|
£2.10
|
|
|
754 - NIBBLING PUNCH
BSD-2608639013.A20
2608639013
|
£25.72
|
£30.86
|
|
|
755 - OFFSET SCREWDRIVER DIN 911 SW2.5
BSD-1907950003.A13
1907950003
|
£2.61
|
£3.13
|
|
|
805/20 - END SPLICE DIN 46 228-A1-6
BSD-1900452012.A377
1900452012
|
£1.75
|
£2.10
|
|
|
818 - SOCKET HEAD CAP SCREW M 3.5x7 MM
BSD-3607030229.A21
3607030229
|
£5.58
|
£6.70
|
|
|
829 - ECCENTRIC SHAFT
BSD-2606122900.A9
2606122900
|
-
|
|
|
|
832/080 - SPIRAL SPRING
BSD-1604652013.A552
1604652013
|
£1.84
|
£2.21
|
|
|
832/090 - CARBON-BRUSH SET
BSD-160701417J.A11
160701417J
|
£10.61
|
£12.73
|
|
|
846 - LOWER DIE
BSD-2608639900.A10
2608639900
|
£83.12
|
£99.74
|
|
|
848 - LOCKING WASHER DIN 6799-5-FSt
BSD-2916080008.A170
2916080008
|
-
|
|
|
|
888 - NAMEPLATE
BSD-160111A3H3.A1153
160111A3H3
|
£2.74
|
£3.29
|
|
